Applications
OV2680/OV2685
¬
¬
¬
¬
Ultrabooks
¬
¬
¬
Cellular and Picture Phones
PC Multimedia
Games
Tablets
Toys
Ordering Information
Home Entertainment
¬
OV02680-H47A
(color, lead-free, 47-pin CSP5)
¬
OV02685-H53A
(color, lead-free, 53-pin CSP5)
Product Features
¬
MIPI and D-PHY specification (contains
one clock lane) with a maximum of
750 Mbps data transfer rate
¬
¬
¬
high sensitivity and low dark current
for low-light conditions
Product Specifications
supports free-running clock and
gated clock
¬
active array size: 1616 x 1216
¬
¬
¬
¬
¬
¬
lens size: 1/5"
¬
support for output formats:
- OV2680: 10-bit RAW RGB
¬
power supply:
lens chief ray angle: 28.5° non-linear
input clock frequency: 6 ~ 27 MHz
maximum image transfer rate: 30 fps
scan mode: progressive
- OV2685: 10-bit RAW RGB, 8-bit YUV
supports down-sampling
and binning mode
- OV2680 core: 1.58V ±3%
- OV2685 core: 1.7 ~ 1.9V
- analog: 2.6 ~ 3.0V
- I/O: 1.7 ~ 3.0V
¬
¬
programmable controls for frame rate,
mirror and flip, cropping, and windowing
¬
¬
¬
auto black level calibration
defect correction capability
low operating voltage and low power
consumption for embedded portable
applications
¬
¬
power requirements:
- OV2680 active: 123 mW
- OV2685 active: 259 mW
- XSHUTDN: <1 µA
supports horizontal and
vertical subsampling
maximum exposure interval:
1 frame - 4 tROW
¬
supports global analog gain
temperature range:
¬
¬
¬
pixel size: 1.75 µm x 1.75 µm
- operating: -30°C to +85°C junction
temperature
image area: 2840 µm x 2150 µm
- stable image: 0°C to +50°C junction
temperature
package/die dimensions:
- OV2680 CSP5: 4180 µm x 3480 µm
- OV2685 CSP5: 4454 µm x 4014 µm
¬
output formats: 10-bit RGB RAW,
8-bit YUV (OV2685)
Functional Block Diagram
OV2680/OV2685
image sensor core
sensor
processor
image output
interface
column
sample/hold
array
10-bit
ADC
AMP
MIPI
gain control
control register bank
SCCB slave interface
PLL
timing generator and system control logic
