SCAS745A − DECEMBER 2003 − REVISED APRIL 2004

D

Controlled Baseline

− One Assembly/Test Site, One Fabrication

Site

D

Include D-Type Flip-Flops and Control

Circuitry to Provide Multiplexed

Transmission of Stored and Real-Time Data

Enhanced Diminishing Manufacturing

Sources (DMS) Support

Bus Hold on Data Inputs Eliminates the

Need for External Pullup/Pulldown

Resistors

Enhanced Product-Change Notification

B-Port Outputs of SN74LVTH182646A

Devices Have Equivalent 25-Ω Series

Resistors, So No External Resistors Are

Required

†

Qualification Pedigree

Members of the Texas Instruments

SCOPE  Family of Testability Products

Members of the Texas Instruments

Widebus Family

State-of-the-Art 3.3-V ABT Design Supports

Mixed-Mode Signal Operation (5-V Input

and Output Voltages With 3.3-V V

D

Compatible With IEEE Std 1149.1-1990

(JTAG) Test Access Port and

Boundary-Scan Architecture

SCOPE Instruction Set

)

CC

− IEEE Std 1149.1-1990 Required

Instructions and Optional CLAMP and

HIGHZ

D

Support Unregulated Battery Operation

Down to 2.7 V

†

Component qualification in accordance with JEDEC and industry

standards to ensure reliable operation over an extended

temperature range. This includes, but is not limited to, Highly

Accelerated Stress Test (HAST) or biased 85/85, temperature

cycle, autoclave or unbiased HAST, electromigration, bond

intermetallic life, and mold compound life. Such qualification

testing should not be viewed as justifying use of this component

beyond specified performance and environmental limits.

− Parallel-Signature Analysis at Inputs

− Pseudorandom Pattern Generation From

Outputs

− Sample Inputs/Toggle Outputs

− Binary Count From Outputs

− Device Identification

− Even-Parity Opcodes

description/ordering information

The SN74LVTH18646A and SN74LVTH182646A scan test devices, with 18-bit bus transceivers and registers,

are members of the Texas Instruments (TI) SCOPE testability integrated-circuit family. This family of devices

supports IEEE Std 1149.1-1990 boundary scan to facilitate testing of complex circuit board assemblies. Scan

access to the test circuitry is accomplished via the 4-wire test access port (TAP) interface.

Additionally, these devices are designed specifically for low-voltage (3.3-V) V

capability to provide a TTL interface to a 5-V system environment.

operation, but with the

CC

In the normal mode, these devices are 18-bit bus transceivers and registers that allow for multiplexed

transmission of data directly from the input bus or from the internal registers. They can be used either as two

9-bit transceivers or one 18-bit transceiver. The test circuitry can be activated by the TAP to take snapshot

samples of the data appearing at the device pins or to perform a self test on the boundary-test cells. Activating

the TAP in the normal mode does not affect the functional operation of the SCOPE bus transceivers

and registers.

ORDERING INFORMATION

ORDERABLE

PART NUMBER

TOP-SIDE

MARKING

‡

T

A

PACKAGE

LQFP − PM

Tape and reel

8V18646AIPMREP

LH18646AEP
