WM8734

w

Stereo Audio CODEC

DESCRIPTION

FEATURES



Audio Performance

The WM8734 is a low power stereo CODEC ideal for

DVD/RW, MP3, media centre and automotive applications



90dB SNR (‘A’ weighted @ 48kHz) ADC

100dB SNR (‘A’ weighted @ 48kHz) DAC

2.7 – 3.6V Digital Supply Operation

2.7 – 3.6V Analogue Supply Operation

Stereo line inputs are provided, along with a mute function

and programmable line level volume control.

Stereo 24-bit multi-bit sigma delta ADCs and DACs are used

with oversampling digital interpolation and decimation filters.



ADC and DAC Sampling Frequency: 8kHz – 96kHz

Selectable ADC High Pass Filter

Digital audio input word lengths from 16-32 bits and

sampling rates from 8kHz to 96kHz are supported.

2 or 3-Wire MPU Serial Control Interface

Programmable Audio Data Interface Modes



I²S, Left, Right Justified or DSP

16/20/24/32 bit Word Lengths

Master or Slave Clocking Mode

Stereo audio line level outputs are provided along with anti-

thump mute and power up/down circuitry.

The device is controlled via a 2 or 3 wire serial interface.

The interface provides access to all features including level

controls, mutes, de-emphasis and power management



Stereo Audio Inputs and Outputs

20-lead SSOP Package

facilities. The device is available in

package.

a 20-lead SSOP

APPLICATIONS



CD and Minidisc Recorder

MP3 Player / Recorder

BLOCK DIAGRAM

AVDD

VMID

CONTROL INTERFACE

W

WM8734

AGND

VOL

RLINEIN

MUTE

ADC

DAC

ROUT

LOUT

+12 to -34.5dB,

1.5dB Steps

DIGITAL

FILTERS

VOL

LLINEIN

MUTE

+12 to -34.5dB,

1.5dB Steps

CLKIN

DIVIDER

(Div x1, x2)

DIGTAL AUDIO INTERFACE

WOLFSON MICROELECTRONICS plc

Production Data, August 2013, Rev 4.4

Copyright 2013 Wolfson Microelectronics plc

WM8734

Production Data

TABLE OF CONTENTS

DESCRIPTION....................................................................................................... 1

FEATURES............................................................................................................ 1

APPLICATIONS..................................................................................................... 1

BLOCK DIAGRAM ................................................................................................ 1

TABLE OF CONTENTS......................................................................................... 2

PIN CONFIGURATION – SSOP ............................................................................ 3

ORDERING INFORMATION - SSOP..................................................................... 3

PIN DESCRIPTION - SSOP................................................................................... 4

ABSOLUTE MAXIMUM RATINGS........................................................................ 5

RECOMMENDED OPERATING CONDITIONS..................................................... 5

ELECTRICAL CHARACTERISTICS ..................................................................... 6

TERMINOLOGY .............................................................................................................. 7

POWER CONSUMPTION (EXAMPLES)............................................................... 8

MASTER CLOCK TIMING..................................................................................... 9

DIGITAL AUDIO INTERFACE – MASTER MODE .......................................................... 9

DIGITAL AUDIO INTERFACE – SLAVE MODE............................................................ 10

MPU INTERFACE TIMING............................................................................................ 12

DEVICE DESCRIPTION ...................................................................................... 14

AUDIO SIGNAL PATH................................................................................................... 14

DEVICE OPERATION ................................................................................................... 20

AUDIO DATA SAMPLING RATES ................................................................................ 25

ACTIVATING DSP AND DIGITAL AUDIO INTERFACE................................................ 30

SOFTWARE CONTROL INTERFACE........................................................................... 30

POWER DOWN MODES............................................................................................... 32

REGISTER MAP............................................................................................................ 34

DIGITAL FILTER CHARACTERISTICS .............................................................. 37

TERMINOLOGY ............................................................................................................ 37

DAC FILTER RESPONSES .......................................................................................... 38

ADC FILTER RESPONSES .......................................................................................... 38

ADC HIGH PASS FILTER ............................................................................................. 39

DIGITAL DE-EMPHASIS CHARACTERISTICS.................................................. 40

APPLICATIONS INFORMATION ........................................................................ 41

RECOMMENDED EXTERNAL COMPONENTS ........................................................... 41

MINIMISING POP NOISE AT THE ANALOGUE OUTPUTS......................................... 42

PACKAGE DIMENSIONS (SSOP) ...................................................................... 43

IMPORTANT NOTICE ......................................................................................... 44

ADDRESS: .................................................................................................................... 44

REVISION HISTORY ........................................................................................... 45

PD, Rev 4.4, August 2013

w

2

WM8734

Production Data

PIN CONFIGURATION

20

19

18

17

16

15

14

13

12

11

DGND

DBVDD

BCLK

1

2

DCVDD

MCLK

SCLK

SDIN

3

DACDAT

DACLRC

ADCDAT

4

5

CSB

6

MODE

7

LLINEIN

RLINEIN

ADCLRC

LOUT

8

ROUT

AVDD

9

VMID

10

AGND

ORDERING INFORMATION

MOISTURE SENSITIVITY

LEVEL

PEAK SOLDERING

TEMPERATURE

DEVICE

TEMPERATURE RANGE

PACKAGE

20-lead SSOP

(Pb-free)

XWM8734EDS/V

-40 to +85^oC

MSL3

260°C

20-lead SSOP

XWM8734EDS/RV

MSL3

260°C

(Pb-free

tape and reel)

Note:

Reel quantity = 2,000

PD, Rev 4.4, August 2013

3

w

WM8734

Production Data

PIN DESCRIPTION

1

NAME

DGND

TYPE

Ground

DESCRIPTION

Digital GND

Digital Buffers VDD

2

DBVDD

BCLK

Supply

Digital Audio Bit Clock, Pull Down, (see Note 1)

DAC Digital Audio Data Input

3

Digital Input/Output

Digital Input

4

DACDAT

DACLRC

ADCDAT

ADCLRC

LOUT

DAC Sample Rate Left/Right Clock. Pull Down (see Note 1)

ADC Digital Audio Data Output

ADC Sample Rate Left/Right Clock, Pull Down (see Note 1)

Left Channel Line Output

5

Digital Input/Output

Digital Output

Digital Input/Output

Analogue Output

Supply

6

7

8

Right Channel Line Output

9

ROUT

Analogue VDD

10

11

12

13

14

15

16

AVDD

Analogue GND

AGND

Ground

Mid-rail reference decoupling point

Right Channel Line Input (AC coupled)

Left Channel Line Input (AC coupled)

Control Interface Selection, Pull Up (see Note 1)

VMID

Analogue Output

Analogue Input

Digital Input

RLINEIN

LLINEIN

MODE

CSB

3-Wire MPU Chip Select / 2-Wire MPU interface address selection, active low,

Pull up (see Note 1)

Digital Input

3-Wire MPU Data Input / 2-Wire MPU Data Input

3-Wire MPU Clock Input / 2-Wire MPU Clock Input

Master Clock Input (MCLK)

17

18

19

20

SDIN

SCLK

Digital Input/Output

Digital Input

Supply

MCLK

DCVDD

Digital Core VDD

Note:

1. Pull Up/Down only present when Control Register Interface ACTIVE = 0 to conserve power.

PD, Rev 4.4, August 2013

w

4

WM8734

Production Data

ABSOLUTE MAXIMUM RATINGS

Absolute Maximum Ratings are stress ratings only. Permanent damage to the device may be caused by continuously operating at

or beyond these limits. Device functional operating limits and guaranteed performance specifications are given under Electrical

Characteristics at the test conditions specified.

ESD Sensitive Device. This device is manufactured on a CMOS process. It is therefore generically susceptible

to damage from excessive static voltages. Proper ESD precautions must be taken during handling and storage

of this device.

Wolfson tests its package types according to IPC/JEDEC J-STD-020 for Moisture Sensitivity to determine acceptable storage

conditions prior to surface mount assembly. These levels are:

MSL1 = unlimited floor life at <30C / 85% Relative Humidity. Not normally stored in moisture barrier bag.

MSL2 = out of bag storage for 1 year at <30C / 60% Relative Humidity. Supplied in moisture barrier bag.

MSL3 = out of bag storage for 168 hours at <30C / 60% Relative Humidity. Supplied in moisture barrier bag.

CONDITION

MIN

-0.3V

MAX

+3.63V

Digital supply voltage

Analogue supply voltage

Voltage range digital inputs

Voltage range analogue inputs

Operating temperature range, T_A

Storage temperature after soldering

-0.3V

+3.63V

DGND -0.3V

AGND -0.3V

-40C

DVDD +0.3V

AVDD +0.3V

+85C

-65C

+150C

Notes:

1. Analogue and digital grounds must always be within 0.3V of each other.

2. The digital supply core voltage (DCVDD) must always be less than or equal to the analogue supply voltage (AVDD)

RECOMMENDED OPERATING CONDITIONS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Digital supply range (Core)

Digital supply range (Buffer)

Analogue supply range

Ground

DCVDD

DBVDD

2.7

3.6

V

AVDD

V

DGND, AGND

IAVDD

0

V

Total analogue supply current

DCVDD, DBVDD,

AVDD = 3.3V

16

mA

Digital supply current

IDCVDD, IDBVDD

DCVDD, DBVDD

AVDD = 3.3V

8

5

mA

uA

Standby Current Consumption

PD, Rev 4.4, August 2013

5

w

WM8734

Production Data

ELECTRICAL CHARACTERISTICS

Test Conditions

AVDD, DBVDD = 3.3V, AGND = 0V, DCVDD = 3.3V, DGND = 0V, T_A= +25^oC, Slave Mode, fs = 48kHz, MCLK = 256fs unless

otherwise stated.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Digital Logic Levels (CMOS Levels)

Input LOW level

V_IL

V_IH

V_OL

0.3 x DBVDD

V

Input HIGH level

0.7 x DBVDD

0.9 x DBVDD

Output LOW

0.10 x

DBVDD

Output HIGH

V_OH

V

Power On Reset Threshold (DCVDD)

