IXGT6N170AHV
TO-268 (VHV) Outline
Symbol Test Conditions
(TJ = 25°C Unless Otherwise Specified)
Characteristic Values
Min.
Typ.
Max.
gfs
IC = 6A, VCE = 20V, Note 1
2.0
3.5
S
Cies
Coes
Cres
390
20
7
pF
pF
pF
VCE = 25V, VGE = 0V, f = 1MHz
PIN:
Qg(on)
Qge
Qgc
18.5
2.8
nC
nC
nC
1 - Gate
2 - Emitter
3 - Collector
IC = 6A, VGE = 15V, VCE = 0.5 • VCES
8.2
td(on)
tri
Eon
td(off)
tfi
46
40
ns
ns
mJ
ns
ns
Inductive load, TJ = 25°C
IC = 6A, VGE = 15V
0.59
220
32
VCE = 0.5 • VCES, RG = 33Ω
400
Note 2
Eoff
0.18
0.36 mJ
td(on)
tri
48
43
ns
ns
Inductive load, TJ = 125°C
IC = 6A, VGE = 15V
Eon
td(off)
tfi
0.62
230
41
mJ
ns
VCE = 0.5 • VCES, RG = 33Ω
ns
Note 2
Eoff
0.25
mJ
RthJC
1.65 °C/W
Notes:
1. Pulse test, t ≤ 300μs, duty cycle, d ≤ 2%.
2. Switching times & energy losses may increase for higher VCE(clamp), TJ or RG.
ADVANCE TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from a subjective evaluation of the design, based upon prior knowledge and experience, and constitute a
"considered reflection" of the anticipated result. IXYS reserves the right to change limits, test
conditions, and dimensions without notice.
IXYS Reserves the Right to Change Limits, Test Conditions, and Dimensions.
