VDSS
ID25
RDS(on)
Standard
IXTH / IXTM 5N100
IXTH / IXTM 5N100A
1000V 5 A
1000V 5 A
2.4 Ω
2.0 Ω
Power MOSFET
N-ChannelEnhancementMode
Symbol
Test Conditions
MaximumRatings
TO-247 AD (IXTH)
VDSS
VDGR
TJ = 25°C to 150°C
1000
1000
V
V
TJ = 25°C to 150°C; RGS = 1 MΩ
VGS
Continuous
Transient
±20
±30
V
V
D(TAB)
VGSM
ID25
IDM
TC = 25°C
5
A
A
TO-204 AA (IXTM)
TC = 25°C, pulse width limited by TJM
20
PD
TC = 25°C
180
W
TJ
-55 ... +150
150
°C
°C
°C
TJM
Tstg
G
-55 ... +150
D
Md
Mountingtorque
1.13/10 Nm/lb.in.
G = Gate,
D = Drain,
S = Source,
TAB = Drain
Weight
TO-204 = 18 g, TO-247 = 6 g
Maximumleadtemperatureforsoldering
1.6 mm (0.062 in.) from case for 10 s
300
°C
Features
Internationalstandardpackages
Low RDS (on) HDMOSTM process
Rugged polysilicon gate cell structure
Low package inductance (< 5 nH)
- easy to drive and to protect
Fast switching times
Symbol
Test Conditions
CharacteristicValues
(TJ = 25°C, unless otherwise specified)
min. typ. max.
Applications
Switch-modeandresonant-mode
powersupplies
Motorcontrols
UninterruptiblePowerSupplies(UPS)
DC choppers
VDSS
VGS = 0 V, ID = 3 mA
1000
2
V
V
VGS(th)
VDS = VGS, ID = 250 µA
4.5
IGSS
IDSS
VGS = ±20 VDC, VDS = 0
±100 nA
250 µA
VDS = 0.8 • VDSS
VGS = 0 V
TJ = 25°C
TJ = 125°C
Advantages
1
mA
Easy to mount with 1 screw (TO-247)
(isolated mounting screw hole)
Space savings
RDS(on)
VGS = 10 V, ID = 0.5 ID25
5N100
5N100A
2.4
2.0
Ω
Ω
Pulse test, t ≤ 300 µs, duty cycle d ≤ 2 %
Highpowerdensity
IXYS reserves the right to change limits, test conditions, and dimensions.
© 2000 IXYS All rights reserved
93009C (4/96)
1 - 4
