IWFM08U9501

型号:

IWFM08U9501

品牌:

IVO[ BAUMER IVO GMBH & CO. KG ]

页数:

1 页

PDF大小:

66 K

Inductive sensors
Inductive linear sensors
IWFM 08
sample drawing
4,7
8
standard cable length 200 mm (L)
general data
sample picture
mounting type
measuring distance Sd
resolution
quasi-flush
0 ... 2 mm
< 0,001 mm (stat.)
< 0,005 mm (dynam.)
< 0,02 mm
repeat accuracy
linearity error
100 µm
temperature drift
5 ꢀ (ꢁull Scale)
electrical data
response time (factory characteristic)
current consumption max. (no load)
output circuit
< 1 ms
10 mA
voltage output
> 3000 Ohm
yes
load resistance
short circuit protection
reverse polarity protection
yes
mechanical data
type
rectangular
housing material
dimension
die-cast zinc nickel plated
8 mm
housing length
16 mm
ambient conditions
operating temperature
protection class
10 ... +60 °C
IP 67
order reference
output signal
voltage supply range +Vs
connection types
IWFM 08U6501
0 ... 5 VDC
0 ... 5 VDC
0 ... 10 VDC
0 ... 10 VDC
10,8 ... 14,4 VDC
10,8 ... 14,4 VDC
15 ... 30 VDC
cable, 2 m
IWFM 08U6501/KS35
IWFM 08U9501
flylead connector M8
cable, 2 m
IWFM 08U9501/KS35
15 ... 30 VDC
flylead connector M8
1
9/1/2014
www.baumer.com
