IXTA08N120P
IXTP08N120P
Symbol
Test Conditions
Characteristic Values
Min. Typ. Max.
TO-220 (IXTP) Outline
(TJ = 25°C, unless otherwise specified)
gfs
VDS= 30V, ID = 0.5 • ID25, Note 1
0.38
0.63
S
Ciss
Coss
Crss
333
20
4.7
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
td(on)
tr
td(off)
tf
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 50Ω (External)
20
ns
26
55
24
ns
ns
ns
Qg(on)
Qgs
Qgd
14.0
2.0
8.2
nC
nC
nC
VGS= 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Pins: 1 - Gate
2 - Drain
RthJC
RthCS
2.5 °C/W
°C/W
(TO-220)
0.50
Source-Drain Diode
Characteristic Values
(TJ = 25°C, unless otherwise specified)
Symbol
IS
Test Conditions
Min.
Typ.
Max.
VGS = 0V
0.8 A
ISM
VSD
trr
Repetitive, pulse width limited by TJM
IF = IS, VGS = 0V, Note 1
2.4 A
1.5 V
ns
IF = 0.8A, -di/dt = 100A/μs,
900
TO-263 (IXTA) Outline
VR = 100V, VGS = 0V
Note 1: Pulse test, t ≤ 300 μs; duty cycle, d ≤ 2%.
IXYS reserves the right to change limits, test conditions, and dimensions.
IXYS MOSFETs and IGBTs are covered
by one or moreof the following U.S. patents: 4,850,072 5,017,508
4,881,106 5,034,796
4,835,592 4,931,844
5,049,961
5,063,307
5,187,117
5,237,481
5,381,025
5,486,715
6,162,665
6,259,123 B1
6,306,728 B1
6,404,065 B1 6,683,344
6,727,585
7,005,734 B2 7,157,338B2
7,063,975 B2
6,771,478 B2 7,071,537
6,534,343
6,583,505
6,710,405 B2 6,759,692
6,710,463
