1 LED (yellow) output state
12...24 V DC with reverse polarity protection
10...30 V DC
[Us] rated supply voltage
Supply voltage limits
Switching capacity in mA
Switching frequency
Voltage drop
<= 100 mA (overload and short-circuit protection)
<= 500 Hz
<= 1.5 V (closed state)
<= 30 mA (no-load)
<= 15 ms
Current consumption
Delay first up
Delay response
Delay recovery
Setting-up
<= 1 ms
<= 1 ms
Without sensitivity adjustment
0.71 in (18 mm)
Diameter
Length
3.46 in (88 mm)
Product weight
Kit composition
0.19 lb(US) (0.085 kg)
Sensor
Reflector XUZC50
Environment
Product certifications
CE
CSA
UL
Ambient air temperature for operation
Ambient air temperature for storage
Vibration resistance
-13...131 °F (-25...55 °C)
-40...158 °F (-40...70 °C)
25 gn, amplitude = +/- 1.5 mm (f = 10...55 Hz) conforming to IEC 60068-2-6
30 gn (duration = 11 ms) conforming to IEC 60068-2-27
IP67 conforming to IEC 60529
Shock resistance
IP degree of protection
Ordering and shipping details
Category
22481 - SENSORS, PHOTOELECTRIC
Discount Schedule
GTIN
DS2
003389110853827
Nbr. of units in pkg.
Package weight(Lbs)
Returnability
1
0.35999999999999999
N
Country of origin
FR
Offer Sustainability
RoHS (date code: YYWW)
Will be compliant on 3Q2013
Will be compliant on 3Q2013
Product environmental profile
Product end of life instructions
California proposition 65
- - - - - - - Substance 1
Available
Available
WARNING: This product can expose you to chemicals including:
Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and
- - - - - - - Substance 2
Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other
reproductive harm.
- - - - - - - More information
For more information go to www.p65warnings.ca.gov
Contractual warranty
Warranty period
18 months