DCVDD Threshold On -> Off

Hysteresis

V_th

V_IH

V_OL

0.9

0.3

0.6

V

DCVDD Threshold Off -> On

Analogue Reference Levels

Reference voltage

V_VMID

R_VMID

AVDD/2

50k

V

Potential divider resistance

Line Input to ADC



Input Signal Level (0dB)

V_INLINE

SNR

1.0

AVDD/3.3

90

Vrms

dB

Signal to Noise Ratio

(Note 1,2,3)

A-weighted, 0dB gain

@ fs = 48kHz

85

A-weighted, 0dB gain

@ fs = 96kHz

90

88

A-weighted, 0dB gain

@ fs = 48kHz,

AVDD = 2.7V

Dynamic Range (Note 3)

DNR

A-weighted, -60dB full

scale input

90

dB

Total Harmonic Distortion

THD

-1dB input, 0dB gain

1kHz 100mVpp

-84

50

45

-74

dB

Power Supply Rejection Ratio

PSSR

20Hz to 20kHz

100mVpp

ADC channel separation

Programmable Gain

1kHz input

90

0

dB

-34.5

+12

Rsource < 50

Guaranteed Monotonic

0dB, 1kHz input

0dB gain

Programmable Gain Step Size

Mute attenuation

1.5

80

dB



Input Resistance

R_INLINE

20k

10k

30k

15k

10

12dB gain

Input Capacitance

C_INLINE

pF

PD, Rev 4.4, August 2013

w

6

WM8734

Production Data

Test Conditions

AVDD, DBVDD = 3.3V, AGND = 0V, DCVDD = 3.3V, DGND = 0V, T_A= +25^oC, Slave Mode, fs = 48kHz, MCLK = 256fs unless

otherwise stated.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Vrms

dB

Line Output for DAC Playback Only (Load= 47k. 50pF)

0dBfs Full scale output voltage

At LINE outputs

1.0 x

AVDD/3.3

100

Signal to Noise Ratio

(Note 1,2,3)

SNR

A-weighted,

@ fs = 48kHz

A-weighted

95

98

@ fs = 96kHz

A-weighted,

@ fs = 48kHz,

AVDD = 2.7V

Dynamic Range (Note 3)

Total Harmonic Distortion

DNR

THD

A-weighted, -60dB full

scale input

85

95

dB

1kHz, 0dBfs

1kHz, -3dBfs

1kHz 100mVpp

-88

-92

50

-80

Power Supply Rejection Ratio

PSSR

dB

20Hz to 20kHz

100mVpp

45

DAC channel separation

1kHz, 0dB

100

Notes:

1. Ratio of output level with 1kHz full scale input, to the output level with the input short circuited, measured ‘A’ weighted

over a 20Hz to 20kHz bandwidth using an Audio analyser.

2. Ratio of output level with 1kHz full scale input, to the output level with all zeros into the digital input, measured ‘A’

weighted over a 20Hz to 20kHz bandwidth.

3. All performance measurements done with 20kHz low pass filter, and where noted an A-weight filter. Failure to use

such a filter will result in higher THD+N and lower SNR and Dynamic Range readings than are found in the Electrical

Characteristics. The low pass filter removes out of band noise; although it is not audible it may affect dynamic

specification values.

4. VMID decoupled with 10uF and 0.1uF capacitors (smaller values may result in reduced performance).

TERMINOLOGY

1. Signal-to-noise ratio (dB) - SNR is a measure of the difference in level between the full scale output and the output

with no signal applied. (No Auto-zero or Automute function is employed in achieving these results).

2. Dynamic range (dB) - DNR is a measure of the difference between the highest and lowest portions of a signal.

Normally a THD+N measurement at 60dB below full scale. The measured signal is then corrected by adding the 60dB

to it. (e.g. THD+N @ -60dB= -32dB, DR= 92dB).

3. THD+N (dB) - THD+N is a ratio, of the rms values, of (Noise + Distortion)/Signal.

4. Stop band attentuation (dB) – Is the degree to which the frequency spectrum is attenuated (outside audio band).

5. Channel Separation (dB) - Also known as Cross-Talk. This is a measure of the amount one channel is isolated from

the other. Normally measured by sending a full scale signal down one channel and measuring the other.

6. Pass-Band Ripple – Any variation of the frequency response in the pass-band region.

PD, Rev 4.4, August 2013

w

7

WM8734

Production Data

POWER CONSUMPTION (EXAMPLES)

CURRENT CONSUMPTION

TYPICAL

MODE DESCRIPTION

POWEROFF

OUTPD

DACPD

ADCPD

LINEINPD

AVDD

(3.3V)

12.2

3.3

DCVDD

(1.5V)

3.2

DBVDD

(3.3V)

0.07

65

UNITS

Record and Playback

Playback Only

0

1

0

1

0

1

0

1

0

1

0

1

mA

A

2.3

Record Only

9.2

2.6

Standby (clock running)

Standby (clock stopped)

Power Down

16

77

16

0.3

0.2

A

1

0.3

77

65

A

(clock running)

Power Down

1

0.3

A

(clock stopped)

Notes:

1. The data presented here was measured with the audio interface in slave mode (MS = 0)

2. All figures are quiescent, with no signal.

PD, Rev 4.4, August 2013

w

8

WM8734

Production Data

MASTER CLOCK TIMING

t_MCLKL

MCLK

t _MCLKH

t _MCLKY

Figure 1 System Clock Timing Requirements

Test Conditions

AVDD, DBVDD = 3.3V, AGND = 0V, DCVDD = 3.3V, DGND = 0V, T_A= +25^oC, Slave Mode, fs = 48kHz, MCLK = 256fs unless

otherwise stated.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

System Clock Timing Information

MCLK System clock pulse width high

MCLK System clock pulse width low

MCLK System clock cycle time

MCLK Duty cycle

T_XTIH

T_XTIL

T_XTIY

18

ns

54

40:60

60:40

DIGITAL AUDIO INTERFACE – MASTER MODE

BCLK

ADCLRC

WM8734

DSP

ENCODER/

DECODER

DACLRC

CODEC

ADCDAT

DACDAT

Figure 2 Master Mode Connection

PD, Rev 4.4, August 2013

9

w

WM8734

Production Data

BCLK

(Output)

t_DL

ADCLRC

DAC/LRC

(Outputs)

t_DDA

ADCDAT

DACDAT

t_DST

t_DHT

Figure 3 Digital Audio Data Timing – Master Mode

Test Conditions

AVDD, DBVDD = 3.3V, AGND = 0V, DCVDD = 3.3V, DGND = 0V, T_A= +25^oC, Slave Mode, fs = 48kHz, MCLK = 256fs unless

otherwise stated.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Audio Data Input Timing Information

ADCLRC/DACLRC

propagation delay from

BCLK falling edge

t_DL

0

10

ns

ADCDAT propagation delay

from BCLK falling edge

t_DDA

t_DST

t_DHT

0

15

ns

DACDAT setup time to

BCLCK rising edge

10

DACDAT hold time from

BCLK rising edge

DIGITAL AUDIO INTERFACE – SLAVE MODE

BCLK

ADCLRC

WM8734

DSP

ENCODER/

DECODER

DACLRC

CODEC

ADCDAT

DACDAT

Figure 4 Slave Mode Connection

PD, Rev 4.4, August 2013

10

w

WM8734

Production Data

t_BCH

t_BCL

BCLK

t_BCY

DACLRC/

ADCLRC

t_LRSU

t_DS

t_LRH

DACDAT

ADCDAT

t_DD

t_DH

Figure 5 Digital Audio Data Timing – Slave Mode

Test Conditions

AVDD, DBVDD = 3.3V, AGND = 0V, DCVDD = 3.3V, DGND = 0V, T_A= +25^oC, Slave Mode, fs = 48kHz, MCLK = 256fs unless

otherwise stated.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Audio Data Input Timing Information

BCLK cycle time

t_BCY

t_BCH

t_BCL

50

20

10

ns

BCLK pulse width high

BCLK pulse width low

DACLRC/ADCLRC set-up

time to BCLK rising edge

t_LRSU

DACLRC/ADCLRC hold

time from BCLK rising edge

t_LRH

t_DS

t_DH

t_DD

10

0

ns

DACDAT set-up time to

BCLK rising edge

DACDAT hold time from

BCLK rising edge

ADCDAT propagation delay

from BCLK falling edge

10

PD, Rev 4.4, August 2013

11

w

WM8734

Production Data

MPU INTERFACE TIMING

t_CSL

t_CSH

CSB

t_SCY

t_CSS

t_SCS

t_SCH

t_SCL

SCLK

SDIN

LSB

t_DSU

t_DHO

Figure 6 Program Register Input Timing – 3-Wire MPU Serial Control Mode

Test Conditions

AVDD, DBVDD = 3.3V, AGND = 0V, DCVDD = 3.3V, DGND = 0V, T_A= +25^oC, Slave Mode, fs = 48kHz, MCLK = 256fs unless

otherwise stated.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Program Register Input Information

SCLK rising edge to CSB rising

edge

t_SCS

60

ns

SCLK pulse cycle time

SCLK pulse width low

SCLK pulse width high

SDIN to SCLK set-up time

SCLK to SDIN hold time

CSB pulse width low

t_SCY

t_SCL

t_SCH

t_DSU

t_DHO

t_CSL

t_CSH

t_CSS

80

20

ns

CSB pulse width high

CSB rising to SCLK rising

PD, Rev 4.4, August 2013

12

w

WM8734

Production Data

t₃

t₅

SDIN

t₄

t₆

t₂

t₈

SCLK

t₇

t₁

t₁₀

Figure 7 Program Register Input Timing – 2-Wire MPU Serial Control Mode

Test Conditions

AVDD, DBVDD = 3.3V, AGND = 0V, DCVDD = 3.3V, DGND = 0V, T_A= +25^oC, Slave Mode, fs = 48kHz, MCLK = 256fs unless

otherwise stated.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Program Register Input Information

SCLK Frequency

0

526

kHz

us

ns

SCLK Low Pulsewidth

SCLK High Pulsewidth

Hold Time (Start Condition)

Setup Time (Start Condition)

Data Setup Time

t₁

t₂

t₃

t₄

t₅

t₆

t₇

t₈

t₁₀

1.3

600

100

SDIN, SCLK Rise Time

SDIN, SCLK Fall Time

Setup Time (Stop Condition)

Data Hold Time

300

600

900

PD, Rev 4.4, August 2013

13

w

WM8734

Production Data

DEVICE DESCRIPTION

The WM8734 is a high performance audio CODEC designed specifically for audio applications that

require recording and playback features.

