PZTA28

型号:

PZTA28

描述:

NPN达林顿晶体管[ NPN Darlington Transistor ]

品牌:

FAIRCHILD[ FAIRCHILD SEMICONDUCTOR ]

页数:

4 页

PDF大小:

126 K

Discrete POWER & Signal
Technologies
MPSA28
MMBTA28
PZTA28
C
C
E
E
C
B
TO-92
C
B
SOT-23
Mark: 3SS
B
SOT-223
E
NPN Darlington Transistor
This device is designed for applications requiring extremely
high current gain at collector currents to 500 mA. Sourced
from Process 03.
Absolute Maximum Ratings*
TA = 25°C unless otherwise noted
Symbol
Parameter
Value
Units
VCES
VCBO
VEBO
IC
Collector-Emitter Voltage
Collector-Base Voltage
Emitter-Base Voltage
80
80
V
V
12
V
Collector Current - Continuous
800
mA
°C
Operating and Storage Junction Temperature Range
-55 to +150
TJ, Tstg
*These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.
NOTES:
1) These ratings are based on a maximum junction temperature of 150 degrees C.
2) These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.
Thermal Characteristics
TA = 25°C unless otherwise noted
Symbol
Characteristic
Max
Units
MPSA28
*MMBTA28
**PZTA28
PD
Total Device Dissipation
Derate above 25°C
Thermal Resistance, Junction to Case
625
5.0
83.3
350
2.8
1,000
8.0
mW
mW/°C
°C/W
Rθ
JC
Rθ
Thermal Resistance, Junction to Ambient
200
357
125
°C/W
JA
*Device mounted on FR-4 PCB 1.6" X 1.6" X 0.06."
**Device mounted on FR-4 PCB 36 mm X 18 mm X 1.5 mm; mounting pad for the collector lead min. 6 cm2.
1997 Fairchild Semiconductor Corporation
NPN Darlington Transistor
(continued)
Electrical Characteristics
TA = 25°C unless otherwise noted
Symbol
Parameter
Test Conditions
Min
Max
Units
OFF CHARACTERISTICS
V(BR)CES
V(BR)CBO
V(BR)EBO
ICBO
Collector-Emitter Breakdown Voltage
80
80
12
V
V
IC = 100 µA, VBE = 0
IC = 100 µA, IE = 0
IE = 10 µA, IC = 0
VCB = 60 V, IE = 0
VCE = 60 V, VBE = 0
VEB = 10 V, IC = 0
Collector-Base Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector Cutoff Current
V
100
500
100
nA
nA
nA
ICES
Collector Cutoff Current
IEBO
Emitter Cutoff Current
ON CHARACTERISTICS
hFE
DC Current Gain
IC = 10 mA, VCE = 5.0 V
IC = 100 mA, VCE = 5.0 V
IC = 10 mA, IB = 0.01 mA
IC = 100 mA, IB = 0.1 mA
IC = 100 mA, VCE = 5.0 V
10,000
10,000
Collector-Emitter Saturation Voltage
Base-Emitter On Voltage
1.2
1.5
2.0
V
V
VCE(sat)
VBE(on)
SMALL SIGNAL CHARACTERISTICS
Current Gain - Bandwidth Product
IC = 10 mA, VCE = 5.0,
f = 100 MHz
VCB = 1.0 V, IE = 0, f = 1.0 MHz
125
MHz
pF
fT
Output Capacitance
8.0
Cobo
*Pulse Test: Pulse Width 300 µs, Duty Cycle 2.0%
Typical Characteristics
Typical Pulsed Current Gain
Collector-Emitter Saturation
Voltage vs Collector Current
vs Collector Current
100
1.6
1.2
0.8
0.4
0
β
= 1000
VCE = 5V
125 °C
80
60
40
20
0
- 40 ºC
25 °C
25 ºC
125 ºC
- 40 °C
1
10
100
1000
0.001
0.01
IC - COLLECTOR CURRENT (A)
0.1
0.2
I C - COLLECTOR CURRENT (mA)
NPN Darlington Transistor
(continued)
Typical Characteristics (continued)
Base-Emitter Saturation
Voltage vs Collector Current
Base Emitter ON Voltage vs
Collector Current
2
2
1.6
1.2
0.8
0.4
0
β
= 1000
1.6
1.2
0.8
0.4
0
- 40 °C
- 40 ºC
25 °C
25 °C
125 ºC
125 °C
VCE= 5V
1
10
100
1000
1
10
100
1000
I C - COLLECTOR CURRENT (mA)
I C - COLLECTOR CURRENT (mA)
Collector-Emitter Breakdown
Voltage with Resistance
Between Emitter-Base
Collector-Cutoff Current
vs. Ambient Temperature
100
VCB = 80V
114.2
114
10
1
113.8
113.6
113.4
113.2
113
0.1
0.01
25
50
75
100
125
112.8
0.1
1
10
100
1000
TA- AMBIENT TEMPERATURE (º C)
RESISTANCE (k)
Input and Output Capacitance
vs Reverse Voltage
Gain Bandwidth Product
vs Collector Current
40
30
20
10
0
f = 1.0 MHz
20
15
V
= 5V
ce
C
ib
10
5
C
ob
2
0.1
1
10
100
1
10
20
50
100 150200
V
- COLLECTOR VOLTAGE(V)
ce
IC- COLLECTOR CURRENT (mA)
NPN Darlington Transistor
(continued)
Typical Characteristics (continued)
Power Dissipation vs
Ambient Temperature
1
0.75
0.5
SOT-223
TO-92
SOT-23
0.25
0
0
25
50
75
100
125
150
TEMPERATURE (oC)
