ELECTRICAL CHARACTERISTICS
AT 25°C
More detailed information can be found in the
Application Manual.
Output Frequency
F
100.000
±20
kHz
ppm
V
1)
2)
Frequency tolerance
ΔF/F
VDD
IDD
Supply voltage
1.2 – 5.5
0.65 / 0.85
40 / 60
0.5
Current consumption (typ./max.)
Duty cycle (min./max.)
Start up time (max.)
µA
%
tstart
s
Voltage coefficient (max.)
Aging first year max. @ 25°C
Turnover temperature (typ.)
Frequency vs. temperature
1) Tighter tolerances on request.
±1.5
ppm/V
ppm
°C
ΔF/F
T0
±3
18 ±5
ΔF/F0
–0.035 ppm
/
(T - T0)2 ±10%
ppm
C
° ²
2) VDD = 3.0 V, CLKOE = LOW.
ENVIRONMENTAL
Conditions
Max. Dev.
CHARACTERISTICS
Storage temp. range
TA Operating temperature range
Shock resistance
–55 to +125°C
–40 to +85°C
5000 g, 0.3 ms, ½ sine ±5 ppm
ΔF/F
ΔF/F
Vibration resistance
20 g / 10–2000 Hz
±5 ppm
TERMINATIONS AND
PROCESSING
Type
Termination
Processing
For SMT mounting
Au flashed pads
IPC/JEDEC J-STD-020C
260°C / 20 - 40 s
OV-0100-C7
20.0
0.0
FREQUENCY TEMPERATURE
CHARACTERISTICS
-20.0
-40.0
-60.0
-80.0
-100.0
-120.0
-140.0
-160.0
-180.0
-60
-40
-20
0
20
40
60
80
100
T [°C]
Tuning Fork Crystal
ORDERING INFORMATION
O V - 0100 - C7 ±20 ppm TA QC
Oscillator
Qualification
QC = Commercial Grade (Standard)
QA = Automotive Grade AEC-Q200
QM = Medical Grade
Ceramic lid
Frequency
0100 = 100.000 kHz
Temperature range
TA = -40 to +85°C (Standard)
Package size
C7 = 3.2 x 1.5 x 1.0 mm
Frequency tolerance
A unique part number will be generated for each product specification, i.e:
20xxxx-MG01
20xxxx-MG03
1'000 pcs (in 12 mm tape on 7" reel)
3'000 pcs (in 12 mm tape on 7" reel)
All specifications subject to change without notice.
Micro Crystal AG
Muehlestrasse 14
CH-2540 Grenchen
Switzerland
Phone +41 32 655 82 82
Fax +41 32 655 82 83
sales@microcrystal.com
www.microcrystal.com
Version 4.1/05.2017