The CODEC includes line inputs to the on-board ADC, line outputs from the on-board DAC, a

configurable digital audio interface and a choice of 2 or 3 wire MPU control interface. It is fully

compatible and an ideal partner for a range of industry standard microprocessors, controllers and

DSPs.

The CODEC includes a stereo low noise input. Line inputs have +12dB to -34dB logarithmic volume

level adjustments and mute. All the required input filtering is contained within the device.

The on-board stereo analogue to digital converter (ADC) is of a high quality using a multi-bit high-

order oversampling architecture delivering optimum performance with low power consumption. The

output from the ADC is available on the digital audio interface. The ADC includes an optional digital

high pass filter to remove unwanted dc components from the audio signal.

The on-board digital to analogue converter (DAC) accepts digital audio from the digital audio

interface. Digital filter de-emphasis at 32kHz, 44.1kHz and 48kHz can be applied to the digital data

under software control. The DAC employs a high quality multi-bit high-order oversampling architecture

to again deliver optimum performance with low power consumption.

Special techniques allow the audio to be muted and the device safely placed into standby, sections of

the device powered off and volume levels adjusted without any audible clicks, pops or zipper noises.

Therefore standby and power off modes may be used dynamically under software control, whenever

recording or playback is not required.

The device caters for a number of different sampling rates including industry standard 8kHz, 32kHz,

44.1kHz, 48kHz, 88.2kHz and 96kHz. The digital filters used for both record and playback are

optimised for each sampling rate used.

The digitised output is available in a number of audio data formats I²S, DSP Mode (a burst mode in

which frame sync plus 2 data packed words are transmitted), MSB-First, left justified and MSB-First,

right justified. The digital audio interface can operate in both master or slave modes.

The software control uses either a 2 or 3-wire MPU interface.

AUDIO SIGNAL PATH

LINE INPUTS

The WM8734 provides Left and Right channel line inputs (RLINEIN and LLINEIN). The inputs are

high impedance and low capacitance, thus ideally suited to receiving line level signals from external

hi-fi or audio equipment.

Both line inputs include independent programmable volume level adjustments and input mute. The

scheme is illustrated in Figure 8. Passive RF and active Anti-Alias filters are also incorporated within

the line inputs. These prevent high frequencies aliasing into the audio band or otherwise degrading

performance.

PD, Rev 4.4, August 2013

14

w

WM8734

Production Data

LINEIN

12.5K

To

ADC

VMID

Figure 8 Line Input Schematic

The gain between the line inputs and the ADC is logarithmically adjustable from +12dB to –34.5dB in

1.5dB steps under software control. The ADC Full Scale input is 1.0V rms at AVDD = 3.3 volts. Any

voltage greater than full scale will possibly overload the ADC and cause distortion. Note that the full

scale input tracks directly with AVDD. The gain is independently adjustable on both Right and Left

Line Inputs. However, by setting the INBOTH bit whilst programming the volume control, both

channels are simultaneously updated with the same value. Use of INBOTH reduces the required

number of software writes required. The line inputs to the ADC can be muted in the analogue domain

under software control. The software control registers are shown below.

REGISTER

ADDRESS

BIT

LABEL

DEFAULT

DESCRIPTION

0000000

4:0

LINVOL[4:0]

10111

( 0dB )

Left Channel Line Input Volume

Control

Left Line In

11111 = +12dB . . 1.5dB steps down

to 00000 = -34.5dB

7

8

LINMUTE

1

0

Left Channel Line Input Mute to ADC

1 = Enable Mute

0 = Disable Mute

LRINBOTH

Left to Right Channel Line Input

Volume and Mute Data Load Control

1 = Enable Simultaneous Load of

LINVOL[4:0] and LINMUTE to

RINVOL[4:0] and RINMUTE

0 = Disable Simultaneous Load

0000001

4:0

7

RINVOL[4:0]

RINMUTE

10111

( 0dB )

Right Channel Line Input Volume

Control

Right Line In

11111 = +12dB . .1.5dB steps down

to 00000 = -34.5dB

1

0

Right Channel Line Input Mute to

ADC

1 = Enable Mute

0 = Disable Mute

8

RLINBOTH

Right to Left Channel Line Input

Volume and Mute Data Load Control

1 = Enable Simultaneous Load of

RINVOL[4:0] and RINMUTE to

LINVOL[4:0] and LINMUTE

0 = Disable Simultaneous Load

Table 1 Line Input Software Control

PD, Rev 4.4, August 2013

15

w

WM8734

Production Data

The line inputs are biased internally through the operational amplifier to VMID. Whenever the line

inputs are muted or the device placed into standby mode, the line inputs are kept biased to VMID

using special anti-thump circuitry. This reduces any audible clicks that may otherwise be heard when

re-activating the inputs.

The external components required to complete the line input application is shown in the Figure 9.

C2

R1

LINEIN

C1

R2

AGND

AGND AGND

Figure 9 Line Input Application Drawing

For interfacing to a typical CD system, it is recommended that the input is scaled to ensure that there

is no clipping of the signal. R1 = 5K, R2 = 5K, C1 = 47pF, C2 = 470nF (10V npo ceramic type).

R1 and R2 form a resistive divider to attenuate the 2 Vrms output from a CD player to a 1 Vrms level,

so avoiding overloading the inputs. R2 also provides a discharge path for C2, thus preventing the

input to C2 charging to an excessive voltage which may otherwise damage any equipment connected

that is not suitably protected against high voltages. C1 forms an RF low pass filter for increasing the

rejection of RF interference picked up on any cables. C2 forms a DC blocking capacitor to remove the

DC path between the WM8734 and the driving audio equipment. C2 together with the input

impedance of the WM8734 form a high pass filter.

ADC

The WM8734 uses a multi-bit oversampled sigma-delta ADC. A single channel of the ADC is

illustrated in the Figure 10.

ANALOG

FROM LINE INPUT

TO ADC DIGITAL FILTERS

INTEGRATOR

MULTI

BITS

Figure 10 Multi-Bit Oversampling Sigma Delta ADC Schematic

PD, Rev 4.4, August 2013

16

w

WM8734

Production Data

The use of multi-bit feedback and high oversampling rates reduces the effects of jitter and high

frequency noise.

The ADC Full Scale input is 1.0V rms at AVDD = 3.3 volts. Any voltage greater than full scale will

possibly overload the ADC and cause distortion. Note that the full scale input tracks directly with

AVDD. The device employs a pair of ADCs. The two channels cannot be selected independently.

The digital data from the ADC is fed for signal processing to the ADC Filters.

ADC FILTERS

The ADC filters perform true 24 bit signal processing to convert the raw multi-bit oversampled data

from the ADC to the correct sampling frequency to be output on the digital audio interface. Figure 11

illustrates the digital filter path.

TO DIGITAL

AUDIO

INTERFACE

DIGITAL

HPF

DECIMATION

FILTER

FROM ADC

DECIMATOR

HPFEN

Figure 11 ADC Digital Filter

The ADC digital filters contain a digital high pass filter, selectable via software control. The high-pass

filter response detailed in Digital Filter Characteristics. When the high-pass filter is enabled the dc

offset is continuously calculated and subtracted from the input signal. By setting HPOR the last

calculated dc offset value is stored when the high-pass filter is disabled and will continue to be

subtracted from the input signal. If the dc offset changed, the stored and subtracted value will not

change unless the high-pass filter is enabled. The software control is shown in Table 2.

REGISTER

ADDRESS

BIT

LABEL

DEFAULT

DESCRIPTION

00000101

ADC High Pass Filter Enable

(Digital)

0

ADCHPD

0

Digital Audio

Path Control

1 = Disable High Pass Filter

0 = Enable High Pass Filter

Store dc offset when High Pass

Filter disabled

4

HPOR

0

1 = store offset

0 = clear offset

Table 2 ADC Software Control

There are several types of ADC filters, frequency and phase responses of these are shown in Digital

Filter Characteristics. The filter types are automatically configured depending on the sample rate

chosen. Refer to the sample rate section for more details.

DAC FILTERS

The DAC filters perform true 24 bit signal processing to convert the incoming digital audio data from

the digital audio interface at the specified sample rate to multi-bit oversampled data for processing by

the analogue DAC. Figure 12 illustrates the DAC digital filter path.

PD, Rev 4.4, August 2013

17

w

WM8734

Production Data

FROM DIGITAL

AUDIO

INTERFACE

DIGITAL

INTERPOLATION

FILTER

TO LINE

OUTPUTS

DIGITAL

DE_EMPHASIS

MUTE

DEEMP

DACMU

Figure 12 DAC Filter Schematic

The DAC digital filter can apply digital de-emphasis under software control, as shown in Table 3. The

DAC can also perform a soft mute where the audio data is digitally brought to a mute level. This

removes any abrupt step changes in the audio that might otherwise result in audible clicks in the

audio outputs.

REGISTER

ADDRESS

BIT

LABEL

DEFAULT

DESCRIPTION

0000101

2:1

DEEMP[1:0]

00

De-emphasis Control

(Digital)

Digital Audio

Path Control

11 = 48kHz

10 = 44.1kHz

01 = 32kHz

00 = Disable

3

DACMU

1

DAC Soft Mute Control

(Digital)

1 = Enable soft mute

0 = Disable soft mute

Table 3 DAC Software Control

DAC

The WM8734 employs a multi-bit sigma delta oversampling digital to analogue converter. The

scheme for the converter is illustrated in Figure 13.

FROM DAC

DIGITAL

FILTERS

TO LINE OUTPUT

Figure 13 Multi-Bit Oversampling Sigma Delta Schematic

The DAC converts the multi-level digital audio data stream from the DAC digital filters into high quality

analogue audio.

PD, Rev 4.4, August 2013

18

w

WM8734

Production Data

LINE OUTPUTS

The WM8734 provides two low impedance line outputs LLINEOUT and RLINEOUT, suitable for

driving typical line loads of impedance 10K and capacitance 50pF. The line output is used to

selectively sum the outputs from the DAC or/and the Line inputs in bypass mode.

