QPA1008

型号：

QPA1008

品牌：

TRIQUINT[ TRIQUINT SEMICONDUCTOR ]

页数：

19 页

PDF大小：

1092 K

下载PDF手册
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Product Description
Qorvo's QPA1008 is an S-band two stage variable gain
driver amplifier in a 5x5 mm QFN. The QPA1008 operates
from 2.7 to 3.8 GHz and provides 31dBm of P1dB output
power with 26 dB of large signal gain and greater than
30% PAE. The QPA1008 includes a 30 dB attenuator at
the input, and a simple resistively coupled (~-20 dB
coupling) power sampler detector at the output. The
amplifier has a fast bias control switch for quick turn on
and off operation.
Product Features
Frequency Range: 2.7 – 3.8 GHz
Small Signal Gain: 28 dB
Input Return Loss: 16 dB
Output Return Loss: 15 dB
32dB Attenuation Range
P1dB: 31dBm
Lead-free and RoHS compliant.
Evaluation Boards are available upon request.
Large Signal Gain: 26 dB
P1dB PAE: 35 %
Bias Switching Speed: 20 nS
Bias: VCC = 6 V, ICQ = 400 mA
Package Dimensions: 5.0 x 5.0 x 0.82 mm
Performance is typical across frequency. Please
reference electrical specification table and data plots for
more details.
Functional Block Diagram
Applications
Commercial & Military Radar
Communications
Test Instrumentation
Ordering Information
Part
QPA1008
ECCN Description
2.7 – 3.8 GHz Driver
EAR99
Amplifier
QPA1008EVB01
Evaluation Board
- 1 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Recommended Operating Conditions
Absolute Maximum Ratings
Parameter
Collector Voltage (VCC)
Collector Current (ICC)
Dissipated Power (PDISS), TBASE = 85 °C,
TCH = 175 °C, CW
Valueꢀ/ꢀRange
3.3 V - 7 V
1.2 A
Parameter
Value
6 V
400 mA
1 A
Collector Voltage (VCC)
Collector Current (quiescent, ICQ
)
Collector Current (under drive, ICD)
VPD
3.2 W
5 V
VSW
TJ Max
5 V
165 °C
−40 to 85ꢀ°C
Input Power (50 Ω, 85 °C)
29 dBm
Channel Temperature, TCH
Mounting Temperature (30 seconds)
Storage Temperature
175 °C
260 °C
−55 to 150 °C
Operating Temperature Range
Electrical specifications are measured at specified test
conditions. Specifications are not guaranteed over all
recommended operating conditions.
Operation of this device outside the parameter ranges given above
may cause permanent damage. These are stress ratings only, and
functional operation of the device at these conditions is not implied.
Electrical Specifications
Test conditions, unless otherwise noted: 25 °C, VCC = 6 V, ICQ = 400 mA, VPD = 5 V, VSW = 5 V, CW
Parameter
Min
Typical
3.3
Max
Units
GHz
dBm
%
Operating Frequency Range
Output Power @ 1dB Compression (P1dB)
Power Added Efficiency @ 1dB Compression (P1dB)
Small Signal Gain
2.7
3.8
30.8
34.6
28
dB
Input Return Loss
16
dB
Output Return Loss
15
dB
OIP3 (POUT/tone ≤ 22 dBm)
IM3 (POUT/tone ≤ 22 dBm)
42
dBm
dBc
dB
-37
32
Gain Control Range
Switching Speed
20
nS
Attenuator / Switch Control (VSW) Voltage Range
Small Signal Temperature Coefficient
Output Power Temperature Coefficient
0
5
V
0.031
0.004
dB/°C
dB/°C
- 2 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Performance Plotsꢀ–ꢀSmall Signal
Test conditions unless otherwise noted: Temp. = 25 °C, VCC = 6 V, ICQ = 400 mA, VPD = 5 V, VSW = 5 V, CW
Gain vs. Frequency vs. Temperature
Input Return Loss vs. Freq. vs. Temp.
35
30
25
20
15
10
5
0
-5
VCC = 6 V, ICD = 400 mA
-10
-15
-20
-25
-30
-40C
+25C
+85C
-40C
+25C
3.5
+85C
4
VCC = 6 V, ICD = 400 mA
0
2
2.5
3
3.5
4
4.5
5
2
2.5
3
4.5
5
Frequency (GHz)
Frequency (GHz)
Output Return Loss vs. Freq. vs. Temp.
0
-5
-10
-15
-20
-25
-40C
+25C
