Document No.
Rev. No.
SPE/LM1-AYL1-11-N1-MT
01
Standard bins for LM1-AYL1-11-N1-MT (IF = 50mA):
Lamps are sorted to Luminous Intensity –IV, VF & Dominant Wavelength –λ bins shown.
D
Orders for LM1-AYL1-11-N1-MT may be filled with any or all bins contained as below.
All Luminous Intensity –IV, VF & Dominant Wavelength –λ values shown and specified are at If=50mA.
D
* V1+
X2
X3
X4
X5
1800mcd
1120mcd
900mcd
710mcd
W1
V2
V1
584nm
587nm
590nm
593nm
596nm
Dominant Wavelength (λD)
* V1+ indicates Luminous Intensity is at V1 bin or above.
Forward Voltage (VF)
Rank
V4
V5
V6
2.6-2.8V
V7
2.8-3.0V
Voltage
2.2-2.4
2.4-2.6V
#The quantity not enough for full reel
VF(V)
2.2-2.6
2.6-3.0
*Majority VF bins are highlighted in Yellow.
Important Notes:
1) All ranks will be included per delivery, rank ratio will be based on Dices distribution.
2) Tolerance of measurement of luminous intensity is ±10%
3) Tolerance of measurement of dominant wavelength is ±1nm.
4) Tolerance of measurement of Vf is ±0.05 V.
5) Packaging methods are available for selection, please refer to PACKAGING STANDARD.
#The notice is only apply quantity not enough for full reel.
6) Please refer to LED LAMP RELIABILITY TEST STANDARD for reliability test conditions.
7) Please refer to APPLICATION NOTES for Application.
3/4
Format #: COTCO-D-074 REV.4