The LLINEOUT and RLINEOUT outputs are only available at a line output level and are not level

adjustable in the analogue domain, having a fixed gain of 0dB. The level is fixed such that at the DAC

full scale level the output level is Vrms at AVDD = 3.3 volts. Note that the DAC full scale level tracks

directly with AVDD. The scheme is shown in Figure 14. The line output includes a low order audio low

pass filter for removing out-of band components from the sigma-delta DAC. Therefore no further

external filtering is required in most applications.

DACSEL

FROM DAC

LINEOUT

VMID

TO HEADPHONE AMP

Figure 14 Line Output Schematic

The line output is muted by either muting the DAC (analogue) or Soft Muting (digital). Refer to the

DAC section for more details. Whenever the DAC is muted or the device placed into standby mode

the DC voltage is maintained at the line outputs to prevent any audible clicks from being present.

The software control for the line outputs is shown in Table 4.

REGISTER

ADDRESS

BIT

LABEL

DEFAULT

DESCRIPTION

DAC Select

0000100

4

DACSEL

0

Analogue

Audio Path

Control

1 = Select DAC

0 = Don’t select DAC

Table 4 Output Software Control

The recommended external components are shown in Figure 15.

R2

LINEOUT

C1

R1

AGND

Figure 15 Line Outputs Application Drawing

PD, Rev 4.4, August 2013

19

w

WM8734

Production Data

Recommended values are C1 = 470nF (10V npo type), R1 = 47K, R2 = 100

C1 forms a DC blocking capacitor to the line outputs. R1 prevents the output voltage from drifting so

protecting equipment connected to the line output. R2 forms a de-coupling resistor preventing

abnormal loads from disturbing the device. Note that poor choice of dielectric material for C1 can

have dramatic effects on the measured signal distortion at the output.

DEVICE OPERATION

DEVICE RESETTING

The WM8734 contains a power on reset circuit that resets the internal state of the device to a known

condition. The power on reset is applied as DCVDD powers on and released only after the voltage

level of DCVDD crosses a minimum turn off threshold. If DCVDD later falls below a minimum turn on

threshold voltage then the power on reset is re-applied. The threshold voltages and associated

hysteresis are shown in the Electrical Characteristics table.

The user also has the ability to reset the device to a known state under software control as shown in

the table below.

REGISTER

ADDRESS

BIT

LABEL

RESET

DEFAULT

DESCRIPTION

0001111

Reset Register

8:0

not reset

Reset Register

Writing 00000000 to register resets

device

Table 5 Software Control of Reset

When using the software reset. In 3-wire mode the reset is applied on the rising edge of CSB and

released on the next rising edge of SCLK. In 2-wire mode the reset is applied for the duration of the

ACK signal (approximately 1 SCLK period, refer to Figure 24).

CLOCKING SCHEMES

In a typical digital audio system there is only one central clock source producing a reference clock to

which all audio data processing is synchronised. This clock is often referred to as the audio system’s

Master Clock. To allow WM8734 to be used in a centrally clocked system, the WM8734 is capable of

deriving the sample rate clock from this Master Clock (Master Mode) or receiving the sample rate

clock from an external source (Slave Mode).

CORE CLOCK

The WM8734 DSP core can be clocked either by MCLK or MCLK divided by 2. This is controlled by

software as shown in Table 6 below.

REGISTER

ADDRESS

BIT

LABEL

DEFAULT

DESCRIPTION

0001000

6

CLKIDIV2

0

Core Clock divider select

Sampling

Control

1 = Core Clock is MCLK divided by 2

0 = Core Clock is MCLK

Table 6 Software Control of Core Clock

Having a programmable MCLK divider allows the device to be used in applications where higher

frequency master Clocks are available. For example the device can support 512fs master clocks

whilst fundamentally operating in a 256fs mode.

DIGITAL AUDIO INTERFACES

WM8734 may be operated in either one of the 4 offered audio interface modes. These are:

Right justified

Left justified

I²S

DSP mode

All four of these modes are MSB first and operate with data 16 to 32 bits, except right justified mode

which does not support 32 bits.

PD, Rev 4.4, August 2013

20

w

WM8734

Production Data

The digital audio interface takes the data from the internal ADC digital filter and places it on the

ADCDAT output. ADCDAT is the formatted digital audio data stream output from the ADC digital

filters with left and right channels multiplexed together. ADCLRC is an alignment clock that controls

whether Left or Right channel data is present on the ADCDAT lines. ADCDAT and ADCLRC are

synchronous with the BCLK signal with each data bit transition signified by a BCLK high to low

transition. BCLK maybe an input or an output dependent on whether the device is in master or slave

mode. Refer to the MASTER/SLAVE OPERATION section.

The digital audio interface also receives the digital audio data for the internal DAC digital filters on the

DACDAT input. DACDAT is the formatted digital audio data stream output to the DAC digital filters

with left and right channels multiplexed together. DACLRC is an alignment clock that controls whether

Left or Right channel data is present on DATDAT. DACDAT and DACLRC are synchronous with the

BCLK signal with each data bit transition signified by a BCLK transition. DACDAT is always an input.

BCLK and DACLRC are either outputs or inputs depending whether the device is in master or slave

mode. Refer to the MASTER/SLAVE OPERATION section

There are four digital audio interface formats accommodated by the WM8734. These are shown in the

figures below. Refer to the Electrical Characteristic section for timing information.

Left Justified mode is where the MSB is available on the first rising edge of BCLK following a ADCLR

or DACLRC transition.

1/fs

LEFT CHANNEL

RIGHT CHANNEL

DACLRC/

ADCLRC

BCLK

DACDAT/

ADCDAT

1

2

3

n

n-2 n-1

1

2

3

n

n-2 n-1

MSB

LSB

MSB

LSB

Figure 16 Left Justified Mode

I²S mode is where the MSB is available on the 2^ndrising edge of BCLK following a DACLRC or

ADCLRC transition.

1/fs

LEFT CHANNEL

RIGHT CHANNEL

DACLRC/

ADCLRC

BCLK

1 BCLK

DACDAT/

ADCDAT

1

2

3

n

1

2

3

n

n-2 n-1

LSB

MSB

Figure 17 I²S Mode

Right Justified mode is where the LSB is available on the rising edge of BCLK preceding a DACLRC

or ADCLRC transition, yet MSB is still transmitted first.

PD, Rev 4.4, August 2013

w

21

WM8734

Production Data

1/fs

LEFT CHANNEL

RIGHT CHANNEL

DACLRC/

ADCLRC

BCLK

DACDAT/

ADCDAT

1

2

3

n

1

2

3

n

n-2 n-1

MSB

LSB

MSB

LSB

Figure 18 Right Justified Mode

In DSP/PCM mode, the left channel MSB is available on either the 1^st(mode B) or 2^nd(mode A) rising

edge of BCLK (selectable by LRP) following a rising edge of LRC. Right channel data immediately

follows left channel data. Depending on word length, BCLK frequency and sample rate, there may be

unused BCLK cycles between the LSB of the right channel data and the next sample.

Figure 19 DSP/PCM Mode Audio Interface (mode A, LRP=1)

Figure 20 DSP/PCM Mode Audio Interface (mode B, LRP=0)

PD, Rev 4.4, August 2013

22

w

WM8734

Production Data

In all modes DACLRC and ADCLRC must always change on the falling edge of BCLK, refer to Figure

16, Figure 17, Figure 18, Figure 19 and Figure 20.

Operating the digital audio interface in DSP mode allows ease of use for supporting the various

sample rates and word lengths. The only requirement is that all data is transferred within the correct

number of BCLK cycles to suit the chosen word length.

In order for the digital audio interface to offer similar support in the three other modes (Left Justified,

I²S and Right Justified), the DACLRC, ADCLRC and BCLK frequencies, continuity and mark-space

ratios need more careful consideration.

In Slave mode, DACLRC and ADCLRC inputs are not required to have a 50:50 mark-space ratio.

BCLK input need not be continuous. It is however required that there are sufficient BCLK cycles for

each DACLRC/ADCLRC transition to clock the chosen data word length.

In Master mode, DACLRC and ADCLRC will be output with a 50:50 mark-space ratio with BCLK

output at 64fs.

The ADC and DAC digital audio interface modes are software configurable as indicated in Table 7.

Note that dynamically changing the software format may result in erroneous operation of the

interfaces and is therefore not recommended. The length of the digital audio data is programmable at

16/20/24 or 32 bits. Refer to the software control table below. The data is signed 2’s complement.

Both ADC and DAC are fixed at the same data length. The ADC and DAC digital filters process data

using 24 bits. If the ADC is programmed to output 16 or 20 bit data then it strips the LSBs from the 24

bit data. If the ADC is programmed to output 32 bits then it packs the LSBs with zeros. If the DAC is

programmed to receive 16 or 20 bit data, the WM8734 packs the LSBs with zeros. If the DAC is

programmed to receive 32 bit data, then it strips the LSBs.

The DAC outputs can be swapped under software control using LRP and LRSWAP as shown in Table

7. Stereo samples are normally generated as a Left/Right sampled pair. LRSWAP reverses the order

of that a Left sample goes to the right DAC output and a Right sample goes to the left DAC output.

LRP swaps the phasing so that a Right/Left sampled pair is expected and preserves the correct

channel phase difference.

To accommodate system timing requirements the interpretation of BCLK may be inverted, this is

controlled vias the software shown in Table 6. This is especially appropriate for DSP mode.

ADCDAT lines are always outputs. They power up and return from standby low.

DACDAT is always an input. It is expected to be set low by the audio interface controller when the

WM8734 is powered off or in standby.

ADCLRC, DACLRC and BCLK can be either outputs or inputs depending on whether the device is

configured as a master or slave. If the device is a master then the ADCLRC, DACLRC and BCLK

signals are outputs that default low. If the device is a slave then the ADCLRC, DACLRC and BCLK

are inputs.