+85C
VCC = 6 V, ICD = 400 mA
3.5
-30
2
2.5
3
4
4.5
5
Frequency (GHz)
- 3 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Performance Plotsꢀ–ꢀLarge Signal
Test conditions unless otherwise noted: Temp. = 25 °C, VCC = 6 V, ICQ = 400 mA, VPD = 5 V, VSW = 5 V, CW
P1dB (PAE) vs. Frequency vs. Temp.
P1dB vs. Frequency vs. Temp.
35
34
33
32
31
30
29
28
27
26
45
40
35
30
25
20
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
- 40C
+25C
+85C
3.5
- 40C
+25C
+85C
3.5
2.5
2.7
2.9
3.1
3.3
3.7
3.9
2.5
2.7
2.9
3.1
3.3
3.7
3.9
Frequency (GHz)
Frequency (GHz)
PAE vs. POUT vs. Temp.
Gain/POUT vs. PIN vs. Temp.
37
35
33
31
29
27
25
23
21
19
17
15
50
40
30
20
10
0
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
Freq. = 2.7 GHz
-40C
Freq. = 2.7 GHz
+25C
+85C
Pout -40C
Pout +25C
Pout +85C
Gain -40C
Gain +25C
Gain +85C
-10
-8
-6
-4
-2
0
2
4
6
8
10
15
19
23
27
31
35
PIN (dBm)
POUT (dBm)
Collector Current vs. PIN vs. Temp.
900
VCC = 6 V, ICQ = 400 mA
800
700
600
500
400
300
200
Freq. = 2.7 GHz
-40C
+25C
0
+85C
4
-10
-8
-6
-4
-2
2
6
8
10
PIN (dBm)
- 4 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Performance Plotsꢀ–ꢀLarge Signal
Test conditions unless otherwise noted: Temp. = 25 °C, VCC = 6 V, ICQ = 400 mA, VPD = 5 V, VSW = 5 V, CW
PAE vs. POUT vs. Temp.
Gain/POUT vs. PIN vs. Temp.
37
35
33
31
29
27
25
23
21
19
17
15
50
40
30
20
10
0
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
Freq. = 2.9 GHz
-40C
Freq. = 2.9 GHz
+25C
+85C
Pout -40C
Pout +25C
Pout +85C
Gain -40C
Gain +25C
Gain +85C
-10
-8
-6
-4
-2
0
2
4
6
8
10
15
19
23
27
31
35
PIN (dBm)
POUT (dBm)
Collector Current vs. PIN vs. Temp.
900
VCC = 6 V, ICQ = 400 mA
800
700
600
500
400
300
200
Freq. = 2.9 GHz
-40C
+25C
0
+85C
4
-10
-8
-6
-4
-2
2
6
8
10
PIN (dBm)
PAE vs. POUT vs. Temp.
Gain/POUT vs. PIN vs. Temp.
35
33
31
29
27
25
23
21
19
17
15
13
50
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
Freq. = 3.3 GHz
Freq. = 3.3 GHz
-40C
40
30
20
10
0
+25C
+85C
Pout -40C
Pout +25C
Pout +85C
Gain -40C
Gain +25C
Gain +85C
-10
-8
-6
-4
-2
0
2
4
6
8
10
15
19
23
27
31
35
PIN (dBm)
POUT (dBm)
- 5 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Performance Plotsꢀ–ꢀLarge Signal
Test conditions unless otherwise noted: Temp. = 25 °C, VCC = 6 V, ICQ = 400 mA, VPD = 5 V, VSW = 5 V, CW
Collector Current vs. PIN vs. Temp.
900
VCC = 6 V, ICQ = 400 mA
800
Freq. = 3.3 GHz
700
600
500
400
-40C
+25C
0
+85C
4
300
200
-10
-8
-6
-4
-2
2
6
8
10
PIN (dBm)
PAE vs. POUT vs. Temp.
Gain/POUT vs. PIN vs. Temp.
35
33
31
29
27
25
23
21
19
17
15
13
50
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
Freq. = 3.5 GHz
-40C
Freq. = 3.5 GHz
40
30
20
10
0
+25C
+85C
Pout -40C
Pout +25C
Pout +85C
Gain -40C
Gain +25C
Gain +85C
-10
-8
-6
-4
-2
0
2
4
6
8
10
15
19
23
27
31
35
PIN (dBm)
POUT (dBm)
Collector Current vs. PIN vs. Temp.
900
800
700
600
500
400
300
200
VCC = 6 V, ICQ = 400 mA
Freq. = 3.5 GHz
-40C
+25C
0
+85C
4
-10
-8
-6
-4
-2
2
6
8
10
PIN (dBm)
- 6 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Performance Plotsꢀ–ꢀLarge Signal
Test conditions unless otherwise noted: Temp. = 25 °C VCC = 6 V, ICQ = 400 mA, VPD = 5 V, VSW = 5 V, CW
Gain/POUT vs. PIN vs. Temp.
PAE vs. POUT vs. Temp.
35
33
31
29
27
25
23
21
19
17
15
13
50
40
30
20
10
0
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
Freq. = 3.8 GHz
Freq. = 3.8 GHz
-40C
+25C
+85C
Pout -40C
Pout +25C
Pout +85C
Gain -40C
Gain +25C
Gain +85C
-10
-8
-6
-4
-2
0
2
4
6
8
10
15
19
23
27
31
35
PIN (dBm)
POUT (dBm)
