GenX3TM 300V IGBT
VCES = 300V
IC25 = 400A
VCE(sat) ≤ 1.15V
IXGN400N30A3
Ultra-Low-Vsat PT IGBT for
up to 10kHz Switching
E
SOT-227B, miniBLOC
E153432
Symbol
Test Conditions
Maximum Ratings
VCES
VCGR
TJ = 25°C to 150°C
300
300
V
V
E c
TJ = 25°C to 150°C, RGE = 1MΩ
G
VGES
VGEM
Continuous
Transient
±20
±30
V
V
IC25
TC = 25°C (Chip Capability)
TC = 110°C
Terminal Current Limit
400
200
A
A
A
A
E c
IC110
ILRMS
ICM
C
200
G = Gate, C = Collector, E = Emitter
TC = 25°C, 1ms
1200
cEither Emitter Terminal Can Be Used
as Main or Kelvin Emitter
SSOA
V
GE= 15V, TVJ = 125°C, RG = 1Ω
ICM = 400
A
V
(RBSOA)
Clamped Inductive Load
@ 0.8 • VCES
PC
TJ
TC = 25°C
735
W
Features
-55 ... +150
°C
z Optimized for Low Conduction Losses
z High Current Capability
z International Standard Package
z miniBLOC, with Aluminium Nitride
Isolation
TJM
Tstg
150
-55 ... +150
°C
°C
VISOL
50/60Hz
IISOL ≤ 1mA
t = 1min
t = 1s
2500
3000
V~
V~
Md
Mounting Torque
Terminal Connection Torque (M4)
1.5/13
1.3/11.5
Nm/lb.in.
Nm/lb.in.
Advantages
Weight
30
g
z High Power Density
z Low Gate Drive Requirement
Applications
Symbol
Test Conditions
Characteristic Values
z Power Inverters
z UPS
(TJ = 25°C, Unless Otherwise Specified)
Min.
300
3.0
Typ.
Max.
z Motor Drives
BVCES
VGE(th)
ICES
IC = 1mA, VGE = 0V
IC = 4mA, VCE = VGE
VCE = VCES, VGE = 0V
V
V
z SMPS
z PFC Circuits
z Battery Chargers
z Welding Machines
z Lamp Ballasts
z Inrush Current Protection Circuits
5.0
50 μA
TJ = 125°C
2 mA
IGES
VCE = 0V, VGE = ±20V
±400 nA
VCE(sat)
IC = 100A, VGE = 15V, Note 1
IC = 400A
1.15
V
V
1.70
DS99592B(7/09)
© 2009 IXYS CORPORATION, All Rights Reserved
