Part Number:
Status:
1200700175
Active
Overview:
Brad Micro-Change (M12) Connectors
Description:
Micro-Change (M12) Receptacle, 4 Pole, 1/2" - 14 NPT Threads, Male (Straight) to 18
AWG Leads, 0.30m (11.81") Length
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Agency Certification
CSA
UL
Series image - Reference only
LR6837
E152210
EU ELV
Not Relevant
General
Product Family
Series
Industrial Receptacles
120070
EU RoHS
China RoHS
IP Rating
NEMA Rating
Overview
Product Name
Type
IP67
NEMA 6
Not Compliant
REACH SVHC
Contained Per -
ED/88/2018 (15
January 2019)
Lead
Brad Micro-Change (M12) Connectors
Micro-Change (M12)
Single Ended (pigtail)
78678824302
UPC
Halogen-Free
Status
Not Low-Halogen
Physical
Coupling Type
Gender
External Thread
Male
Single
For more information, please visit Contact US
Keyway
Length
0.30m
China ROHS
ELV
RoHS Phthalates
50 Image
Not Relevant
Not Contained
Material - Component
Mounting Thread Size
Net Weight
Orientation
Panel Mount
Poles
Temperature Range - Operating
Wire Size AWG
Wire/Cable Type
Gray Annodized Aluminum
1/2" - 14 NPT
124.000/g
Straight
Front
Search Parts in this Series
120070 Series
4
-20°C to +80°C
18
UL 1061
Electrical
Current - Maximum per Contact
Voltage - Maximum
4.0A
250V AC/DC
Material Info
Engineering Number
8R4006A16A120
SD-120070-044
Reference - Drawing Numbers
Sales Drawing
