LM3-EWN1-01-N2

型号：

LM3-EWN1-01-N2

描述：

SMD LED[ SMD LED ]

品牌：

CREE[ CREE, INC ]

页数：

6 页

PDF大小：

383 K

下载PDF手册
®
Cree SMD LED
Model # LM3-EWNꢀ-0ꢀ-N2
Data Sheet
120-degree, 2.7 x 2.0 mm, SMT LED in white color with water-transparent lens
Applications
•
•
•
•
Indicators
Illuminations
LCD Back Lights
Automobile Applications
Absolute Maximum Ratings (TA = 25°C)
Items
Symbol
Absolute Maximum Rating
Unit
mA
mA
V
Forward Current
Peak Forward Current
Reverse Voltage
Power Dissipation
IF
25
100
Note 1
IFP
VR
PD
5
100
mW
°C
Operation Temperature
Storage Temperature
T
-40 ~ +100
-40 ~ +100
opr
Tstg
°C
Junction Temperature
TJ
110
450
300
°C
Note 2
Junction/Ambient
RTHJA
RTHJS
°C/W
°C/W
Junction/Solder Point
Notes:
1. Pulse width ≤0.1 msec, duty ≤1/10.
2. Rth test condition: mounted on PCB FR4 (pad size ≥16 mm2)
Typical Electrical & Optical Characteristics (TA = 25°C )
Characteristics
Forward Voltage
Reverse Current
Symbol
Condition
IF = 20 mA
VR = 5 V
Unit
V
Minimum
Typical
Maximum
VF
IR
3.4
4.0
10
ꢀ A
Luminous Flux
ꢁV
IV
IF = 20 mA
IF = 20 mA
IF = 20 mA
IF = 20 mA
IF = 20 mA
mlm
mcd
4000
1500
0.30
0.29
120
Luminous Intensity
1120
x
Chromaticity
Coordinates
y
50% Power Angle
2ꢂ ½
deg
Subject to change without notice.
www.cree.com/ledlamps
ꢀ
Standard Bins for LM3-EWNꢀ-0ꢀ-Nꢀ (IF = 20 mA)
Lamps are sorted to luminous intensity (IV) and chromaticity coordiates (x,y) bins shown.
Orders for LM3-EWN1-01-N1 may be filled with any or all bins contained as below.
All luminous intensity (IV) and chromaticity coordinates (x,y) values shown and specified are at IF = 20 mA.
k1
k2
k3
k4
k5
k6
X2 or
above
2240 mcd
X1
W2
W1
1800 mcd
1400 mcd
1120 mcd
Chromaticity Coordinates (x,y)
Rank
k1
k4
k2
k3
0.264
0.280
0.248
0.291
0.257
0.275
0.281
0.275
0.281
0.291
0.257
0.300
0.267
0.287
0.295
0.287
0.300
0.267
0.3065
0.297
0.305
x
Chromaticity
Coordinates
0.267
0.295
0.275
y
Rank
k5
k6
0.297
0.305
0.3065
0.275
0.313
0.283
0.307
0.315
0.307
0.315
0.313
0.283
0.322
0.295
0.319
0.328
0.319
0.328
0.322
0.295
0.330
0.307
0.330
0.339
x
Chromaticity
Coordinates
y
Important Notes:
1. All ranks will be included per delivery; rank ratio will be based on the dice distribution.
2. Tolerance of measurement of luminous intensity is ±10%.
3. Tolerance of measurement of the color coordinates is ±0.01.
4. Tolerance of measurement of VF is ±0.05 V.
5. Packaging methods are available for selection; please refer to the “Cree LED Lamp Packaging” document.
6. Please refer to the “Cree LED Lamp Reliability Test Parameters” document for reliability test conditions.
7. Please refer to the “Cree LED Lamp Soldering & Handling” document for information about how to use this LED
product safely.
8. Do not handle the device by the SMD surface. Care must be taken to avoid damage to the SMD surface or the
interior of the device, which can be damaged by excessive force to the SMD surface.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
Fax: +1.919.313.5778
www.cree.com/ledlamps
Copyright © 2007 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and the
Cree logo are registered trademarks of Cree, Inc.
2
CLD-CTꢀ65.000
CIE Chromaticity Diagram
0.90
520
530
0.80
510
540
55
0.70
560
0.60
570
490
0.50
580
590
0.40
600
˾ˉ
˾ˈ
610
620
630
˾ˇ
˾ˆ
˾˅
0.30
480
˴
˾˄
0.20
470
0.10
460
0.00
0.00
0.10
0.20
0.30
0.40
0.50
0.60
0.70
0.80
X
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
Copyright © 2007 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and the
Cree logo are registered trademarks of Cree, Inc.
