LM1-AYL1-11-N1
1210 PLCC-4 Yellow SMT LED
- 3 Northway Lane North - Latham, New York 12110 - Toll Free: 800.984.5337 - Fax: 518.785.4725
Company Headquarters
- 950 South Coast Drive, Suite 225 - Costa Mesa, California 92626 - Toll Free: 800.984.5337 - Fax: 714.850.9314
California Sales Office
Web:
Email:
info@marktechopto.com
www.marktechopto.com
Applications:
- Automobile Applications
- Illuminations
- Indicators
- LCD Back lights
- RGB Full color displays
o
Maximum Characteristics (Ta = 25 C)
Characteristics (symbol)
Forward Current ( I
Max (unit)
)
70 mA
F
Reverse Voltage ( V
)
10 V
R
Power Dissipation ( P
)
210 mW
-40 ~ +100
-40 ~ +100
D
o
C
Operating Temperature ( T
)
opr
o
C
Storage Temperature ( T
)
stg
o
C
Soldering Temperature ( T
Soldering Time
)
260
sol
for 3 sec. max
o
Opto-Electrical Characteristics (Ta=25 C)
Characteristics (symbol)
Test Condition
Min
Typ
Max
I =50mA
F
-
2.40 ( V )
3.00 ( V )
Forward Voltage ( F
)
V
-
10 ( µA )
Reverse Voltage ( I
)
R
Luminous Intensity ( I
)
I =50mA
F
710.00 ( lm )
1000.00 ( lm )
120 °
0.00 ( lm )
V
Viewing Angle ( 2θ1/2 )
Peak Wavelength ( λp )
I =50mA
F
596 ( nm )
592 ( nm )
13 (nm)
Dominant Wavelength ( λd )
Spectral Line Half Width ( ∆λ )
I =50mA
F
I =50mA
F
Specifications Subject To Change Without Notice.