PD, Rev 4.4, August 2013

23

w

WM8734

Production Data

REGISTER

ADDRESS

BIT

1:0

LABEL

DEFAULT

10

DESCRIPTION

0000111

FORMAT[1:0]

Audio Data Format Select

Digital Audio

Interface

Format

11 = DSP Mode, frame sync + 2 data

packed words

10 = I²S Format, MSB-First left-1

justified

01 = MSB-First, left justified

00 = MSB-First, right justified

Input Audio Data Bit Length Select

11 = 32 bits

3:2

IWL[1:0]

10

10 = 24 bits

01 = 20 bits

00 = 16 bits

4

LRP

0

DACLRC phase control (in left, right

or I²S modes)

1 = Right Channel DAC data when

DACLRC high

0 = Right Channel DAC data when

DACLRC low

(opposite phasing in I²S mode)

or

DSP mode A/B select (in DSP mode

only)

1 = MSB is available on 2nd BCLK

rising edge after ADCLRC/DACLRC

rising edge

0 = MSB is available on 1st BCLK

rising edge after ADCLRC/DACLRC

rising edge

5

6

7

LRSWAP

MS

0

DAC Left Right Clock Swap

1 = Right Channel DAC Data Left

0 = Right Channel DAC Data Right

Master Slave Mode Control

1 = Enable Master Mode

0 = Enable Slave Mode

Bit Clock Invert

BCLKINV

1 = Invert BCLK

0 = Don’t invert BCLK

Table 7 Digital Audio Interface Control

Note: If right justified 32 bit mode is selected then the WM8734 defaults to 24 bits.

MASTER AND SLAVE MODE OPERATION

The WM8734 can be configured as either a master or slave mode device. As a master mode device

the WM8734 controls sequencing of the data and clocks on the digital audio interface. As a slave

device the WM8734 responds with data to the clocks it receives over the digital audio interface. The

mode is set with the MS bit of the control register as shown in Table 8.

REGISTER

ADDRESS

BIT

LABEL

DEFAULT

DESCRIPTION

0000111

6

MS

0

Master Slave Mode Control

1 = Enable Master Mode

0 = Enable Slave Mode

Digital Audio Interface

Format

Table 8 Programming Master/Slave Modes

PD, Rev 4.4, August 2013

24

w

WM8734

Production Data

As a master mode device the WM8734 controls the sequencing of data transfer (ADCDAT, DACDAT)

and output of clocks (BCLK, ADCLRC, DACLRC) over the digital audio interface. It uses the timing

generated from either its on-board crystal or the MCLK input as the reference for the clock and data

transitions. This is illustrated in Figure 21. ADCDAT is always an output from and DACDAT is always

an input to the WM8734 independent of master or slave mode.

BCLK

ADCLRC

DSP

WM8734

CODEC

ENCODER/

DECODER

DACLRC

ADCDAT

DACDAT

Figure 21 Master Mode

As a slave device the WM8734 sequences the data transfer (ADCDAT, DACDAT) over the digital

audio interface in response to the external applied clocks (BCLK, ADCLRC, DACLRC). This is

illustrated in Figure 22.

BCLK

ADCLRC

DSP

WM8734

CODEC

ENCODER/

DECODER

DACLRC

ADCDAT

DACDAT

Figure 22 Slave Mode

Note that the WM8734 relies on controlled phase relationships between audio interface BCLK,

DACLRC and the master MCLK. To avoid any timing hazards, refer to the timing section for detailed

information.

AUDIO DATA SAMPLING RATES

The WM8734 provides for two modes of operation (normal and USB) to generate the required DAC

and ADC sampling rates. Normal and USB modes are programmed under software control according

to the table below.

In Normal mode, the user controls the sample rate by using an appropriate MCLK or crystal frequency

and the sample rate control register setting. The WM8734 can support sample rates from 8ks/s up to

96ks/s.

In USB mode, the user must use a fixed MLCK or crystal frequency of 12MHz to generate sample

rates from 8ks/s to 96ks/s. It is called USB mode since the common USB (Universal Serial Bus) clock

is at 12MHz and the WM8734 can be directly used within such systems. WM8734 can generate all

the normal audio sample rates from this one Master Clock frequency, removing the need for different

master clocks or PLL circuits.

PD, Rev 4.4, August 2013

25

w

WM8734

Production Data

Uniquely, the WM8734 offers the user the ability to sample the ADC and DAC at different rates under

software control in both Normal and USB modes. The reduces the burden on any controlling DSP.

However, the signal processing in the ADC and DAC over-sampling filters is tightly coupled together

in order to minimise power consumption. To this end, only the combinations of sample rates listed in

the following sections are supported. Note that these rates supported are anticipated to be the likely

combinations used in typical audio systems.

REGISTER

ADDRESS

BIT

LABEL

DEFAULT

DESCRIPTION

0001000

0

USB/

0

Mode Select

NORMAL

BOSR

Sampling

Control

1 = USB mode (250/272fs)

0 = Normal mode (256/384fs)

Base Over-Sampling Rate

1

0

USB Mode

0 = 250fs

1 = 272fs

Normal Mode

96/88.2 kHz

0 = 256fs

0 = 128fs

1 = 384fs

1 = 192fs

5:2

SR[3:0]

0000

ADC and DAC sample rate control;

See USB Mode and Normal Mode

Sample Rate sections for operation

Table 9 Sample Rate Control

SAMPLE RATE SETTING

In normal mode MCLK/crystal oscillator is set up according to the desired sample rates of the ADC

and DAC. For ADC or DAC sampling rates of 8, 32, 48 or 96kHz, MCLK frequencies of either

12.288MHz (256fs) or 18.432MHz (384fs) can be used. For ADC or DAC sampling rates of 8, 44.1 or

88.2kHz from MCLK frequencies of either 11.2896MHz (256fs) or 16.9344MHz (384fs) can be used.

The table below should be used to set up the device to work with the various sample rate

combinations. For example if the user wishes to use the WM8734 in normal mode with the ADC and

DAC sample rates at 48kHz and 48kHz respectively then the device should be programmed with

BOSR = 0, SR3 = 0, SR2 = 0, SR1 = 0 and SR0 = 0 with a 12.288MHz MCLK or with BOSR = 1, SR3

= 0, SR2 = 0, SR1 = 0 and SR0 = 0 with a 18.432MHz MCLK. The ADC and DAC will then operate

with a Digital Filter of type 1, refer to Digital Filter Characteristics section for an explanation of the

different filter types.

PD, Rev 4.4, August 2013

26

w

WM8734

Production Data

SAMPLING

RATE

MCLK

FREQUENCY

SAMPLE

RATE

REGISTER SETTINGS

DIGITAL

FILTER

TYPE

ADC

DAC

kHz

MHz

BOSR

SR3

0

SR2

0

SR1

0

SR0

0

48

12.288

18.432

12.288

18.432

12.288

18.432

12.288

18.432

12.288

18.432

12.288

18.432

11.2896

16.9344

11.2896

16.9344

11.2896

16.9344

11.2896

16.9344

11.2896

16.9344

0 (256fs)

1 (384fs)

0 (256fs)

1 (384fs)

0 (256fs)

1 (384fs)

0 (256fs)

1 (384fs)

0 (256fs)

1 (384fs)

0 (128fs)

1 (192fs)

0 (256fs)

1 (384fs)

0 (256fs)

1 (384fs)

0 (256fs)

1 (384fs)

0 (256fs)

1 (384fs)

0 (128fs)

1 (192fs)

1

2

1

2

0

48

8

48

8

0

1

0

1

0

1

0

1

0

8

0

1

0

1

32

96

44.1

0

1

0

1

0

96

0

1

0

1

44.1

1

0

1

0

8

1

0

1

(Note 1)

44.1

1

0

1

8

(Note 1)

8

1

0

1

0

1

0

1

0

8

1

0

1

(Note 1) (Note 1)

88.2 88.2

1

0

1

Table 10 Normal Mode Sample Rate Look-up Table

Notes:

1. 8k not exact, actual = 8.018kHz

2. All other combinations of BOSR and SR[3:0] that are not in the truth table are invalid

The BOSR bit represents the base over-sampling rate. This is the rate that the WM8734 digital signal

processing is carried out at. In Normal mode, with BOSR = 0, the base over-sampling rate is at 256fs,

with BOSR = 1, the base over-sampling rate is at 384fs. This can be used to determine the actual

audio data rate produced by the ADC and required by the DAC.

Example scenarios are:

1. with a requirement that the ADC data rate is 8kHz and DAC data rate is 48kHz, then choosing

MCLK = 12.288MHz the device is programmed with BOSR = 0 (256fs), SR3 = 0, SR2 = 0, SR1

= 1, SR0 = 0.The ADC output data rate will then be exactly 8kHz (derived from 12.288MHz/256

x1/6) and the DAC expects data at exactly 48kHz (derived from 12.288MHz/256)

2. with a requirement that ADC data rate is 8kHz and DAC data rate is 44.1kHz, then choosing

MCLK = 16.9344MHz the device is programmed with BOSR = 1 (384fs), SR3 = 1, SR2 = 0, SR1

= 0, SR0 = 1. The ADC will no longer output data at exactly 8.000kHz, instead it will be 8.018kHz

(derived from 16.9344MHz/384 x 2/11), the DAC still is at exactly 44.1kHz (derived from

16.9344MHz/384). A slight (sub 0.5%) pitch shift will therefore result in the 8kHz audio data and

(importantly) the user must ensure that the data across the digital interface is correctly

synchronised at the 8.018kHz rate.

PD, Rev 4.4, August 2013

27

w

WM8734

Production Data

The exact sample rates achieved are defined by the relationships in Table 11 below.

TARGET

ACTUAL SAMPLING RATE

SAMPLING

RATE

BOSR=0

MCLK=11.2896

kHz

BOSR=1

MCLK=12.288

MCLK=18.432

kHz

MCLK=16.9344

kHz

8

8.018

8

8.018

(12.288MHz/256) x 1/6

32

(11.2896MHz/256) x 2/11

not available

(18.432MHz/384) x 1/6

32

(16.9344MHz/384) x 2/11

not available

32

44.1

48

(12.288MHz/256) x 2/3

not available

(18.432MHz/384)x 2/3

not available

44.1

11.2896MHz/256

not available

16.9344MHz /384

not available

48

12.288MHz/256

not available

18.432MHz/384

not available

88.2

96

88.2

(11.2896MHz/384) x 2

not available

(16.9344MHz /384) x 2

not available

96

(12.288MHz/256) x 2

(18.432MHz/384) x 2

Table 11 Normal Mode Actual Sample Rates

128/192fs NORMAL MODE

The Normal Mode sample rates are designed for standard 256fs and 384fs MCLK rates. However the

WM8734 is also capable of being clocked from a 128 or 192fs MCLK for application over limited

sampling rates as shown in the table below.