USA Tel: +1.919.313.5300
Fax: +1.919.313.5778
www.cree.com/ledlamps
3
CLD-CTꢀ65.000
Graphs
-10
0
-40
-30 -20
-50
If (mA)
0.0
Vr(V)
100.0
80.0
-10.0
-20.0
60.0
40.0
20.0
-30.0
-40.0
-50.0
Vf(V)
Ir(uA)
0.0
3.0
FIG.1 FORWARD CURRENT VS.
FORWARD VOLTAGE.
5.0
FIG.2 REVERSE CURRENT VS.
REVERSE VOLTAGE.
3.4
3.8
4.2
4.6
Half Power WL=150nm
100%
5.0
4.0
3.0
2.0
1.0
75%
50%
25%
If(mA)
20.0 40.0 60.0 80.0 100.0
0.0
0.0
0%
400
500 600 700 800
FIG.3 RELATIVE LUMINOUS INTENSITY VS.
FORWARD CURRENT
FIG.4 RELATIVE LUMINOUS INTENSITY VS.
WAVELENGTH.
IF(mA)
50
50% Power Angle :
0
Ie(%)
100%
40
30
Rth j-s=300 C/W
Rth j-a=450 C/W
80%
60%
20
10
40%
20%
T ( C)
100
0
0
20
40
60
80
0%
-90
-30
0
30
-60
60
90
FIG.5 MAXIMUM FORWARD DC CURRENT VS
TEMPERATURE. DERATING BASED ON Tjmax=110 C
FIG.6 FAR FIELD PATTERN
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
Copyright © 2007 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and the
Cree logo are registered trademarks of Cree, Inc.
USA Tel: +1.919.313.5300
Fax: +1.919.313.5778
www.cree.com/ledlamps
ꢁ
CLD-CTꢀ65.000
Mechanical Dimensions
All dimensions are in mm.
Notes
RoHS Compliance
The levels of environmentally sensitive, persistent biologically toxic (PBT), persistent organic pollutants (POP), or
otherwise restricted materials in this product are below the maximum concentration values (also referred to as the
threshold limits) permitted for such substances, or are used in an exempted application, in accordance with EU Direc-
tive 2002/95/EC on the restriction of the use of certain hazardous substances in electrical and electronic equipment
(RoHS), as amended through April 21, 2006.
Vision Advisory Claim
Users should be cautioned not to stare at the light of this LED product. The bright light can damage the eye.
Cree, Inc.
4600 Silicon Drive
Copyright © 2007 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and the
Cree logo are registered trademarks of Cree, Inc.
Durham, NC 27703
USA Tel: +1.919.313.5300
Fax: +1.919.313.5778
www.cree.com/ledlamps
5
CLD-CTꢀ65.000
Kit Number System
Cree LED lamps are tested and sorted into performance bins. A bin is specified by ranges of color, forward voltage,
and brightness. Sorted LEDs are packaged for shipping in various convenient options. Please refer to the “Cree LED
Lamp Packaging Standard” document for more information about shipping and packaging options.
Cree LEDs are sold by order codes in combinations of bins called kits. Order codes are configured in the following
manner:
Standard/Custom
0: Standard
C: Custom
VF
0: Full forward voltage distribution
1~9, A~Z . . . : special request *
Wd/Color
1: Full-color distribution
2~9, A~Z . . . : special request *
aaaaaaaaa-aaa-aa- x x x x x
I
V0: Full luminous intensity distribution
1~9, A~Z . . . : special request *
Packing type
0: Standard = tape pack
1~9, A~Z . . . : special request *
Product P/N
* Contact your Cree sales representative for ordering information.
Standard Available Kits*
Kit Number
Description
LM3-EWN1-01-N1-00001 SMD 120 White, FULL RANK, Tape & Reel
LM3-EWN1-01-N1-00002 SMD 120 White, A1, A2, B1, B2, Tape & Reel
* Please contact your Cree representative about the availability of non-standard kits.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
Copyright © 2007 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and the
Cree logo are registered trademarks of Cree, Inc.
USA Tel: +1.919.313.5300
Fax: +1.919.313.5778
www.cree.com/ledlamps
6
CLD-CTꢀ65.000
