LUPA 3000
General Specifications
General Specifications
Parameter
Specifications
Parameter
Specifications
Active Pixels
Pixel Size
1696 (H) x 1710 (V)
8 µm x 8µm.)
Extended Dynamic Range
Multiple slope (up to 80 dB optical
dynamic range)
Pixel Type
Data Rate
Pipelined shutter pixel
Electro-Optical Specifications
412 Mbps (32 serial LVDS outputs)
Parameter
Specifications
Shutter Type
485 fps at 3.0 Mpixel (Can be
boosted by subsampling and win-
dowing.))
Conversion gain
39.2uV/e
27000e
Full well charge
Sensitivity
Frame Rate
485 fps at 3.0 Mpixel (Can be
boosted by sub sampling and win-
dowing.)
2800 V.m2/W.s @600nm with
micro-lens
Fill factor
36%
Master Clock
206 MHz
Parasitic light sensitivity
Dark noise
QE x FF
< 1/5000
21e-
Windowing (ROI)
Randomly programmable ROI read
out. Implemented as scanning of
lines or columns from an uploaded
position
37% @ 680nm
1.7% of Vsat
2.2% of Vsignal
250 mV/s @25°C
1.1W @485 fps
FPN
PRNU
Read Out
Windowed, flipped, mirrored, and
subsampled read out.
Dark signal
Power dissipation
ADC Resolution
Sensitivity
8-bit, on-chip
3.81 V/lux.s @ 550nm
Document History Page
Document Title: LUPA 3000, 485 FPS, 13.3 Gbit High Speed Image Sensor
Document Number:
REV.
ECN
Orig. of Change
Submission Date
Description Of Change
**
2598180
VED
October 29, 2008
New image sensor document
