8. Notices during the use of KYL-600L
1) The antenna should away from the power supply if use the switch
power, because the transmitting of the antenna may affect the normal
work of the switch power. When the transmission happen fault,
checking the power voltage whether interfered from the antenna is
one way of eliminating fault.
2) Use the min. grain wave and high anti-jamming switch power or
batteries
3) The power capacity must meet D.C. 5~12V, more than 800mA
output current
4) The space between the experiment Radio should be more than 5m.
The antenna should span on the high to increase the distance of
electric wave. It is important for using shortwave communication
equipment in the city.
5) After connecting the antenna to the Radio, the space between the
Radios should more than 10m, so avoiding signal backup.
6) The antenna plywood should nip in the connection inside the
antenna, but not nip the antenna projectile, so avoiding the
performance of the antenna.
7) High frequency cable don’t come down directness, circle a circuit
and fixup it on the frame for the best.
9. Standard configuration and Antenna configuration
i: Standard configuration:
* One KYL-600L RF module
* A 9pin flat Connection Line
* A whip antenna（about 10cm）
ii: Antenna configuration:
Many appropriative antennas for low power RF modules are selected
for meeting different user antenna configuration. Please ask our Sales
office for further information about the antenna’s dimension and
performance. The main options of antennas are exterior flagelliform
rubber antenna with helical SMA joint, small osculum antenna, small
rod antenna and elbow antenna. If the user has special demands on