Collector Current vs. PIN vs. Temp.
900
VCC = 6 V, ICQ = 400 mA
800
700
600
500
400
300
200
Freq. = 3.8 GHz
-40C
+25C
0
+85C
4
-10
-8
-6
-4
-2
2
6
8
10
PIN (dBm)
PDET vs. POUT vs. Frequency
Coupling Factor (CF) vs. POUT vs. Freq.
18
14
10
6
25
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
20
15
10
5
2.7 GHz
2.9 GHz
3.3 GHz
3.5 GHz
3.8 GHz
2.7 GHz
2.9 GHz
3.3 GHz
3.5 GHz
3.8 GHz
2
-2
-6
Temp. = 25˚C
CF = POUT - PDET
Temp. = 25˚C
15
19
23
27
31
35
15
19
23
27
31
35
POUT (dBm)
POUT (dBm)
- 7 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Performance Plotsꢀ–ꢀLarge Signal
Test conditions unless otherwise noted: Temp. = 25 °C, VCC = 6 V, ICQ = 400 mA, VPD = 5 V, VSW = 5 V, CW
PDET vs. POUT vs. Frequency
Coupling Factor (CF) vs. POUT vs. Freq.
18
14
10
6
25
20
15
10
5
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
2.7 GHz
2.9 GHz
3.3 GHz
3.5 GHz
3.8 GHz
2.7 GHz
2.9 GHz
3.3 GHz
3.5 GHz
3.8 GHz
2
-2
-6
Temp. = 85˚C
CF = POUT - PDET
Temp. = 85˚C
15
19
23
27
31
35
15
19
23
27
31
35
POUT (dBm)
POUT (dBm)
PDET vs. POUT vs. Frequency
Coupling Factor (CF) vs. POUT vs. Freq.
18
14
10
6
25
20
15
10
5
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
2.7 GHz
2.9 GHz
3.3 GHz
3.5 GHz
3.8 GHz
2
2.7 GHz
2.9 GHz
3.3 GHz
3.5 GHz
3.8 GHz
-2
-6
Temp. = -40˚C
CF = POUT - PDET
Temp. = -40˚C
15
19
23
27
31
35
15
19
23
27
31
35
POUT (dBm)
POUT (dBm)
- 8 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Performance Plotsꢀ–ꢀLinearity
Test conditions unless otherwise noted: Temp. = 25 °C, VCC = 6 V, ICQ = 400 mA, VPD = 5 V, VSW = 5 V, CW
OIP3 vs. POUT vs. Temp.
OIP3 vs. POUT vs. Temp.
48
47
46
45
44
43
42
41
40
39
38
48
47
46
45
44
43
42
41
40
39
38
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
Freq. = 2.9 GHz, ∆f = 1 MHz
Freq. = 2.7 GHz, ∆f = 1 MHz
-40C
+25C
+85C
-40C
+25C
+85C
12
14
16
18
20
22
24
26
12
14
16
18
20
22
24
26
POUT per Tone (dBm)
POUT per Tone (dBm)
OIP3 vs. POUT vs. Temp.
48
47
VCC = 6 V, ICQ = 400 mA
Freq. = 3.3 GHz, ∆f = 1 MHz
46
45
44
43
42
41
40
39
38
-40C
+25C
+85C
12
14
16
18
20
22
24
26
POUT per Tone (dBm)
OIP3 vs. POUT vs. Temp.
OIP3 vs. POUT vs. Temp.
48
47
46
45
44
43
42
41
40
39
38
60
55
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
Freq. = 3.8 GHz, ∆f = 1 MHz
50
45
40
35
30
-40C
+25C
+85C
-40C
+25C
+85C
Freq. = 3.5 GHz, ∆f = 1 MHz
12
14
16
18
20
22
24
26
12
14
16
18
20
22
24
26
POUT per Tone (dBm)
POUT per Tone (dBm)
- 9 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Performance Plotsꢀ–ꢀLinearity
Test conditions unless otherwise noted: Temp. = 25 °C, VCC = 6 V, ICQ = 400 mA, VPD = 5 V, VSW = 5 V, CW
IM3 vs. POUT vs. Temp.
IM3 vs. POUT vs. Temp.
-30
-35
-40
-45
-50
-55
-60
-65
-70
-30
-35
-40
-45
-50
-55
-60
-65
-70
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
Freq. = 2.9 GHz, ∆f = 1 MHz
Freq. = 2.7 GHz, ∆f = 1 MHz
-40C
+25C
+85C
-40C
+25C
+85C
12
14
16
18
20
22
24
26
12
14
16
18
20
22
24
26
POUT per Tone (dBm)
POUT per Tone (dBm)
IM3 vs. POUT vs. Temp.
-30
-35
VCC = 6 V, ICQ = 400 mA
Freq. = 3.3 GHz, ∆f = 1 MHz
-40
-45
-50
-55
-60
-65
-70
-40C
+25C
+85C
12
14
16
18
20
22
24
26
POUT per Tone (dBm)
IM3 vs. POUT vs. Temp.
IM3 vs. POUT vs. Temp.
-30
-35
-40
-45
-50
-55
-60
-65
-70
-30
-35
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
Freq. = 3.5 GHz, ∆f = 1 MHz
Freq. = 3.8 GHz, ∆f = 1 MHz
-40
-45
-50
-55
-60
-65
-70
-40C
+25C
+85C
-40C
14
+25C
+85C
12
14
16
18
20
22
24
26
12
16
18
20
22
24
26
POUT per Tone (dBm)
POUT per Tone (dBm)
