12V 8.5 AH @ 20-hr.
PSH-1280FR 36W/Cell@15-min.
Rechargeable Sealed Lead Acid Battery
PSH – High-Rate Series
CONSTANT POWER DISCHARGE (WATTS/CELL) AT 25°C (77°F)
CHARGING
Watts per Cell @ 25°C (68°F)
Final
Model
Cycle Applications: Apply constant voltage charge at
2.35v/c – 2.45v/c (14.1 – 14.7v for 12v Monobloc) at 20°C.
Initial charging current should be set at less than 0.25C
Amps. Switch to float charge to avoid overcharging.
Voltage
5min 10min 15min 20min 30min 45min 60min
1.75
1.70
1.67
65
66
67
43
44
45
35
36
37
24
17.5
18.7
19.5
14.8
15
12.8
12.9
13
24.3
24.7
PSH-1280FR
15.5
“Float” or “Stand-By” Service: Apply constant voltage
charge of 2.25v/c – 2.30v/c (13.5 to 13.8 volts for 12v
Monobloc at 20°C. When held at this voltage, the battery
will seek its own current level and maintain itself in a fully
charged condition.
DISCHARGE CHARACTERISTICS
14.0
Ambient Temperature 20oC (68oF)
13.0
12.0
11.0
10.0
9.0
Temperature Compensation: Charging Voltage for both
Cyclic and Standby applications should be regulated in
relation to ambient temperature. As temperature rises
charging voltage should be reduced to prevent overcharge
and increased as temperature falls to avoid undercharge.
0.425
0.85
1.7
4.25
For further charging information including temperature
compensation factors, see Power Sonic Technical Manual/
Power Sonic Charger specifications.
Final
8.5
Voltage
8.0
17
1.2 2.4
6
12 24 36 48 1
min
2
4 6 8 10 20 4 0
h
APPLICATIONS
Discharge Time
UPS
Telecoms
•
•
•
•
Data Center
Fire and Security
SHELF LIFE & STORAGE
100
Charging is not
necessary unless
100% of capacity
is required.
CHARGERS
80
Power Sonic offers a wide range of chargers suitable
for batteries with a variety of capacities.
5oC
(41oF)
Charging before
use is necessary
to help recover
full capacity.
60
Please refer to our website for more information on
our switch mode and transformer type chargers.
Chargemayfail
to restore full
capacity. Do not
let batteries reach
this state.
30oC
20oC
40oC
(86oF)
(104oF)
(68oF)
40
0
Please contact our technical department for advice if
you have difficulty in locating a suitable charger.
0
2
4
6
8
10 12 14 16 18 20
Standing Period (Months)
FURTHER INFORMATION
Please refer to our website www.power-sonic.com
for a complete range of useful downloads, such as
product catalogs, material safety data sheets (MSDS),
ISO certification, etc.
