Switching frequency
Voltage drop
Current consumption
Delay first up
Delay response
Delay recovery
Setting-up
<= 500 Hz
1.5 V (closed state)
35 mA (no-load)
< 15 ms
< 1 ms
< 1 ms
Without sensitivity adjustment
0.71 in (18 mm)
1.81 in (46 mm)
Diameter
Length
Environment
Product certifications
CE
CSA
UL
Ambient air temperature for operation
Ambient air temperature for storage
Vibration resistance
-13...131 °F (-25...55 °C)
-40...158 °F (-40...70 °C)
7 gn, amplitude = +/- 1.5 mm (f = 10...55 Hz) conforming to IEC 60068-2-6
30 gn (duration = 11 ms) conforming to IEC 60068-2-27
Shock resistance
IP degree of protection
IP65 double insulation conforming to IEC 60529
IP67 double insulation conforming to IEC 60529
Ordering and shipping details
Category
22415 - SENSORS, PHOTOELECTRIC, BASIC
Discount Schedule
GTIN
DS2
003389110395570
Nbr. of units in pkg.
Package weight(Lbs)
Returnability
1
0.38
N
Country of origin
FR
Offer Sustainability
RoHS (date code: YYWW)
Compliant - since 0903 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
Product environmental profile
Product end of life instructions
California proposition 65
- - - - - - - Substance 1
Available
Available
WARNING: This product can expose you to chemicals including:
Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and
- - - - - - - Substance 2
Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other
reproductive harm.
- - - - - - - More information
For more information go to www.p65warnings.ca.gov
Contractual warranty
Warranty period
18 months