- 10 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Performance Plotsꢀ–ꢀAttenuation
Test conditions unless otherwise noted: Temp. = 25 °C, VCC = 6 V, ICQ = 400 mA, VPD = 5 V, VSW = 5 V, CW
Gain vs. VSW vs. Temp.
Gain vs. VSW vs. Temp.
35
30
25
20
15
10
5
35
30
25
20
15
10
5
Freq. = 2.7 GHz
Freq. = 2.9 GHz
-40C
+25C
+85C
-40C
+25C
+85C
0
0
PIN = -10 dBm
PIN = -10 dBm
-5
-5
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
-10
-10
0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0
VSW (V)
0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0
VSW (V)
Gain vs. VSW vs. Temp.
35
30
25
20
15
10
5
Freq. = 3.3 GHz
-40C
+25C
+85C
0
PIN = -10 dBm
-5
VCC = 6 V, ICQ = 400 mA
-10
0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0
VSW (V)
Gain vs. VSW vs. Temp.
Gain vs. VSW vs. Temp.
35
30
25
20
15
10
5
35
30
25
20
15
10
5
Freq. = 3.5 GHz
Freq. = 3.8 GHz
-40C
+25C
+85C
-40C
+25C
+85C
0
0
PIN = -10 dBm
PIN = -10 dBm
-5
-5
VCC = 6 V, ICQ = 400 mA
VCC = 6 V, ICQ = 400 mA
-10
-10
0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0
VSW (V)
0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0
VSW (V)
- 11 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Thermal and Reliability Information
Parameter
Test Conditions
Tbase = 85°C, Tcase =94°C
VCC = 6 V, ICQ = 395 mA,
VPD = 5V IPD = 13 mA PDISS = 2.44 W
Value
29.1
Units
°C/W
°C
Thermal Resistance (θJC) (1)
Channel Temperature (TCH) (Quiescent)
Median Lifetime (TM)
165
>8E+7
26.1
Hrs
Thermal Resistance (θJC) (1)
°C/W
Tbase = 85°C, Tcase =97°C Freq = 3.8 GHz,
VCC = 6 V, ICC = 589 mA,
Channel Temperature (TCH) (Under RF drive)
163
°C
VPD = 5V IPD = 13 mA
PIN = 4 dBm, POUT = 30.3 dBm, PDISS = 2.53 W
Median Lifetime (TM)
Notes:
>8E+7
Hrs
1. Thermal resistance measured to back of EVB.
Median Lifetime
Test Conditions: VCC = +5ꢀV, Jc=19.5kA/cm2 Failure Criteria = 20ꢀ% change in Beta for HBT Technology
- 12 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Applications Circuit
Bias Up Procedure
1. Set ICC limit to 1A
Bias Down Procedure
1. RF off signal
2. Set VCC to 6 V
2. Turn Off VPD
3. Set VPD to 5 V (Switched bias input)
3. Turn Off VSW
4. Apply VSW
:
4. Turn Off VCC
VSW = 0 V (Maximum Attenuation)
VSW = 5 V (Minimum Attenuation)
5. Apply RF signal
- 13 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Evaluation Board
Qorvo PCB Material and Stack-Up
Notes:
If operating near PSAT, 20 dB (>3W) attenuation pad is recommended at the output of the device to protect test equipment.
For this EVB, the Attenuation control is reversed compared to the design requirements and the final production product.
Bill of Materials
Ref. Des.
U1
C2, C3, L1, R1
C4, C6, C9
C5, C7, C8
C13
Value
Description
Manufacturer Part Number
QPA1008
Various
Various
Various
Various
Various
Various
Various
0 Ω
RES, 0603, 1/16 W, Chip
CAP, 0603, 5%, 50 V
CAP, 0603, 5%, 50 V
CAP, 0603, 10%, 50 V, X7R
CAP, 6032, 20%, 50 V, Tantalum
IND, 0603 5%, 4800 MHz
100 pF
1000 pF
0.1 uF
10 uF
C14
L2
10 nH
- 14 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
PCB Mounting Pattern
Recommended PCB land-pad pattern metallization (Top View)
- 15 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Mechanical Information
Units: millimeters
Tolerances: unless specified
x.xx = ± 0.25
x.xxx = ± 0.100
Materials:
Base: Laminate
All metalized features are gold plated
Marking:
QPA1008: Part number
YY: Part Assembly year
WW: Part Assembly week
MXXX: Batch ID
- 16 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Pad Description
