IXTF03N400
Symbol
Test Conditions
Characteristic Values
ISOPLUS i4-PakTM (HV) Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 50V, ID = 100mA, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
110
180
mS
Ciss
Coss
Crss
435
19
6
pF
pF
pF
td(on)
tr
td(off)
tf
17
16
86
58
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 250V, ID = 150mA
RG = 50Ω (External)
Qg(on)
Qgs
16.3
1.9
nC
nC
nC
Pin 1 = Gate
PIN 1 = Gate
Pin 2 = Source
PIN 2 = Source
Pin 3 = Drain
PIN 3 = Drain
VGS = 10V, VDS = 1kV, ID = 0.5 • ID25
Tab 4 = Isolated
TAP 4 = Electically Isolated 4000V
Qgd
8.8
RthJC
RthCS
1.78 °C/W
°C/W
0.15
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
300 mA
ISM
VSD
trr
Repetitive, Pulse Width Limited by TJM
IF = 300mA, VGS = 0V, Note 1
IF = 1A, -di/dt = 100A/μs, VR = 200V
1.2
3.0
A
V
2.8
μs
Notes: 1. Pulse test, t < 300μs, duty cycle, d < 2%.
2. Device must be heatsunk for high-temperature leakage current
measurements to avoid thermal runaway.
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from a subjective evaluation of the design, based upon prior knowledge and experience, and constitute a
"considered reflection" of the anticipated result. IXYS reserves the right to change limits, test
conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
