Embedded Power for
Business-Critical Continuity
Rev.03.23.07
nxi100
4 of 4
Americas
5810 Van Allen Way
Carlsbad, CA 92008
USA
Telephone: +1 760 930 4600
Facsimile: +1 760 930 0698
0.160 (4.06) REF
0.250 (6.35) REF
2.320 (58.93) REF
1
31
32
Europe (UK)
62
Waterfront Business Park
Merry Hill, Dudley
West Midlands, DY5 1LX
United Kingdom
Telephone: +44 (0) 1384 842 211
Facsimile: +44 (0) 1384 843 355
0.062 0.007 THICK
FR-4 2-Sided CKT BD
W/Gold Plated 30μ"
Connector Fingers
3.200 (81.28) REF
0.500 max.
(12.70)
3.800 (96.52)
3.186 0.002
(80.92 0.05)
0.307 (7.80)
Asia (HK)
16th - 17th Floors, Lu Plaza
2 Wing Yip Street, Kwun Tong
Kowloon, Hong Kong
Telephone: +852 2176 3333
Facsimile: +852 2176 3888
0.855 (21.72)
0.305 (7.75)
0.265 (6.73) REF
8.050
0.820 max.
(20.83)
62
32
0.042 (1.07) Typ.
Key slot
(1.27) REF
1.143 (29.03)
0.100 (2.54)
C C
L L
For global contact, visit:
30 EQ Spaces @ 0.100 (2.54)
each Equals 3.000 (76.20)
TOL Non-Accum
0.093 (2.36)
www.powerconversion.com
Dimensions in Inches (mm)
Tolerances (unless otherwise specified)
2 Place 0.02
technicalsupport@powerconversion.com
While every precaution has been taken to ensure
accuracy and completeness in this literature, Emerson
Network Power assumes no responsibility, and disclaims
all liability for damages resulting from use of this
information or for any errors or omissions.
Figure 1: Mechanical Drawing
Notes
1
2
3
15 mV pk-pk ripple 8 x 560 μF/4 V OSCON and 10 x 4.7 μF/6.3 V MLCC’st on the output. Vin = 12 V, Vout = 1.5 V, Iout =
60 A.
125 mV peak deviation when slewing load from no load to full load at 50 A/μs. Oscon type low impedance caps required
across output.
Each phase operates at a fixed 330 kHz. Effective fundamental output
frequency is 990 kHz / 3 phases each at 330 kHz interleaved.
Recommended mating connector is AMP 1364125-1 or equivalent.
From 5 Hz to 20 Hz, maintaining 0.02 G2/Hz from 20 Hz to 500 Hz, all axes.
Test performed in end use equipment.
Refer to thermal de-rating curves found in the long form datasheet.
VID code lower than 1.25 V, use 5 A as minimum load.
Emerson Network Power.
The global leader in enabling
business-critical continuity.
4
5
6
7
8
9
AC Power
Connectivity
DC Power
The ‘Y’ suffix indicates that these parts are TSE RoHS 5/6 (non Pb-free) compliant.
10 NOTICE: Some models do not support all options. Please contact your local Artesyn representative or use the on-line
Embedded Power
model number search tool at http://www.artesyn.com/powergroup/products.htm to find a suitable alternative.
