IXTH15N50L2

型号:

IXTH15N50L2

品牌:

IXYS[ IXYS CORPORATION ]

页数:

5 页

PDF大小:

170 K

Linear L2TM
Power MOSFETs
w/ Extended FBSOA
VDSS = 500V
ID25 = 15A
RDS(on) 480mΩ
IXTA15N50L2
IXTP15N50L2
IXTH15N50L2
N-Channel Enhancement Mode
Avalanche Rated
TO-263 AA (IXTA)
G
S
D (Tab)
Symbol
VDSS
Test Conditions
Maximum Ratings
TO-220AB (IXTP)
TJ = 25°C to 150°C
TJ = 25°C to 150°C, RGS = 1MΩ
500
500
V
V
VDGR
VGSS
VGSM
Continuous
Transient
±20
±30
V
V
G
D
ID25
IDM
TC = 25°C
TC = 25°C, Pulse Width Limited by TJM
15
35
A
A
D (Tab)
S
TO-247 (IXTH)
IA
EAS
TC = 25°C
TC = 25°C
15
A
750
mJ
PD
TC = 25°C
300
W
TJ
TJM
Tstg
-55 ... +150
150
-55 ... +150
°C
°C
°C
G
D
D (Tab)
S
TL
TSOLD
1.6mm (0.062 in.) from Case for 10s
Plastic Body for 10s
300
260
°C
°C
G = Gate
S = Source
D
= Drain
Tab = Drain
Md
Mounting Torque (TO-220 & TO-247)
1.13/10
Nm/lb.in.
Features
Weight
TO-263
TO-220
TO-247
2.5
3.0
6.0
g
g
g
z
Designed for Linear Operation
International Standard Packages
Avalanche Rated
Molding Epoxies Meet UL 94 V-0
Flammability Classification
Guaranteed FBSOA at 75°C
z
z
z
z
Advantages
Symbol
Test Conditions
Characteristic Values
z
Easy to Mount
Space Savings
High Power Density
(TJ = 25°C, Unless Otherwise Specified)
Min.
500
2.5
Typ. Max.
z
z
BVDSS
VGS(th)
IGSS
VGS = 0V, ID = 250μA
VDS = VGS, ID = 250μA
VGS = ± 20V, VDS = 0V
VDS = VDSS, VGS = 0V
V
V
4.5
Applications
±100 nA
z
IDSS
25 μA
200 μA
Solid State Circuit Breakers
Soft Start Controls
Linear Amplifiers
Programmable Loads
z
TJ = 125°C
z
RDS(on)
VGS = 10V, ID = 0.5 • ID25, Note 1
480 mΩ
z
z
Current Regulators
DS100054B(12/11)
© 2011 IXYS CORPORATION, All Rights Reserved
IXTA15N50L2 IXTP15N50L2
IXTH15N50L2
Symbol
Test Conditions
Characteristic Values
TO-247 Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 10V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
4.5
6.3
8.0
S
Ciss
Coss
Crss
4080
265
68
pF
pF
pF
td(on)
tr
td(off)
tf
38
73
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, 0.5 • VDSS, ID = 0.5 • ID25
RG = 10Ω (External)
110
65
Qg(on)
Qgs
123
20
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
nC
1 = Gate
2 = Drain
3 = Source
Qgd
72
nC
RthJC
RthCS
0.42 °C/W
(TO-220)
(TO-247)
0.50
0.25
°C/W
°C/W
Safe Operating Area Specification
Characteristic Values
Min. Typ. Max.
Symbol
SOA
Test Conditions
VDS = 400V, ID = 375mA, TC = 75°C, tp = 2s 150
W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
TO-220 Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
15
A
A
ISM
VSD
trr
Repetitive, pulse width limited by TJM
IF = 15A, VGS = 0V, Note 1
60
1.5
V
IF = 15A, -di/dt = 100A/μs, VR = 100V, VGS = 0V
570
ns
Note
1: Pulse test, t 300μs, duty cycle, d 2%.
TO-263 Outline
Pins: 1 - Gate
3 - Source
