Applications
OV7261
¬
¬
¬
Occupant Detection
Driver Monitor
Vehicle Entry
¬
¬
Stereo Vision
Gesture Control
Ordering Information
¬
OV07261-N35Y-MA
¬
OV07261-N35Y-NA
(B&W, lead-free, 35-pin a-CSP™
packed in tray with protective film,
tab in top right direction)
(B&W, lead-free, 35-pin a-CSP™
packed in tape & reel with protective
film, tab in top right direction)
Product Features
¬
3 µm x 3 µm pixel with
¬
¬
¬
¬
supports 2x2 monochrome binning
one-lane MIPI serial output interface
one-lane LVDS serial output interface
OmniPixel3-GS™ technology
¬
¬
automatic black level calibration (ABLC)
programmable controls for frame rate,
mirror and flip, cropping and windowing
Product Specifications
embedded 256 bits of one-time
programmable (OTP) memory for
part identification
¬
active array size: 640 x 480
¬
¬
¬
¬
¬
input clock frequency: 6 ~ 27 MHz
lens chief ray angle: 29° non-linear
max S/N ratio: 38 dB
¬
¬
support output formats: 8/10-bit RAW
¬
power supply:
support for image sizes: 640x480,
320x240, 160x120
¬
¬
¬
¬
two on-chip phase lock loops (PLLs)
built-in 1.5V regulator for core
PWM
- core: 1.5V (optional)
- analog: 2.8V (nominal)
- I/O: 1.8V (nominal)
¬
¬
fast mode switching
dynamic range: 69.6 dB @ 8x gain
¬
power requirements:
supports horizontal and vertical 2:1 and
4:1 monochrome subsampling
- active: 117 mW (VGA @ 100 fps)
- standby: 15 µA for AVDD,
40 µA for DOVDD without input clock,
700 µA for DOVDD with input clock
- XSHUTDOWN: 5 µA for AVDD,
5 µA for DOVDD
maximum image transfer rate:
- 640x480: 100 fps
built-in strobe control
¬
sensitivity:
- 10,800 mV/(µW.cm-2.sec) @ 850 nm
¬
¬
¬
¬
scan mode: progressive
¬
¬
temperature range:
- operating: -40°C to +105°C ambient
temperature and -40°C to +125°C
junction temperature
maximum exposure interval: 502 x tROW
pixel size: 3 µm x 3 µm
-
output interface: 1-lane MIPI/LVDS
serial output
dark current: 350 e /s
@ 50°C junction temperature
¬
¬
output formats: 10-bit B&W RAW
lens size: 1/7.5"
¬
¬
image area: 1968 µm x 1488 µm
package dimensions:
- a-CSP™: 3910 µm x 3410 µm
Functional Block Diagram
OV7261
image sensor array
output
interface
column
sample/hold
MCP/N
MDP/N
array
10-bit
ADC
AMP
gain
control
control register bank
SCCB slave interface
regulator
PLL system control logic
timing generator
