This document was generated on 09/13/2021
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
0923181223
Active
Picoflex Ribbon-Cable Connectors
Picoflex PF-50 IDT-to-Board-in Z-Style, 12 Circuits, 0.23m Length
Overview:
Description:
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Product Specification PS-99020-0011-001 (PDF)
Application tooling part link
Application Tooling Part Link
Application Tooling Part Link
Series image - Reference only
EU ELV
62100-6000
62100-6010
General
Product Family
Series
Not Relevant
Cable Assemblies
92318
EU RoHS
China RoHS
Assembly Configuration
Connector to Connector
Overview
Product Name
UPC
Dual Ended Connectors
Picoflex PCB-to-IDT
Picoflex Ribbon-Cable Connectors
Picoflex
Compliant
REACH SVHC
Not Contained Per -
D(2021)4569-DC (8
July 2021)
822350104883
Halogen-Free
Status
Not Low-Halogen
Physical
Cable Length
Circuits (Loaded)
Color - Resin
0.23m
12
Natural
For more information, please visit Contact US
Gender
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Packaging Type
Female-Female
None
Phosphor Bronze
Tin
Tin
Polyester
7.310/g
2
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Search Parts in this Series
92318 Series
Bag
Mates With
Picoflex PF-50 Header 90325 , 90800 ,
90779 , 90715 , 90814
Pitch - Mating Interface
Plating min - Mating
Plating min - Termination
Single Ended
1.27mm
2.032µm
2.032µm
No
Termination Interface: Style
Waterproof / Dustproof
Wire Insulation Diameter
Wire Size AWG
IDT or Pierce, Through Hole - Kinked Pin
No
N/A
28
Application Tooling | FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Wire/Cable Type
PVC, Ribbon Cable
Electrical
Current - Maximum per Contact
Shielded
Global
1.2A
No
250V
Description
Product #
Extractor Tool for
Connectors
621006000
Voltage - Maximum
Material Info
Reference - Drawing Numbers
Product Specification
Sales Drawing
PS-99020-0011-001
SD-92318-001-001
