VUO 55
IdAVM = 58 A
VRRM = 1200-1800 V
Three Phase
Rectifier Bridge
+
–
+
-
VRSM
V
VRRM
V
Type
~
~
~
1200
1400
1600
1800
1200
1400
1600
1800
VUO 55-12NO7
VUO 55-14NO7
VUO 55-16NO7
VUO 55-18NO7*
~
~
~
* delivery time on request
Symbol
Test Conditions
Maximum Ratings
Features
●
Package with screw terminals
Isolation voltage 3000 V~
Planar passivated chips
Blocking voltage up to 1800 V
IdAVM
IFSM
TC = 85°C, module
58
A
●
●
TVJ = 45°C;
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
750
820
A
A
●
●
Low forward voltage drop
T
VJ = TVJM
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
670
740
A
A
●
UL registered E 72873
VR = 0
I2t
TVJ = 45°C
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
2800
2820
A2s
A2s
A2s
A2s
Applications
●
Supplies for DC power equipment
Input rectifiers for PWM inverter
Battery DC power supplies
Field supply for DC motors
TVJ = TVJM
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
2250
2300
●
●
●
TVJ
TVJM
Tstg
-40...+150
150
-40...+150
°C
°C
°C
Advantages
●
Easy to mount with two screws
Space and weight savings
Improved temperature and power
VISOL
50/60 Hz, RMS
IISOL £ 1 mA
t = 1 min
t = 1 s
2500
3000
V~
V~
●
●
Md
Mounting torque (M5)
5 ± 15 %
Nm
cycling
44 ± 15 % lb.in.
3 ± 15 % Nm
26 ± 15 % lb.in.
Terminal connection torque (M5)
typ.
Dimensions in mm (1 mm = 0.0394")
Weight
260
g
Symbol
IR
Test Conditions
Characteristic Values
VR = VRRM
;
;
TVJ = 25°C
TVJ = TVJM
£
£
0.3
10.0
mA
mA
VR = VRRM
VF
IF = 150 A;
TVJ = 25°C
£
1.6
V
VT0
rT
For power-loss calculations only
0.85
8
V
mW
RthJC
per diode; DC current
per module
per diode; DC current
per module
2.7
0.45
3.06
0.51
K/W
K/W
K/W
K/W
RthJH
Data according to IEC 60747 and refer to a single diode unless otherwise stated.
IXYS reserves the right to change limits, test conditions and dimensions.
© 2000 IXYS All rights reserved
1 - 2
