AM-/AMC-/AMS-117
Low Noise Amplifier
V2.00
0.016 W±0.002 (0.41±0.5) X
0.010 T±0.001 (0.25±0.03)
GROUND TAB
SF-1
Typical Performance
0.060
(1.52)
ORIENTATION
GAIN
MARK
1
2
0.385±0.020
(0.8±0.5)
3
4
0.072
(1.83)
0.205
(5.21)
0.305
(7.75)
0.422
0.170
(4.31)
MAX
(10.72)
0.510±0.20
(12.9±0.5)
VSWR
Dimensions in ( ) are in mm.
Unless otherwise noted: .xxx = ±0.010 (.xx = ±0.25)
WEIGHT (APPROX.) : 0.07 OUNCES 2 GRAMS
Pin Configuration
AMC-117
NOISE FIGURE
INTERMODULATION INTERCEPT
AMS-117
Typical S-Parameter Data
1 DB COMPRESSION
AM-117
S11
S21
S12
S22
FREQUENCY MAG ANG MAG ANG MAG ANG MAG ANG
10.0
20.0
50.0
0.04 -166.2 2.59 3.7 0.29
4.1 0.04 -172.2
0.03 -151.6 2.60 -1.5 0.29 -1.0 0.04 -170.2
0.03 -133.5 2.61 -9.6 0.29 -8.3 0.03 -163.4
0.04 -128.7 2.60 -15.2 0.29 -13.4 0.03 -164.6
0.06 -124.3 2.59 -20.9 0.29 -18.1 0.05 -167.0
0.08 -124.1 2.59 -26.3 0.29 -22.7 0.06 -168.0
0.11 -121.6 2.60 -31.4 0.29 -27.5 0.06 -169.3
0.13 -123.3 2.60 -36.8 0.29 -32.2 0.07 -170.0
0.14 -124.6 2.59 -42.2 0.28 -37.0 0.07 -171.1
75.0
100.0
125.0
150.0
175.0
200.0
Frequency in MHz
Specifications Subject to Change Without Notice.