2 - Drain
1 = Gate
2 = Drain
3 = Source
4 = Drain
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXYS MOSFETs and IGBTs are covered
by one or more of the following U.S. patents: 4,850,072 5,017,508
4,881,106 5,034,796
4,835,592 4,931,844
5,049,961
5,063,307
5,187,117
5,237,481
5,381,025
5,486,715
6,162,665
6,259,123 B1
6,306,728 B1
6,404,065 B1 6,683,344
6,534,343
6,583,505
6,727,585
6,710,405 B2 6,759,692
6,710,463
7,005,734 B2 7,157,338B2
7,063,975 B2
6,771,478 B2 7,071,537
IXTA15N50L2 IXTP15N50L2
IXTH15N50L2
Fig. 1. Output Characteristics @ TJ =25ºC
Fig. 2. Extended Output Characteristics @ TJ = 25ºC
16
14
12
10
8
40
35
30
25
20
15
10
5
VGS = 20V
VGS = 20V
14V
12V
10V
12V
10V
9V
8V
7V
9V
8V
6
4
6V
5V
7V
2
6V
5V
0
0
0
0
0
1
2
3
4
5
6
7
0
5
10
15
20
25
30
VDS - Volts
VDS - Volts
Fig. 4. RDS(on) Normalized to ID = 7.5A Value vs.
Junction Temperature
Fig. 3. Output Characteristics @ TJ = 125ºC
2.8
2.4
2.0
1.6
1.2
0.8
0.4
16
14
12
10
8
VGS = 20V
10V
VGS = 10V
9V
I D = 15A
8V
7V
I D = 7.5A
6
6V
5V
4
2
0
2
4
6
8
10
12
14
-50
-25
0
25
50
75
100
125
150
VDS - Volts
TJ - Degrees Centigrade
Fig. 5. RDS(on) Normalized to ID = 7.5A Value vs.
Drain Current
Fig. 6. Maximum Drain Current vs.
Case Temperature
3.0
2.6
2.2
1.8
1.4
1.0
0.6
16
14
12
10
8
VGS = 10V
TJ = 125ºC
6
TJ = 25ºC
4
2
0
5
10
15
20
25
30
35
-50
-25
0
25
50
75
100
125
150
ID - Amperes
TC - Degrees Centigrade
© 2011 IXYS CORPORATION, All Rights Reserved
IXTA15N50L2 IXTP15N50L2
IXTH15N50L2
Fig. 7. Input Admittance
Fig. 8. Transconductance
18
16
14
12
10
8
12
10
8
T
= - 40ºC
J
25ºC
125ºC
TJ = 125ºC
25ºC
- 40ºC
6
4
6
4
2
2
0
0
0
2
4
6
8
10
12
14
16
18
20
180
10
3.0
3.5
4.0
4.5
5.0
5.5
6.0
6.5
7.0
7.5
8.0
8.5
VGS - Volts
ID - Amperes
Fig. 9. Forward Voltage Drop of Intrinsic Diode
Fig. 10. Gate Charge
45
40
35
30
25
20
15
10
5
16
14
12
10
8
VDS = 250V
I D = 7.5A
I G = 10mA
6
TJ = 125ºC
4
TJ = 25ºC
2
0
0
0.5
0.6
0.7
0.8
0.9
1
0
20
40
60
80
100
120
140
160
VSD - Volts
QG - NanoCoulombs
Fig. 11. Capacitance
Fig. 12. Maximum Transient Thermal Impedance
10,000
1,000
100
1
C
C
iss
oss
0.1
C
rss
= 1 MHz
5
f
10
0.01
0
10
15
20
25
30
35
40
0.0001
0.001
0.01
0.1
1
Pulse Width - Seconds
VDS - Volts
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
IXTA15N50L2 IXTP15N50L2
IXTH15N50L2
Fig. 13. Forward-Bias Safe Operating Area
@ TC = 25ºC
Fig. 14. Forward-Bias Safe Operating Area
@ TC = 75ºC
100
10
1
100
10
1
RDS(on) Limit
R
Limit
DS(on)
25µs
25µs
100µs
100µs
1ms
1ms
10ms
100ms
10ms
TJ = 150ºC
C = 75ºC
Single Pulse
TJ = 150ºC
C = 25ºC
Single Pulse
DC
100ms
T
T
DC
0.1
0.1
10
100
1000
10
100
1000
VDS - Volts
VDS - Volts
© 2011 IXYS CORPORATION, All Rights Reserved
IXYS REF: T_15N50L2(6R)12-22-11-A
