IXTA140N12T2
IXTP140N12T2
Symbol
Test Conditions
Characteristic Values
Min. Typ. Max.
TO-263 Outline
(TJ = 25C, Unless Otherwise Specified)
gfs
VDS = 10V, ID = 0.5 • ID25, Note 1
VGS = 0V, VDS = 25V, f = 1MHz
66
110
S
Ciss
Coss
Crss
9700
850
58
pF
pF
pF
td(on)
tr
td(off)
tf
27
30
39
17
ns
ns
ns
ns
Resistive Switching Times
Pins:
1 - Gate
2,4 - Drain
3 - Source
V
GS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
RG = 2 (External)
Qg(on)
Qgs
174
52
nC
nC
nC
VGS = 10V, VDS = 0.5 • VDSS, ID = 0.5 • ID25
Qgd
40
RthJC
RthCH
0.26 C/W
C/W
TO-220
0.50
Source-Drain Diode
Symbol
Test Conditions
Characteristic Values
(TJ = 25C, Unless Otherwise Specified)
Min. Typ.
Max.
140
560
1.4
IS
VGS = 0V
A
A
V
ISM
VSD
Repetitive, Pulse Width Limited by TJM
IF = IS, VGS = 0V, Note 1
TO-220 Outline
trr
65
13
ns
A
IF = 0.5 • ID25, VGS = 0V
IRM
QRM
-di/dt = 100A/s
VR = 60V
430
nC
Notes: 1. Pulse test, t 300s, duty cycle, d 2%.
2. On through-hole packages, RDS(on) Kelvin test contact
location must be 5mm or less from the package body.
Pins: 1 - Gate
3 - Source
2 - Drain
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from a subjective evaluation of the design, based upon prior knowledge and experience, and constitute a
"considered reflection" of the anticipated result. IXYS reserves the right to change limits, test
conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
