IXTA2N100
IXTP2N100
Symbol
Test Conditions
Characteristic Values
TO-220 (IXTP) Outline
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 10V, ID = 0.5 • ID25, Note 1
1.5
2.5
S
Ciss
Coss
Crss
825
58
15
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
td(on)
tr
td(off)
tf
20
23
34
21
ns
ns
ns
ns
Resistive Switching Times
V
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 20Ω (External)
Qg(on)
Qgs
Qgd
18.0
3.7
8.2
nC
nC
nC
VGS= 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Pins: 1 - Gate
2 - Drain
RthJC
RthCS
1.25 °C/W
°C/W
(TO-220)
0.50
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C, Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
2
A
A
V
ISM
VSD
Repetitive, pulse width limited by TJM
IF = 2A, VGS = 0V, Note 1
IF = 2A, -di/dt = 100A/μs, VR = 100V
8
1.5
TO-263 (IXTA) Outline
trr
800
ns
Note 1: Pulse Test, t ≤ 300 μs; Duty Cycle, d ≤ 2%.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