Bottom view of package base
Pin Number
1-3, 5-9, 11, 13, 15-17, 19-
21, 23-25, 27-28
Label
Description
No internal connection. Pads on PCB should be grounded to
improve isolation
No Connect
4
RF Input
VSW
RF input, matched to 50 Ω, DC blocked
Attenuator Switch Control
10
12
VPD
Bias Switch Control
Power Detector, coupled output power (resistive coupler;
approximately 20 dB below output power)
14
Power Sample
18
22
26
RF Output
VCC2
RF output, matched to 50 Ω, DC blocked
Second stage supply voltage. Bias network required
First stage supply voltage. Bias network required
VCC1
Ground paddle; must be grounded using plated through/copper filled
via holes on PCB to improve isolation and for heat sinking
29
GND
- 17 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Recommended Soldering Temperature Profile
- 18 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
QPA1008
2.7ꢀ–ꢀ3.8 GHz Variable Gain Driver Amplifier
Handling Precautions
Parameter
Rating
Class 1C
Class C3
3
Standard
ESDꢀ–ꢀHuman Body Model (HBM)
ESDꢀ–ꢀCharge Device Model (CDM)
MSLꢀ–ꢀMoisture Sensitivity Level
ANSI/ESD/JEDEC JS-001
ANSI/ESD/JEDEC JS-002
IPC/JEDEC J-STD-020
Caution!
ESD-Sensitive Device
Solderability
Compatible with the latest version of J-STD-020 Lead free solder, 260 °C.
Solder profiles available upon request.
RoHS Compliance
This product is compliant with the 2011/65/EU RoHS directive (Restrictions on the Use of Certain Hazardous Substances
in Electrical and Electronic Equipment), as amended by Directive 2015/863/EU. This product also has the following
attributes:
Lead Free
Halogen Free (Chlorine, Bromine)
Antimony Free
TBBP-A (C15H12Br402) Free
PFOS Free
SVHC Free
Qorvo Green
Pb
Contact Information
For the latest specifications, additional product information, worldwide sales and distribution locations:
Tel: 1-844-890-8163
Web: www.qorvo.com
Email: customer.support@qorvo.com
For technical questions and application information: Email: appsupport@qorvo.com
Important Notice
The information contained herein is believed to be reliable; however, Qorvo makes no warranties regarding the information contained
herein and assumes no responsibility or liability whatsoever for the use of the information contained herein. All information contained
herein is subject to change without notice. Customers should obtain and verify the latest relevant information before placing orders for
Qorvo products. The information contained herein or any use of such information does not grant, explicitly or implicitly, to any party any
patent rights, licenses, or any other intellectual property rights, whether with regard to such information itself or anything described by
such information. THIS INFORMATION DOES NOT CONSTITUTE A WARRANTY WITH RESPECT TO THE PRODUCTS DESCRIBED
HEREIN, AND QORVO HEREBY DISCLAIMS ANY AND ALL WARRANTIES WITH RESPECT TO SUCH PRODUCTS WHETHER
EXPRESS OR IMPLIED BY LAW, COURSE OF DEALING, COURSE OF PERFORMANCE, USAGE OF TRADE OR OTHERWISE,
INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Without limiting the generality of the foregoing, Qorvo products are not warranted or authorized for use as critical components in medical,
life-saving, or life-sustaining applications, or other applications where a failure would reasonably be expected to cause severe personal
injury or death.
Copyright 2016 © Qorvo, Inc. | Qorvo is a registered trademark of Qorvo, Inc.
- 19 of 19 -
Data Sheet Rev. C, May 30 , 2017
www.qorvo.com
厂商 型号 描述 页数 下载