SAMPLING

RATE

MCLK

FREQUENCY

SAMPLE

RATE

REGISTER SETTINGS

DIGITAL

FILTER

TYPE

ADC

DAC

kHz

MHz

6.144

9.216

5.6448

8.4672

BOSR

SR3

SR2

SR1

SR0

48

0

1

0

1

0

1

2

44.1

Table 12 128fs Normal Mode Sample Rate Look-up Table

512/768fs NORMAL MODE

512 fs and 768 fs MCLK rates can be accommodated by using the CLKIDIV2 bit. The core clock to

the DSP will be divided by 2 so an external 512/768 MCLK will become 256/384 fs internally and the

device otherwise operates as in Table 8 but with MCLK at twice the specified rate. See Table 6 for

software control.

PD, Rev 4.4, August 2013

28

w

WM8734

Production Data

USB MODE SAMPLE RATES

In USB mode the MCLK/crystal oscillator input is 12MHz only.

SAMPLING

RATE

MCLK

FREQUENCY

SAMPLE

RATE

REGISTER SETTINGS

DIGITAL

FILTER

TYPE

ADC

DAC

kHz

MHz

BOSR

SR3

SR2

SR1

SR0

48

12.000

0

1

0

1

0

1

0

1

0

3

2

44.1

12.000

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

0

1

(Note 2) (Note 2)

48

8

44.1

(Note 2)

8

(Note 1)

48

8

44.1

(Note 2)

(Note 1)

8

(Note 1) (Note 1)

32

96

88.2

(Note 3) (Note 3)

Table 13 USB Mode Sample Rate Look-up Table

Notes:

1. 8k not exact, actual = 8.021kHz

2. 44.1k not exact, actual = 44.118kHz

3. 88.1k not exact, actual = 88.235kHz

4. All other combinations of BOSR and SR[3:0] that are not in the truth table are invalid

The table above can be used to set up the device to work with various sample rate combinations. For

example if the user wishes to use the WM8734 in USB mode with the ADC and DAC sample rates at

48kHz and 48kHz respectively then the device should be programmed with BOSR = 0, SR3 = 0, SR2

= 0, SR1 = 0 and SR0 = 0. The ADC and DAC will then operate with a Digital Filter of type 0, refer to

Digital Filter Characteristics section for an explanation of the different filter types.

The BOSR bit represents the base over-sampling rate. This is the rate that the WM8734 digital signal

processing is carried out at and the sampling rate will always be a sub-multiple of this. In USB mode,

with BOSR = 0, the base over-sampling rate is defined at 250fs, with BOSR = 1, the base over-

sampling rate is defined at 272fs. This can be used to determine the actual audio sampling rate

produced by the ADC and required by the DAC.

Example scenarios are, :-

1. with a requirement that the ADC data sampling rate is 8kHz and DAC data sampling rate is

48kHz the device is programmed with BOSR = 0 (250fs), SR3 = 0, SR2 = 0, SR1 = 1, SR0 =

0.The ADC will then be exactly 8kHz ( derived from 12MHz/250 x 1/6 ) and the DAC expects

data at exactly 48kHz ( derived from 12MHz/250 ).

2. with a requirement that ADC data rate is 8kHz and DAC data rate is 44.1kHz the device is

programmed with BOSR = 0 (272fs), SR3 = 0, SR2 = 0, SR1 = 1, SR0 = 0. The ADC will not

output data at exactly 8kHz, instead it will be 8.021kHz ( derived from 12MHz/272 x 2/11 ) and

the DAC at 44.118kHz ( derived from 12MHz/272 ). A slight (sub 0.5%) pitch shift will therefore

results in the 8kHz and 44.1kHz audio data and (more importantly) the user must ensure that

PD, Rev 4.4, August 2013

29

w

WM8734

Production Data

the data across the digital interface is correctly synchronised at the 8.021kHz and 44.117kHz

rates.

The exact sample rates supported for all combinations are defined by the relationships in Table 14

below.

TARGET

ACTUAL SAMPLING RATE

SAMPLING

RATE

BOSR=0

BOSR=1

(272fs)

( 250fs)

kHz

8

8.021

12MHz/(250 x 48/8)

32

12MHz/(272 x 11/2)

not available

32

44.1

48

12MHz/(250 x 48/32)

not available

44.117

12MHz/272

48

not available

12MHz/250

88.2

96

not available

88.235

12MHz/136

96

not available

12MHz/125

Table 14 USB Mode Actual Sample Rates

ACTIVATING DSP AND DIGITAL AUDIO INTERFACE

To prevent any communication problems from arising across the Digital Audio Interface the Audio

Interface is disabled (tristate with weak 100k pulldown). Once the Audio Interface and the Sampling

Control has been programmed it is activated by setting the ACTIVE bit under Software Control.

REGISTER

ADDRESS

BIT

LABEL

DEFAULT

DESCRIPTION

0001001

Active Control

0

ACTIVE

0

Activate Interface

1 = Active

0 = Inactive

Table 15 Activating DSP and Digital Audio Interface

It is recommended that between changing any content of Digital Audio Interface or Sampling Control

Register that the active bit is reset then set.

SOFTWARE CONTROL INTERFACE

The software control interface may be operated using either a 3-wire (SPI-compatible) or 2-wire MPU

interface. Selection of interface format is achieved by setting the state of the MODE pin.

In 3-wire mode, SDIN is used for the program data, SCLK is used to clock in the program data and

CSB is used to latch in the program data. In 2-wire mode, SDIN is used for serial data and SCLK is

used for the serial clock. In 2-wire mode, the state of CSB pin allows the user to select one of two

addresses.

Unused register bits should always be set to ‘0’ unless specified otherwise.

SELECTION OF SERIAL CONTROL MODE

The serial control interface may be selected to operate in either 2 or 3-wire modes. This is achieved

by setting the state of the MODE pin.

MODE

INTERFACE

FORMAT

0

1

2 wire

3 wire

Table 16 Control Interface Mode Selection

PD, Rev 4.4, August 2013

30

w

WM8734

Production Data

3-WIRE (SPI COMPATIBLE) SERIAL CONTROL MODE

The WM8734 can be controlled using a 3-wire serial interface. SDIN is used for the program data,

SCLK is used to clock in the program data and CSB is use to latch in the program data. The 3-wire

interface protocol is shown in Figure 23.

CSB

SCLK

B15

B14

B13

B12

B11

B10

B9

B8

B7

B6

B5

B4

B3

B2

B1

B0

SDIN

Figure 23 3-Wire Serial Interface

Notes:

1. B[15:9] are Control Address Bits

2. B[8:0] are Control Data Bits

2-WIRE SERIAL CONTROL MODE

The WM8734 supports a 2-wire MPU serial interface. The device operates as a slave device only.

The WM8734 has one of two slave addresses that are selected by setting the state of pin 10, (CSB).

ACK

DATA B15-8

R ADDR

R/W

DATA B7-0

SDIN

SCLK

START

STOP

Figure 24 2-Wire Serial Interface

Notes:

1. B[15:9] are Control Address Bits

2. B[8:0] are Control Data Bits

CSB STATE

Address

(Default = LOW)

0

1

0011010

0011011

Table 17 2-Wire MPU Interface Address Selection

To control the WM8734 on the 2-wire bus the master control device must initiate a data transfer by

establishing a start condition, defined by a high to low transition on SDIN while SCLK remains high.

This indicates that an address and data transfer will follow. All peripherals on the 2-wire bus respond

to the start condition and shift in the next eight bits (7-bit address + R/W bit). The transfer is MSB

first. The 7-bit address consists of a 6-bit base address + a single programmable bit to select one of

two available addresses for this device (see table 24). If the correct address is received and the R/W

bit is ‘0’, indicating a write, then the WM8734 will respond by pulling SDIN low on the next clock pulse

(ACK). The WM8734 is a write only device and will only respond to the R/W bit indicating a write. If

the address is not recognised the device will return to the idle condition and wait for a new start

condition and valid address.

Once the WM8734 has acknowledged a correct address, the controller will send eight data bits (bits

B[15]-B[8]). WM8734 will then acknowledge the sent data by pulling SDIN low for one clock pulse.

PD, Rev 4.4, August 2013

31

w

WM8734

Production Data

The controller will then send the remaining eight data bits (bits B[7]-B[0]) and the WM8734 will then

acknowledge again by pulling SDIN low.

A stop condition is defined when there is a low to high transition on SDIN while SCLK is high. If a start

or stop condition is detected out of sequence at any point in the data transfer then the device will

jump to the idle condition.

After receiving a complete address and data sequence the WM8734 returns to the idle state and

waits for another start condition. Each write to a register requires the complete sequence of start

condition, device address and R/W bit followed by the 16 register address and data bits.

Note that the 16 bit control word is made up of 7 address bits, B[15:9], and 9 data bits, B[8:0]. These

are transmitted as 2 blocks of 8 bits. The first block contains 7 address bits and the data HSB. The

second block contains the 8 data LSBs.

POWER DOWN MODES

The WM8734 contains power conservation modes in which various circuit blocks may be safely

powered down in order to conserve power. This is software programmable as shown in the table

below.

REGISTER

ADDRESS

BIT

LABEL

DEFAULT

DESCRIPTION

0000110

0

2

3

4

7

LINEINPD

1

Line Input Power Down

1 = Enable Power Down

0 = Disable Power Down

ADC Power Down

Power Down

Control

ADCPD

1

1 = Enable Power Down

0 = Disable Power Down

DAC Power Down

DACPD

1 = Enable Power Down

0 = Disable Power Down

Line Output Power Down

1 = Enable Power Down

0 = Disable Power Down

Power Off Device

OUTPD

POWEROFF

1 = Device Power Off

0 = Device Power On

Table 18 Power Conservation Modes Software Control

When writing to the powerdown register bits 1,5 and 6 should be set to ‘1’.

The power down control can be used to either a) permanently disable functions when not required in

certain applications or b) to dynamically power up and down functions depending on the operating

mode, e.g.: during playback or record. Please follow the special instructions below if dynamic

implementations are being used.

