IXGE 200N60B
VCES
IC25
= 600 V
= 160 A
HiPerFASTTM IGBT
VCE(sat) = 2.3 V
tfi
= 160ns
E
ISOPLUS227TM (IXGE)
E c
Symbol
TestConditions
Maximum Ratings
G
VCES
VCGR
TJ = 25°C to 150°C
TJ = 25°C to 150°C; RGE = 1 MΩ
600
600
V
V
VGES
VGEM
Continuous
Transient
20
30
V
V
E c
C
IC25
IL
IC90
ICM
TC = 25°C
Terminal Current Limit(RMS)
TC = 90°C
160
100
96
A
A
A
A
G = Gate, E = Emitter, C = Collector
c
either emitter terminal can be
used as Main or Kelvin Emitter
TC = 25°C, 1 ms
400
SSOA
V
= 15 V, T = 125°C, RG = 2.4 Ω
ICM = 200
A
(RBSOA)
CGlaE mped indVuJctive load @ 0.8 VCES
Features
•Conforms to SOT-227B outline
•Isolation voltage 3000 V~
•Very high current, fast switching IGBT
PC
TC = 25°C
416
W
TJ
TJM
Tstg
-40 ... +150
150
-40 ... +150
°C
°C
°C
•Low VCE(sat)
- for minimum on-state conduction
losses
VISOL
50/60 Hz
ISOL ≤ 1 mA
t = 1 min
t = 1 s
2500
3000
V~
V~
I
•MOS Gate turn-on
- drive simplicity
Md
Mounting torque
1.5/13 Nm/lb.in.
1.5/13 Nm/lb.in.
•Low collector-to-case capacitance
Terminal connection torque (M4)
(< 50 pF)
Weight
19
g
•Low package inductance (< 5 nH)
- easy to drive and to protect
Applications
Symbol
TestConditions
Characteristic Values
•AC motor speed control
•DC servo and robot drives
•DC choppers
(TJ = 25°C, unless otherwise specified)
min. typ. max.
BVCES
VGE(th)
IC = 1 mA , VGE = 0 V
IC = 1 mA, VCE = VGE
600
2.5
V
V
•Uninterruptible power supplies (UPS)
5.5
•Switch-mode and resonant-mode
power supplies
ICES
VCE = V
T = 25°C
TJJ = 125°C
200
2
µA
VGE = 0CVES
mA
Advantages
•Easy to mount with 2 screws
•Space savings
IGES
VCE = 0 V, VGE = 20 V
IC = 120A, VGE = 15 V
400
2.3
nA
V
VCE(sat)
•High power density
DS98911B(09/04)