QORVO

 		QPA0363A [ DC – 5000 MHz Cascadable SiGe HBT Amplifier ] 7 页

QORVO

 		QPA0363APCK401 [ DC – 5000 MHz Cascadable SiGe HBT Amplifier ] 7 页

QORVO

 		QPA0363ASQ [ DC – 5000 MHz Cascadable SiGe HBT Amplifier ] 7 页

QORVO

 		QPA0363ASR [ DC – 5000 MHz Cascadable SiGe HBT Amplifier ] 7 页

QORVO

 		QPA0363ATR7 [ DC – 5000 MHz Cascadable SiGe HBT Amplifier ] 7 页

TRIQUINT

 		QPA1001 [ 3.1 – 3.5 GHz 60 Watt GaN Power Amplifier ] 15 页

QORVO

 		QPA1001 [ 3.1 – 3.5 GHz 60 Watt GaN Power Amplifier ] 17 页

TRIQUINT

 		QPA1001-EVB [ 3.1 – 3.5 GHz 60 Watt GaN Power Amplifier ] 15 页

QORVO

 		QPA1001EVB [ 3.1 – 3.5 GHz 60 Watt GaN Power Amplifier ] 17 页

QORVO

 		QPA1001TR7 [ 3.1 – 3.5 GHz 60 Watt GaN Power Amplifier ] 17 页

购物指南

支付方式

配送服务

售后服务

发票须知

优惠券使用规则

特色服务

PCBA制造

国产品牌推荐

国产料号替代

质量保证

技术资料

行业资讯

关于我们

关于壹壹捌

联系我们

联系我们

服务热线：400-618-9990

企业邮箱：sales@ic118.com

服务时间：周一至周六 8:30-17:30

壹壹捌官方微信号

PDF索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

IC型号索引：

A

B

C

D

E

F

G

H

I

J

K

L

M

N

O

P

Q

R

S

T

U

V

W

X

Y

Z

0

1

2

3

4

5

6

7

8

9

Copyright 2024 gkzhan.com Al Rights Reserved 京ICP备06008810号-21 京

深圳网络警察报警平台
公共信息安全网络监察
经营性网站备案信息
不良信息举报中心
工商网监电子标识
全国公安机关备案
0.251540s
