IXTP270N04T4
IXTH270N04T4
Symbol
Test Conditions
Characteristic Values
Min. Typ. Max.
(TJ = 25C, Unless Otherwise Specified)
gfs
VDS = 10V, ID = 60A, Note 1
Gate Input Resistance
90
150
1.4
S
RGi
Ciss
Coss
Crss
9140
1450
980
pF
pF
pF
VGS = 0V, VDS = 25V, f = 1MHz
td(on)
tr
td(off)
tf
18
28
72
23
ns
ns
ns
ns
Resistive Switching Times
VGS = 10V, VDS = 0.5 • VDSS, ID = 135A
RG = 2 (External)
Qg(on)
Qgs
182
45
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
67
RthJC
RthCS
0.40 C/W
C/W
TO-220
TO-247
0.50
0.21
C/W
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min. Typ.
Max.
IS
VGS = 0V
270
A
A
V
ISM
VSD
Repetitive, Pulse width limited by TJM
IF = 100A, VGS = 0V, Note 1
1080
1.4
trr
48
1.8
43
ns
A
IF = 150A, VGS = 0V
IRM
QRM
-di/dt = 100A/s
VR = 30V
nC
Notes: 1. Pulse test, t 300s, duty cycle, d 2%.
2. On through-hole packages, RDS(on) Kelvin test contact location must be 5mm
or less from the package body.
