OV2655
applications
mobile phones
toys
PC multimedia
digital still cameras
ordering information
OV02655-V38A
(color, lead-free, 38-pin CSP2)
OV02655-G00A
(color, chip probing, no backgrinding)
product specifications
product features
industry leading low-light sensitivity
of 1030 mV(Lux-sec)
support for:
array size: 1600 x 1200
input clock frequency: 6 ~ 27 MHz
– video or snapshot operations
– auto focus control (AFC)
– horizontal/vertical sub-sampling
power supply:
max image transfer rate:
– UXGA (1600 x 1200): 15 fps (and
any size scaling down from UXGA)
– SVGA (800 x 600): 30 fps (and any
size scaling down from SVGA)
ultra low power and low cost
– core: 1.5VDC + 5%
– analog: 2.45 ~ 3.0V
– I/O: 1.7 ~ 3.0V
automatic image control functions:
– automatic exposure control (AEC)
– automatic white balance (AWB)
– automatic 50/60 Hz luminance
detection
– internal and external frame
synchronization
– LED and flash strobe mode
power requirements:
– active: 250 mW
– standby: 75 μA
S/N ratio: 38 dB
second CameraChip-sharing ISP
and MIPI interface
dynamic range: 66 dB
– automatic black level calibration
(ABLC)
temperature range:
– operating: -20° C to 70°C
– stable image: 0° C to 50° C
sensitivity: 1030 mV/(Lux-sec)
maximum exposure interval:
standard serial SCCB interface
support for output formats: RAW
RGB, RGB565/555, YUV422/420,
and YCbCr422
digital video port (DVP) parallel
output interface
1235 x t
ROW
output format (8-bit):
– YUV(422/420)
– YCbCr422
– RGB565/555
– 8-/10-bit raw RGB data
MIPI serial output interface
pixel size: 1.75 μm x 1.75 μm
programmable controls for frame
rate, AEC/AGC 16-zone size/
embedded one-time programmable
(OTP) memory
image area: 2842 μm x 2121 μm
position/weight control, mirror and
flip, scaling, cropping, and windowing
package/die dimensions:
– CSP2: 4835 μm x 4895 μm
– COB: 4850 μm x 4910 μm
image quality controls: color
saturation, hue, gamma, sharpness
(edge enhancement), lens correction,
defective pixel canceling, and noise
canceling
lens size: 1/5"
chief ray angle: 25° non-linear
functional block diagram
OV2655
image sensor core
image sensor processor
image output
interface
column
sample/hold
DVP
DATA[9:0]
10-bit RAW
array
10-bit
A/D
AMP
MIPI
50/60Hz
auto
detection
gain
control
control register bank
SCCB
slave
interface
MIPI
control
interface
timing generator
and system control logic
PLL
OV2655_PB_001