LINEINPD: Simultaneously powers down both the Line Inputs. This can be done dynamically without

any audible effects either on the ADC or to the Line Outputs in Bypass mode. This is of use when the

device enters Playback, Pause or Stop modes or the Microphone input has been selected.

ADCPD: Powers down the ADC and ADC Filters. If this is done dynamically then audible pops will

result if any signals were present through the ADC. To overcome this whenever the ADC is to be

powered down, either mute the Microphone Input (MUTEIN) or MUTELINEIN, then change ADCPD.

This is of use when the device enters Playback, Pause or Stop modes regardless of whether

Microphone or Line Inputs are selected.

DACPD: Powers down the DAC and DAC Digital Filters. If this is done dynamically then audible pops

will result unless the following guidelines are followed. In order to prevent pops, the DAC should first

be soft-muted (DACMU), the output should then be de-selected from the line and headphone output

(DACSEL), then the DAC powered down (DACPD). This is of use when the device enters Record,

Pause, Stop or Bypass modes.

PD, Rev 4.4, August 2013

32

w

WM8734

Production Data

The device can be put into a standby mode (STANDBY) by powering down all the audio circuitry

under software control as shown in Table 18. Provision has been made to independently power off

these areas according to Table 19.

DESCRIPTION

STANDBY

0

1

Table 19 Standby Mode

In STANDBY mode the Control Interface, a small portion of the digital and areas of the analogue

circuitry remain active. The active analogue includes the analogue VMID reference so that the

analogue line inputs, line outputs and headphone outputs remain biased to VMID. This reduces any

audible effects caused by DC glitches when entering or leaving STANDBY mode.

The device can be powered off by writing to the POWEROFF bit of the Power Down register. In

POWEROFF mode the Control Interface and a small portion of the digital remain active. The

analogue VMID reference is disabled.

DESCRIPTION

POWEROFF

1

X

Table 20 Poweroff Mode

PD, Rev 4.4, August 2013

33

w

WM8734

Production Data

REGISTER MAP

The complete register map is shown in Table 21. The detailed description can be found in the

relevant text of the device description. There are 8 registers with 9 bits per register. These can be

controlled using either the 2 wire or 3 wire MPU interface.

REGISTER

ADDRESS

BIT

LABEL

DEFAULT

DESCRIPTION

0000000

4:0

LINVOL[4:0]

10111

( 0dB )

Left Channel Line Input Volume

Control

Left Line In

11111 = +12dB . . 1.5dB steps down

to 00000 = -34.5dB

7

8

LINMUTE

1

0

Left Channel Line Input Mute to ADC

1 = Enable Mute

0 = Disable Mute

LRINBOTH

Left to Right Channel Line Input

Volume and Mute Data Load Control

1 = Enable Simultaneous Load of

LINVOL[4:0] and LINMUTE to

RINVOL[4:0] and RINMUTE

0 = Disable Simultaneous Load

0000001

4:0

RINVOL[4:0]

10111

( 0dB )

Right Channel Line Input Volume

Control

Right Line In

11111 = +12dB . .1.5dB steps down

to 00000 = -34.5dB

7

8

RINMUTE

1

0

Right Channel Line Input Mute to ADC

1 = Enable Mute

0 = Disable Mute

RLINBOTH

Right to Left Channel Line Input

Volume and Mute Data Load Control

1 = Enable Simultaneous Load of

RINVOL[4:0] and RINMUTE to

LINVOL[4:0] and LINMUTE

0 = Disable Simultaneous Load

DAC Select

0000100

4

DACSEL

0

Analogue Audio

Path Control

1 =Select DAC

0 = Don’t select DAC

ADC High Pass Filter Enable

1 = Enable High Pass Filter

0 = Disable High Pass Filter

De-emphasis Control

11 = 48kHz

0000101

0

ADCHPD

DEEMP[1:0]

0

Digital Audio

Path Control

2:1

00

10 = 44.1kHz

01 = 32kHz

00 = Disable

3

4

DACMU

HPOR

1

0

DAC Soft Mute Control

1 = Enable soft mute

0 = Disable soft mute

Store dc offset when High Pass Filter

disabled

1 = store offset

0 = clear offset

PD, Rev 4.4, August 2013

34

w

WM8734

Production Data

DESCRIPTION

REGISTER

ADDRESS

BIT

LABEL

DEFAULT

0000110

0

LINEINPD

1

Line Input Power Down

1 = Enable Power Down

0 = Disable Power Down

ADC Power Down

Power Down

Control

2

ADCPD

1

1 = Enable Power Down

0 = Disable Power Down

DAC Power Down

3

DACPD

1

1 = Enable Power Down

0 = Disable Power Down

Line Output Power Down

1 = Enable Power Down

0 = Disable Power Down

POWEROFF mode

4

OUTPD

1

7

POWEROFF

FORMAT[1:0]

1

1 = Enable POWEROFF

0 = Disable POWEROFF

Audio Data Format Select

0000111

1:0

10

Digital Audio

Interface Format

11 = DSP Mode, frame sync + 2 data

packed words

10 = I²S Format, MSB-First left-1

justified

01 = MSB-First, left justified

00 = MSB-First, right justified

Input Audio Data Bit Length Select

11 = 32 bits

3:2

IWL[1:0]

10

10 = 24 bits

01 = 20 bits

00 = 16 bits

4

LRP

0

DACLRC phase control (in left, right

or I²S modes)

1 = Right Channel DAC data when

DACLRC high

0 = Right Channel DAC data when

DACLRC low

(opposite phasing in I²S mode)

or

DSP mode A/B select (in DSP mode

only)

1 = MSB is available on 2nd BCLK

rising edge after ADCLRC/DACLRC

rising edge

0 = MSB is available on 1st BCLK

rising edge after ADCLRC/DACLRC

rising edge

5

6

7

LRSWAP

MS

0

DAC Left Right Clock Swap

1 = Right Channel DAC Data Left

0 = Right Channel DAC Data Right

Master Slave Mode Control

1 = Enable Master Mode

0 = Enable Slave Mode

Bit Clock Invert

BCLKINV

1 = Invert BCLK

0 = Don’t invert BCLK

PD, Rev 4.4, August 2013

35

w

WM8734

Production Data

DESCRIPTION

Mode Select

REGISTER

ADDRESS

BIT

LABEL

USB/

DEFAULT

0001000

0

NORMAL

Sampling

Control

1 = USB mode (250/272fs)

0 = Normal mode (256/384fs)

Base Over-Sampling Rate

0 = 256fs

1

BOSR

0

1 = 384fs

5:2

6

SR[3:0]

0000

0

ADC and DAC sample rate control

Core Clock divider select

1 = Core Clock is MCLK divided by 2

0 = Core Clock is MCLK

Activate Interface

CLKIDIV2

0001001

0

ACTIVE

0

Active Control

1 = Active

0 = Inactive

Table 21 Register Map Description

Note:

Unused register bits should be set to ‘0’ except when writing to Register 0000110, when bits 1,5 and 6

should be set to ‘1’.

PD, Rev 4.4, August 2013

36

w

WM8734

Production Data

DIGITAL FILTER CHARACTERISTICS

The ADC and DAC employ different digital filters. There are 4 types of digital filter, called Type 0, 1, 2

and 3. The performance of Types 0 and 1 is listed in the table below, the responses of all filters is

shown in the proceeding pages.

PARAMETER

TEST CONDITIONS

MIN

TYP

MAX

0.416fs

+/- 0.05

UNIT

ADC Filter Type 0 (USB Mode, 250fs operation)

Passband

+/- 0.05dB

-6dB

0

0.5fs

Passband Ripple

Stopband

dB

0.584fs

-60

Stopband Attenuation

f > 0.584fs

ADC Filter Type 1 (USB mode, 272fs or Normal mode operation)

Passband

+/- 0.05dB

-6dB

0

0.4535fs

+/- 0.05

0.5fs

Passband Ripple

Stopband

dB

Hz

0.5465fs

-60

Stopband Attenuation

f > 0.5465fs

-3dB

High Pass Filter Corner

Frequency

3.7

-0.5dB

10.4

21.6

-0.1dB

DAC Filter Type 0 (USB mode, 250fs operation)

Passband

+/- 0.03dB

-6dB

0

0.416fs

+/-0.03

0.5fs

Passband Ripple

Stopband

dB

0.584fs

-50

Stopband Attenuation

f > 0.584fs

DAC Filter Type 1 (USB mode, 272fs or Normal mode operation)

Passband

+/- 0.03dB

-6dB

0

0.4535fs

+/- 0.03

Passband Ripple

Stopband

dB

0.5465fs

-50

Stopband Attenuation

f > 0.5465fs

Table 22 Digital Filter Characteristics

TERMINOLOGY

1. Stop Band Attenuation (dB) - the degree to which the frequency spectrum is attenuated (outside audio band)

2. Pass-band Ripple – any variation of the frequency response in the pass-band region

PD, Rev 4.4, August 2013

37

w

WM8734

Production Data

DAC FILTER RESPONSES

0.04

0.03

0.02

0.01

0

-20

-40

-60

-0.01

-0.02

-0.03

-0.04

-80

-100

0

0.5

1

1.5

2

2.5

3

0

0.05

0.1

0.15

0.2

0.25

0.3

0.35

0.4

0.45

0.5

Frequency (Fs)

Figure 25 DAC Digital Filter Frequency Response –Type 1

Figure 26 DAC Digital Filter Ripple –Type 1

0.02

0.01

0

-20

-0.01

-0.02

-0.03

-0.04

-0.05

-0.06

-40

-60

-80

-100

0

0.5

1

1.5

2

2.5

3

0

0.05

0.1

0.15

0.2

0.25

Frequency (Fs)

Figure 27 DAC Digital Filter Frequency Response –Type 2

Figure 28 DAC Digital Filter Ripple –Type 2

ADC FILTER RESPONSES

0.02

0.01

0

-20

-40

-0.01

-0.02

-0.03

-0.04

-0.05

-0.06

-60

-80

-100

0

0.5

1

1.5

2

2.5

3

0

0.05

0.1

0.15

0.2

0.25

0.3

0.35

0.4

0.45

0.5

Frequency (Fs)

Figure 29 ADC Digital Filter Frequency Response –Type 1

Figure 30 ADC Digital Filter Ripple –Type 1

PD, Rev 4.4, August 2013

38

w

WM8734

Production Data

0.02

0.01

0

-20

-40

-60

-80

-0.01

-0.02

-0.03

-0.04

-0.05

-0.06

-100

0

0.5

1

1.5

2

2.5

3

0

0.05

0.1

0.15

0.2

0.25

Frequency (Fs)

Figure 31 ADC Digital Filter Frequency Response –Type 2

Figure 32 ADC Digital Filter Ripple –Type 2

ADC HIGH PASS FILTER

The WM8734 has a selectable digital high pass filter to remove DC offsets. The filter response is

characterised by the following polynomial.

