VUO 36
IdAVM = 35 A
VRRM = 1200-1800 V
Three Phase
Rectifier Bridge
~
+
–
-
VRSM
V
VRRM
V
Type
~
~
~
~
600
1200
1400
1600
1800
600
1200
1400
1600
1800
VUO 36-06NO8
VUO 36-12NO8
VUO 36-14NO8
VUO 36-16NO8
VUO 36-18NO8
~
+
Features
Symbol
Test Conditions
Maximum Ratings
●
Package with ¼" fast-on terminals
Isolation voltage 3000 V~
Planar passivated chips
Blocking voltage up to 1800 V
Low forward voltage drop
UL registered E 72873
IdAV
IdAVM
T = 85°C, module
TCC = 62°C, module
27
35
A
A
●
●
●
●
●
IFSM
T
= 45°C;
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
550
600
A
A
VVRJ = 0
T
= T
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
500
550
A
A
VVRJ = 0 VJM
I2t
T
= 45°C
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
1520
1520
A2s
A2s
VVRJ = 0
Applications
●
Supplies for DC power equipment
Input rectifiers for PWM inverter
Battery DC power supplies
Field supply for DC motors
T
= T
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
1250
1250
A2s
A2s
VVRJ = 0 VJM
●
●
TVJ
TVJM
Tstg
-40...+150
150
-40...+150
°C
°C
°C
●
VISOL
50/60 Hz, RMS
IISOL £ 1 mA
t = 1 min
t = 1 s
2500
3000
V~
V~
Advantages
●
Easy to mount with one screw
Space and weight savings
Improved temperature and power
Md
Mounting torque
(M5)
(10-32 UNF)
2 ± 10 %
18 ± 10 %
Nm
lb.in.
●
●
Weight
typ.
22
g
cycling
Symbol
IR
Test Conditions
Characteristic Values
Dimensions in mm (1 mm = 0.0394")
TVJ = 25°C;
VR = VRRM
VR = VRRM
£
£
0.3
2.0
mA
mA
TVJ = TVJM
;
VF
IF = 150 A;
TVJ = 25°C
£
1.7
V
VT0
rT
For power-loss calculations only
0.8
7.4
V
mW
RthJC
per diode; DC current
per module
7.5
1.25
K/W
K/W
RthJH
per diode; DC current
per module
8.4
1.4
K/W
K/W
dS
dA
a
Creeping distance on surface
Creepage distance in air
Max. allowable acceleration
12.7
9.4
50
mm
mm
m/s2
Data according to DIN IEC 60747 and refer to a single diode unless otherwise stated.
IXYS reserves the right to change limits, test conditions and dimensions.
© 2000 IXYS All rights reserved
1 - 2
