IXTA2R4N120P IXTP2R4N120P
IXTH2R4N120P
Symbol
Test Conditions
Characteristic Values
TO-220 (IXTP) Outline
(TJ = 25°C, unless otherwise specified)
Min.
Typ.
Max
gfs
VDS= 20V, ID = 0.5 • ID25, Note 1
1.2
2.0
S
Ciss
Coss
Crss
1207
57
11.2
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
td(on)
tr
td(off)
tf
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 18Ω (External)
22
ns
25
70
32
ns
ns
ns
Qg(on)
Qgs
Qgd
37
6
20
nC
nC
nC
VGS= 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Pins: 1 - Gate
2 - Drain
RthJC
RthCS
1.0 °C/W
°C/W
(TO-220)
(TO-247)
0.50
0.21
°C/W
Source-Drain Diode
Characteristic Values
(TJ = 25°C, unless otherwise specified)
Symbol
IS
Test Conditions
Min.
Typ.
Max.
VGS = 0V
2.4 A
ISM
VSD
trr
Repetitive, pulse width limited by TJM
IF = IS, VGS = 0V, Note 1
7.2 A
1.5 V
TO-247 (IXTH) Outline
IF = 2.4A, -di/dt = 100A/μs,
VR = 100V, VGS = 0V
920
ns
∅ P
1
2
3
Note 1: Pulse test, t ≤ 300 μs; duty cycle, d ≤ 2%.
Terminals: 1 - Gate 2 - Drain
3 - Source
TO-263 (IXTA) Outline
Dim.
Millimeter
Min. Max.
Inches
Min.
Max.
A
A1
A2
4.7
2.2
2.2
5.3
2.54
2.6
.185
.087
.059
.209
.102
.098
b
b1
b2
1.0
1.65
2.87
1.4
2.13
3.12
.040
.065
.113
.055
.084
.123
C
D
E
.4
20.80
15.75
.8
21.46
16.26
.016
.819
.610
.031
.845
.640
e
L
L1
5.20
19.81
5.72
20.32
4.50
0.205 0.225
.780
.800
.177
∅P
Q
3.55
5.89
3.65
6.40
.140
0.232 0.252
.144
R
S
4.32
6.15 BSC
5.49
.170 .216
242 BSC
