Applications
OV02K10
¬ Mobile Smartphones
¬ Action / IoT cameras
¬ Dual Cameras
Ordering Information
¬
OV02K10-GA5A-Z
(color, chip probing, 150 µm backgrinding, reconstructed wafer with good die)
Product Features
¬ support for image size:
- 1920 x 1080
¬ SCCB for register programming
¬ programmable GPIOs
- VGA
- QVGA, and any cropped size
¬ high speed serial data transfer with
MIPI CSI-2 or LVDS
Product Specifications
¬ high dynamic range
¬ high sensitivity
¬ external frame synchronization
capability
¬
active array size: 1920 x 1080
¬
output formats:
- linear output
¬ programmable conversion gain
¬
power supply:
- analog: 2.8V
- digital: 1.1V
- I/O pads: 1.8V
- dual exposure HDR (long and short)
- 3-exposure HDR
(long, short, and very short)
- conversion gain programmable
in each channel
¬ embedded temperature sensor
¬ image sensor processor functions:
- defective pixel cancelation
- automatic black level correction, etc.
¬ one time programmable (OTP) memory
¬
¬
temperature range:
- operating: -30°C to +85°C junction
temperature
¬ pixel data: 12b RAW RGB
¬
maximum image transfer rate:
- 40X3 fps @ 1080p in 10-bit
- 30X3 fps @ 1080p in 12-bit
output interfaces: up to 4-lane MIPI
CSI-2 or LVDS
-
¬
¬
sensitivity: 32,000 e /Lux-sec (green
pixel response at 530 nm illumination)
¬
¬
¬
¬
¬
¬
input clock frequency: 6 ~ 36 MHz
lens size: 1/2.8"
dynamic range: >120 dB
3-exposure staggered HDR
lens chief ray angle: 35.5°
SCCB speed: up to 1 MHz
scan mode: progressive
shutter: rolling shutter
¬
¬
¬
pixel size: 2.9 µm x 2.9 µm
image array area: 5614.4 µm x 3178.4 µm
die dimensions:
- COB: 6708 µm x 4188 µm
- RW: 6758 µm x 4238 µm
Functional Block Diagram
OV02K10
image sensor core
sensor
processor
interface
column
sample/hold
MCP/N
MDP/N[3:0]
AMP
12-bit
ADC
array
temperature
sensor
gain
control
control register bank
SCCB interface
PLLs PLL
timing generator and system control logic
