Supply voltage limits
Residual current
Switching capacity in mA
Switching frequency
Voltage drop
10...30 V DC
< 1.5 mA (open state)
<= 100 mA (overload and short-circuit protection)
<= 500 Hz
<= 1.5 V (closed state)
<= 30 mA (no-load)
<= 15 ms
Current consumption
Delay first up
Delay response
Delay recovery
Setting-up
<= 1 ms
<= 1 ms
Without sensitivity adjustment
0.71 in (18 mm)
Diameter
Length
2.52 in (64 mm)
Product weight
Kit composition
0.34 lb(US) (0.155 kg)
Sensor
Reflector XUZC50
Environment
Product certifications
CE
CSA
UL
Ambient air temperature for operation
Ambient air temperature for storage
Vibration resistance
-13...131 °F (-25...55 °C)
-40...158 °F (-40...70 °C)
25 gn, amplitude = +/- 1.5 mm (f = 10...55 Hz) conforming to IEC 60068-2-6
30 gn (duration = 11 ms) conforming to IEC 60068-2-27
IP67 conforming to IEC 60529
Shock resistance
IP degree of protection
Ordering and shipping details
Category
22481 - SENSORS, PHOTOELECTRIC
Discount Schedule
GTIN
DS2
003389118388185
Nbr. of units in pkg.
Package weight(Lbs)
Returnability
1
0.40000000000000002
N
Country of origin
FR
Offer Sustainability
RoHS (date code: YYWW)
Compliant - since 0924 - Schneider Electric declaration of conformity
Schneider Electric declaration of conformity
REACh
Reference not containing SVHC above the threshold
Reference not containing SVHC above the threshold
California proposition 65
- - - - - - - Substance 1
- - - - - - - Substance 2
WARNING: This product can expose you to chemicals including:
Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and
Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other
reproductive harm.
- - - - - - - More information
For more information go to www.p65warnings.ca.gov
Contractual warranty
Warranty period
18 months
