VUO 70
IdAV = 70 A
VRRM = 800-1600 V
Three Phase
Rectifier Bridge
A
VRSM
V
VRRM
V
Types
E
D
C
900
800
VUO 70-08NO7
VUO 70-12NO7
VUO 70-14NO7
VUO 70-16NO7
1300
1500
1700
1200
1400
1600
B
Symbol
Conditions
TC = 100°C, module
Maximum Ratings
Features
• Package with copper base plate
• Isolation voltage 3000 V~
• Planar passivated chips
• Low forward voltage drop
• ¼" fast-on power terminals
IdAV
IFSM
①
70
A
TVJ = 45°C;
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
550
600
A
A
TVJ = TVJM
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
500
550
A
A
Applications
I2t
TVJ = 45°C
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
1520
1520
A2s
A2s
• Supplies for DC power equipment
• Input rectifiers for PWM inverter
• Battery DC power supplies
• Field supply for DC motors
TVJ = TVJM
VR = 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
1250
1250
A2s
A2s
TVJ
TVJM
Tstg
-40...+150
150
-40...+125
°C
°C
°C
Advantages
• Easy to mount with two screws
• Space and weight savings
• Improved temperature and power
cycling capability
VISOL
50/60 Hz, RMS t = 1 min
ISOL ≤ 1 mA t = 1 s
2500
3000
V~
V~
I
• Small and light weight
Md
Mounting torque (M5)
(10-32 UNF)
5 ± 15 %
44 ± 15 % lb.in.
Nm
Weight
typ.
110
g
Symbol
IR
Conditions
Characteristic Values
Dimensions in mm (1 mm = 0.0394")
VR = VRRM
;
;
TVJ = 25°C
TVJ = TVJM
≤
≤
0.5 mA
10 mA
VR = VRRM
VF
IF = 150 A;
TVJ = 25°C
≤
1.7
V
VT0
rT
For power-loss calculations only
0.8
8
V
mΩ
RthJC
RthJH
per diode; DC current
per module
per diode, DC current
per module
1.45 K/W
0.242 K/W
1.9 K/W
0.317 K/W
dS
dA
a
Creeping distance on surface
Creepage distance in air
Max. allowable acceleration
16.1 mm
7.5 mm
50 m/s2
Data according to IEC 60747 refer to a single diode unless otherwise stated
① for resistive load at bridge output. IXYS reserves the right to change limits, test conditions and dimensions.
© 2003 IXYS All rights reserved
1 - 2
