Working frequency 433MHz(400-470MHz);
RF power: 500mW;
Receive sensitivity: -120dBm
5、 Receive current: 30mA; transmitting current: 300mA
6、 Power supply: DC 9-15V
7、 Size: 82mm*82mm
III. DIP switch definition
DIP8：Working mode choosing:
ON—send the inputting conditions. The module will send the
inputting conditions of the 4-channel ON-OFF
OFF—send timely every 1s or 2s; principal equipment will send
the 4-channel input condition to the subordinate equipment
(non-realtime transmission)
DIP7：Principal and subordinate mode choosing under the timing mode:
ON—subordinate equipment, OFF—principal equipment
DIP6：Sending interval choosing under the timing mode:
ON—slow(2s one time), OFF—fast(1s one time)
DIP5：No definition
DIP1-4：Channels choosing (max 16 channels)
The following is the channel correspondence table for DIP switch 1-16:
Channel
No.
Channel
No.
Channel
No.
Channel
No.
DIP NO.
DIP NO.
DIP NO.
DIP NO.
