Advanced Data Sheet
Product Description
STM-2016
The Stanford Microdevices’ STM-2016 is a high linearity
active mixer for use in a wide variety of communication
systems covering the 1800-2200 MHz frequency bands.
This device operates from a single 5V supply and provides
9dB of conversion gain while requiring only 0dBm input to
the integrated LO driver. The STM-2016 also includes an
integrated on chip IF amplifier and is fabricated using sili-
con germanium device technology.
1800 - 2200 MHz High Linearity
Silicon Germanium
Active Transmit Mixer
The STM-2016 incorporates internal matching on each RF,
IF, and LO port to enhance ease of use and to reduce the
number of external components required. The IF and LO
ports can be driven differential or single ended. Each
broadband port has been designed to minimize perfor-
mance degradation while operating into highly reactive
components such as SAW filters.
16 pin TSSOP with Exposed Pad
Package Body: 0.20 x 0.17 x 0.04 (inches)
5.0 x 4.4 x 1.0 (mm)
Product Features
Functional Block Diagram
• Active mixer with conversion gain
• No need for separate external LO driver
• Low LO drive level required to drive mixer
• IF and LO ports may be driven single-ended
• Single supply operation (+5V)
• Broadband resistive 50Ω impedances on all
three ports
VEE
VCC
VEE
RFN
RFP
VEE
VCC
IFN
1
2
3
4
5
6
7
8
16 VEE
15 VCC
14 VEE
13 LON
12 LOP
11 VEE
10 VCC
Applications
• Digital and spread spectrum communication
systems
• 1800-2200 MHz transceivers for base station
infrastructure equipment
9
IFP
Key Specifications
Parameters
Test Conditions (VCC=5.0V, I=190mA, T=25ºC)
Unit
MHz
MHz
dBm
dBm
dB
Min.
1800
10
Typ.
Max.
2200
300
RF Frequency Range
IF Frequency Range
Output IP3
200
+15
+3.5
9
IF1 = IF2 = -20 dBm/tone
Output P1dB
Conversion Gain
SSB Noise Figure
dB
9
