VVZ 12
IdAVM = 20 A
VRRM = 1200-1600 V
Three Phase Half Controlled
Rectifier Bridge
4
3
2
2
8
1
VRSM
VDSM
VRRM
VDRM
Type
7
6
3
1
6
5
5
7
4
V
V
1300
1500
1700
1200
1400
1600
VVZ 12-12io1
VVZ 12-14io1
VVZ 12-16io1
8
Features
Symbol
Test Conditions
Maximum Ratings
●
Package with DCB ceramic base plate
Isolation voltage 3600 V~
Planar passivated chips
Soldering terminals
IdAV
IdAVM
IFRMS, ITRMS
TK = 100°C; module
module
per leg
15
20
12
A
A
A
●
●
●
●
IFSM, ITSM
TVJ = 45°C;
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
110
115
A
A
UL registered E 72873
TVJ = TVJM
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
100
105
A
A
Applications
●
Input rectifier for switch mode power
I2t
TVJ = 45°C
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
60
55
A2s
A2s
supplies (SMPS)
Softstart capacitor charging
Electric drives and auxiliaries
●
●
TVJ = TVJM
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
50
45
A2s
A2s
Advantages
(di/dt)cr
TVJ = TVJM
repetitive, IT = 50 A
150
A/ms
●
Easy to mount with two screws
Space and weight savings
Improved temperature and power
cycling
f =400 Hz, tP =200 ms
VD = 2/3 VDRM
IG = 0.3 A,
●
●
non repetitive, IT = 1/3 ˜ IdAV
500
1000
10
A/ms
V/ms
V
diG/dt = 0.3 A/ms
(dv/dt)cr
TVJ = TVJM; VDR = 2/3 VDRM
RGK = ¥; method 1 (linear voltage rise)
Dimensions in mm (1 mm = 0.0394")
VRGM
PGM
TVJ = TVJM
IT = ITAVM
tp = 30 ms
tp = 500 ms
tp = 10 ms
£
£
£
10
5
1
W
W
W
W
PGAVM
0.5
TVJ
TVJM
Tstg
-40...+125
125
-40...+125
°C
°C
°C
VISOL
50/60 Hz, RMS
t = 1 min
t = 1 s
3000
3600
V~
V~
IISOL £ 1 mA
Md
Mounting torque
typ.
(M5)
(10-32 UNF)
2-2.5
18-22
28
Nm
lb.in.
g
Weight
Data according to IEC 60747 and refer to a single thyristor/diode unless otherwise stated.
IXYS reserves the right to change limits, test conditions and dimensions.