H(z) =

1 – z^-1

1 – 0.9995 z^-1

PD, Rev 4.4, August 2013

39

w

WM8734

Production Data

DIGITAL DE-EMPHASIS CHARACTERISTICS

0

0.4

0.3

0.2

0.1

0

-2

-4

-6

-0.1

-0.2

-0.3

-0.4

-8

-10

0

2000

4000

6000

8000

10000 12000 14000 16000

0

2000

4000

6000

8000

10000 12000 14000 16000

Frequency (Fs)

Figure 33 De-Emphasis Frequency Response (32kHz)

Figure 34 De-Emphasis Error (32kHz)

0

0.4

0.3

0.2

0.1

0

-2

-4

-6

-0.1

-0.2

-0.3

-0.4

-8

-10

0

5000

10000

Frequency (Fs)

15000

20000

0

5000

10000

Frequency (Fs)

15000

20000

Figure 35 De-Emphasis Frequency Response (44.1kHz)

Figure 36 De-Emphasis Error (44.1kHz)

0

0.4

0.3

0.2

0.1

0

-2

-4

-6

-0.1

-0.2

-0.3

-0.4

-8

-10

0

5000

10000

15000

20000

0

5000

10000

15000

20000

Frequency (Fs)

Figure 37 De-Emphasis Frequency Response (48kHz)

Figure 38 De-Emphasis Error (48kHz)

PD, Rev 4.4, August 2013

40

w

WM8734

Production Data

APPLICATIONS INFORMATION

RECOMMENDED EXTERNAL COMPONENTS

3.3V

2

10

11

DBVDD

+

AVDD

AGND

0.1 F

10 F

0.1

F

10 F

1

DGND

10 F

0.1 F

3.3V

20

DCVDD

LLINEIN

+

5K

14

5K

470nF

47pF

+

5K

+

13

100

8

RLINEIN

LOUT

ROUT

5K

470nF

47k

47pF

WM8734

Codec

+

100

9

5

4

6

470nF

47k

DACLRC

DACDAT

ADCDAT

ADCLRC

BCLK

Audio Serial Data I/F

7

3

3.3V

3-wire Interface

10k

15

16

2-wire Interface

MODE

CSB

SDIN

SCLK

12

VMID

3-wire or 2-wire

MPU Interface

17

18

+

0.1 F

10 F

MCLK

19

Figure 39 External Components Diagram

Notes:

1. Where possible, it is recommended that NPO or COG type capacitors should be used for best performance.

PD, Rev 4.4, August 2013

41

w

WM8734

Production Data

MINIMISING POP NOISE AT THE ANALOGUE OUTPUTS

To minimise any pop or click noise when the system is powered up or down, the following procedures

are recommended.

POWER UP SEQUENCE



Switch on power supplies. By default the WM8734 is in Standby Mode, the DAC is

digitally muted and the Audio Interface and Outputs are all OFF.



Set all required bits in the Power Down register (0Ch) to ‘0’; EXCEPT the OUTPD bit,

this should be set to ‘1’ (Default).



Set required values in all other registers except 12h (Active).

Set the ‘Active’ bit in register 12h.

The last write of the sequence should be setting OUTPD to ‘0’ (active) in register

0Ch, enabling the DAC signal path, free of any significant power-up noise.

POWER DOWN SEQUENCE



Set the OUTPD bit to ‘1’ (power down).

Remove the WM8734 supplies.

PD, Rev 4.4, August 2013

42

w

WM8734

Production Data

PACKAGE DIMENSIONS

DS: 20 PIN SSOP (7.2 x 5.3 x 1.75 mm)

DM0015.C

b

e

20

11

E1

E

GAUGE

PLANE



1

10

D

0.25

L

c

A1

A A2

L

1

-C-

C

0.10

SEATING PLANE

Dimensions

(mm)

NOM

-----

Symbols

MIN

-----

MAX

2.0

-----

1.85

0.38

0.25

7.50

A

A₁

A₂

b

c

D

e

E

E₁

L

0.05

1.65

0.22

0.09

6.90

-----

1.75

0.30

-----

7.20

0.65 BSC

7.80

7.40

5.00

0.55

8.20

5.60

0.95

5.30

0.75

L₁



1.25 REF

0^o

4^o

8^o

-

JEDEC.95, MO 150

REF:

NOTES:

A. ALL LINEAR DIMENSIONS ARE IN MILLIMETERS.

B. THIS DRAWING IS SUBJECT TO CHANGE WITHOUT NOTICE.

C. BODY DIMENSIONS DO NOT INCLUDE MOLD FLASH OR PROTRUSION, NOT TO EXCEED 0.20MM.

D. MEETS JEDEC.95 MO-150, VARIATION = AE. REFER TO THIS SPECIFICATION FOR FURTHER DETAILS.

PD, Rev 4.4, August 2013

43

w

WM8734

Production Data

IMPORTANT NOTICE

Wolfson Microelectronics plc (“Wolfson”) products and services are sold subject to Wolfson’s terms and conditions of sale,

delivery and payment supplied at the time of order acknowledgement.

Wolfson warrants performance of its products to the specifications in effect at the date of shipment. Wolfson reserves the

right to make changes to its products and specifications or to discontinue any product or service without notice. Customers

should therefore obtain the latest version of relevant information from Wolfson to verify that the information is current.

Testing and other quality control techniques are utilised to the extent Wolfson deems necessary to support its warranty.

Specific testing of all parameters of each device is not necessarily performed unless required by law or regulation.

In order to minimise risks associated with customer applications, the customer must use adequate design and operating

safeguards to minimise inherent or procedural hazards. Wolfson is not liable for applications assistance or customer

product design. The customer is solely responsible for its selection and use of Wolfson products. Wolfson is not liable for

such selection or use nor for use of any circuitry other than circuitry entirely embodied in a Wolfson product.

Wolfson’s products are not intended for use in life support systems, appliances, nuclear systems or systems where

malfunction can reasonably be expected to result in personal injury, death or severe property or environmental damage.

Any use of products by the customer for such purposes is at the customer’s own risk.

Wolfson does not grant any licence (express or implied) under any patent right, copyright, mask work right or other

intellectual property right of Wolfson covering or relating to any combination, machine, or process in which its products or

services might be or are used. Any provision or publication of any third party’s products or services does not constitute

Wolfson’s approval, licence, warranty or endorsement thereof. Any third party trade marks contained in this document

belong to the respective third party owner.

Reproduction of information from Wolfson datasheets is permissible only if reproduction is without alteration and is

accompanied by all associated copyright, proprietary and other notices (including this notice) and conditions. Wolfson is

not liable for any unauthorised alteration of such information or for any reliance placed thereon.

Any representations made, warranties given, and/or liabilities accepted by any person which differ from those contained in

this datasheet or in Wolfson’s standard terms and conditions of sale, delivery and payment are made, given and/or

accepted at that person’s own risk. Wolfson is not liable for any such representations, warranties or liabilities or for any

reliance placed thereon by any person.

ADDRESS:

Wolfson Microelectronics plc

26 Westfield Road

Edinburgh

EH11 2QB

United Kingdom

Tel :: +44 (0)131 272 7000

Fax :: +44 (0)131 272 7001

Email :: sales@wolfsonmicro.com

PD, Rev 4.4, August 2013

44

w

WM8734

Production Data

REVISION HISTORY

DATE

REV

DESCRIPTION OF CHANGES

QFN references removed from datasheet

CHANGED BY

09/05/13

4.4

JMacD

PD, Rev 4.4, August 2013

45

w

厂商	型号	描述	页数
WOLFSON	XWM8146CDW/V	12位（8 + 4位）的线性传感器图像处理器[ 12-bit(8+4-bit) Linear Sensor Image Processor ]	17 页
WOLFSON	XWM8148CFT/V	12位/ 12MSPS CCD / CIS模拟前端/数字转换器[ 12-bit/12MSPS CCD/CIS Analogue Front End/Digitiser ]	43 页
WOLFSON	XWM8170CFT/V	3.3V集成信号处理器的面阵CCD的[ 3.3V Integrated Signal Processor for Area Array CCDs ]	41 页
WOLFSON	XWM8181CDW	12位2MSPS串行输出CIS / CCD数字转换器[ 12-bit 2MSPS Serial Output CIS/CCD Digitiser ]	14 页
WOLFSON	XWM8190CDW/V	（ 8 + 6 ）位输出14位CIS / CCD AFE /数字转换器[ (8+6) Bit Output 14-bit CIS/CCD AFE/Digitiser ]	25 页
WOLFSON	XWM8191CFT	14位6MSPS CIS / CCD模拟前端/数字转换器[ 14-bit 6MSPS CIS/CCD Analogue Front End/Digitiser ]	27 页
WOLFSON	XWM8192	（88）位输出16位CIS / CCD AFE /数字转换器[ (88) Bit Output 16-bit CIS/CCD AFE/Digitiser ]	24 页
WOLFSON	XWM8192CDW/V	（88）位输出16位CIS / CCD AFE /数字转换器[ (88) Bit Output 16-bit CIS/CCD AFE/Digitiser ]	24 页
CIRRUS	XWM8194CDW/V	[ Analog Circuit, 1 Func, CMOS, PDSO28, 7.50 MM, 1.27 MM PITCH, MS-013AE, SOIC-28 ]	27 页
WOLFSON	XWM81955CFT/RV	14位12MSPS CIS / CCD模拟前端/数字转换器[ 14-bit 12MSPS CIS/CCD Analogue Front End/Digitiser ]	33 页
