Embedded Power for
Business-Critical Continuity
Rev.03.28.07
nxi150
4 of 4
Americas
5810 Van Allen Way
Carlsbad, CA 92008
USA
0.255 (6.48) Max
1
31
32
0.250 (6.35) Max
62
Telephone: +1 760 930 4600
Facsimile: +1 760 930 0698
3.800 (96.52)
Europe (UK)
Waterfront Business Park
Merry Hill, Dudley
West Midlands, DY5 1LX
United Kingdom
Telephone: +44 (0) 1384 842 211
Facsimile: +44 (0) 1384 843 355
0.936 (23.77)
62
32
0.700 (17.78)
0.093 (2.36)
Asia (HK)
0.042 (1.07)
1.243
(31.57)
16th - 17th Floors, Lu Plaza
2 Wing Yip Street, Kwun Tong
Kowloon, Hong Kong
Telephone: +852 2176 3333
Facsimile: +852 2176 3888
0.063 0.007 THICK
FR-4 2-Sided CKT BD
W/Gold Plated 30μ"
Connector Fingers
C
L
30 EQ Spaces @ 0.100 (2.54)
each Equals 3.000 (76.20)
TOL Non-Accum
0.307 (7.80)
3.186 (80.92)
For global contact, visit:
Dimensions in Inches (mm)
Tolerances (unless otherwise specified)
2 Place 0.02
www.powerconversion.com
technicalsupport@powerconversion.com
3 Place 0.010
While every precaution has been taken to ensure
accuracy and completeness in this literature, Emerson
Network Power assumes no responsibility, and disclaims
all liability for damages resulting from use of this
information or for any errors or omissions.
Figure 1: Mechanical Drawing
Notes
2
1
2
3
Recommended output capacitance, 8 x 560 μF/4 V
OSCON and 10 x 4.7 μF/6.3 V MLCC.
15 mV pk-pk ripple. Vin = 12 V, Vout = 1.5 V, Iout = 65
A.
125 mV peak deviation when slewing load from no
load to full load at 50 A/μs. Recommended capacitors
(per Note 1) required across output.
Each phase operates at a fixed 250 kHz. Effective
fundamental output
frequency is 1 MHz / 4 phases each at 250 kHz
interleaved.
Recommended mating connector is AMP 1489162-1
or equivalent.
6
7
8
From 5 Hz to 20 Hz, maintaining 0.02 G /Hz from 20
Hz to 500 Hz, all axes.
Emerson Network Power.
The global leader in enabling
business-critical continuity.
When included in the users system ESD event shall
cause no out-of-regulation conditions.
Please consult your local application support for:
Longform Datasheet and Application Note for the de-
rating curves
AC Power
4
5
Connectivity
DC Power
9
The ‘Y’ suffix.indicates that these parts are TSE RoHS
5/6 (non Pb-free) compliant.
10 NOTICE: Some models do not support all options.
Please contact your local Artesyn representative or use
the on-line model number search tool at
Embedded Power
http://www.artesyn.com/powergroup/products.htm
to find a suitable alternative.
