Part Number:
Status:
1200700183
Active
Overview:
Brad Micro-Change (M12) Connectors
Description:
Micro-Change (M12) Receptacle, 4 Poles, 1/2" - 14 NPT Threads, Straight Male, 0.15m
(6.00") Length
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Agency Certification
CSA
UL
Series image - Reference only
LR6837
E152210
EU ELV
Not Reviewed
General
Product Family
Series
Industrial Receptacles
120070
EU RoHS
China RoHS
IP Rating
NEMA Rating
Overview
Product Name
Type
IP67
NEMA 6
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Brad Micro-Change (M12) Connectors
Micro-Change (M12)
Single Ended (pigtail)
78678837659
UPC
Not Reviewed
For more information, please visit Contact US
Physical
Coupling Type
Gender
Keyway
External Thread
Male
Single
0.15m
China ROHS
ELV
RoHS Phthalates
Not Reviewed
Not Reviewed
Not Reviewed
Length
Material - Component
Mounting Thread Size
Orientation
Black Annodized Aluminum
1/2" - 14 NPT
Straight
Search Parts in this Series
120070 Series
Panel Mount
Front
Poles
4
Temperature Range - Operating
Wire Size AWG
Wire/Cable Type
-20°C to +80°C
22
Leads, UL 1061
Electrical
Current - Maximum per Contact
Voltage - Maximum
4.0A
250V AC/DC
Material Info
Engineering Number
8R4006A18A060
SD-120070-005
Reference - Drawing Numbers
Sales Drawing
