FZCK07N6901/KS35A

型号:

FZCK07N6901/KS35A

品牌:

IVO[ BAUMER IVO GMBH & CO. KG ]

页数:

2 页

PDF大小:

75 K

Photoelectric sensors
Diffuse sensors with
intensity difference
FZCK 07
sample drawing
23,5
18
10,8
Teach-in
LED
4,6
13,4
9,2
3
8
* emitter axis
general data
type
sample picture
intensity difference
light source
pulsed red LED
20 ... 150 mm
sensing distanceTw
alignment / soiled lens indicator
light indicator
flashing light indicator
LED green
LED yellow
Teach-in
output indicator
sensitivity adjustment
wave length
660 nm
suppression of reciprocal influence
yes
electrical data
response time / release time
voltage supply range +Vs
current consumption max. (no load)
current consumption typ.
voltage drop Vd
< 0,5 ms
10 ... 30 VDC
25 mA
20 mA
< 1,8 VDC
light / dark operate
< 100 mA
yes
output function
output current
short circuit protection
reverse polarity protection
yes
mechanical data
width / diameter
height / length
depth
8 mm
16,2 mm
10,8 mm
rectangular
type
housing material
front (optics)
plastic (PMMA, MABS, PA)
PMMA
ambient conditions
operating temperature
protection class
-20 ... +50 °C
IP 65
1
19/11/2013
www.baumer.com
Photoelectric sensors
Diffuse sensors with
intensity difference
FZCK 07
order reference
connection types
output circuit
NPN
FZCK 07N6901
cable rear side, 2 m
FZCK 07N6901/KS35A
FZCK 07P6901
flylead connector M8 4 pin, L=200 mm
cable rear side, 2 m
NPN
PNP
FZCK 07P6901/KS35A
flylead connector M8 4 pin, L=200 mm
PNP
2
19/11/2013
www.baumer.com
