IXTN8N150L
Symbol
Test Conditions
Characteristic Values
SOT-227B (IXTN) Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS= 50V, ID = 4A, Note 1
1.4
2.3
3.2 S
Ciss
Coss
Crss
8000
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
405
70
td(on)
tr
td(off)
tf
36
18
90
95
ns
ns
ns
ns
Resistive Switching Times
V
GS = 15V, VDS = 0.5 • VDSS, ID = 4A
RG = 2Ω (External)
(M4 screws (4x) supplied)
Qg(on)
Qgs
250
80
nC
nC
nC
VGS= 15V, VDS = 0.5 • VDSS, ID = 4A
Qgd
116
RthJC
RthCS
0.23 °C/W
°C/W
0.05
Safe Operating Area Specification
Symbol
SOA
Test Conditions
Characteristic Values
Min. Typ. Max.
VDS = 1500V, ID = 0.17A, TC = 60°C, TP = 3s 255
W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
8
A
A
ISM
VSD
trr
Repetitive, Pulse Width Limited by TJM
32
IF = 8A, VGS = 0V, Note 1
1.2
V
IF = IS, -di/dt = 100A/µs, VR = 100V
1700
ns
Notes: 1. Pulse Test, t ≤ 300µs; Duty Cycle, d ≤ 2%.
