IXTA05N100P
IXTP05N100P
Symbol
Test Conditions
Characteristic Values
TO-263 Outline
(TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
gfs
VDS = 30V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
0.24
0.40
S
Ciss
Coss
Crss
196
15
4
pF
pF
pF
td(on)
tr
td(off)
tf
6
15
20
15
ns
ns
ns
ns
Resistive Switching Times
V
GS = 10V, VDS = 50V, ID = 0.5 • ID25
RG = 30Ω (External)
Qg(on)
Qgs
8.1
0.7
4.2
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
RthJC
RthCS
2.5 °C/W
°C/W
TO-220
0.50
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25°C Unless Otherwise Specified)
Min.
Typ.
Max.
IS
VGS = 0V
0.5
A
A
TO-220 Outline
ISM
VSD
trr
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
2.0
1.2
V
IF = 0.5A, -di/dt = 100A/μs
750
ns
VR = 100V, VGS = 0V
Note
1. Pulse test, t ≤ 300μs, duty cycle, d ≤ 2%.
Pins: 1 - Gate
3 - Source
2 - Drain
PRELIMINARY TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from data gathered during objective characterizations of preliminary engineering lots; but also may yet
contain some information supplied during a pre-production design evaluation. IXYS reserves the right
to change limits, test conditions, and dimensions without notice.
