DATA SHEET
1U1G thru 1U6G
GLASS PASSIVATED JUNCTION ULTRAFAST RECOVERY RECTIFIER
R-1
Unit: inch(mm)
1.0 Amperes
50 to 800 Volts
CURRENT
VOLTAGE
FEATURES
• Plastic package has Underwriters Laboratory
Flammability Classification 94V-O utilizing
Flame Retardant Epoxy Molding Compound
.025(.64)
.021(.53)
• Exceeds environmental standards of MIL-S-19500/228.
• Ultra Fast switching for high efficiency.
• Both normal and Pb free product are available :
Normal : 80~95% Sn, 5~20% Pb
Pb free: 98.5% Sn above
MECHANICALDATA
.102(2.6)
.087(2.2)
Case: Molded plastic, R-1
Terminals: Axial leads, solderable per MIL-STD-202,Method 208
Polarity: Band denotes cathode
Mounting Position: Any
Weight: 0.0064 ounce, 0.181 gram
MAXIMUMRATINGSANDELECTRICALCHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified. Resistive or inductive load, 60Hz.
PARAMETER
SYMBOL
UNITS
1U1G 1U2G
1U3G
200
1U4G 1U5G 1U6G
Maximum Recurrent Peak Reverse Voltage
V
V
RRM
RMS
50
35
50
100
70
400
280
400
600
420
600
800
560
800
V
Maximum RMS Voltage
140
200
V
V
A
Maximum DC Blocking Voltage
V
DC
100
Maximum Average Forward Current .375"(9.5mm)
I
AV
1.0
lead length at TA
=55OC
Peak Forward Surge Current : 8.3ms single half sine-
wave superimposed on rated load(JEDEC method)
I
FSM
30
A
V
Maximum Forward Voltage at 1.0A
V
F
1.0
1.3
1.7
Maximum DC Reverse Current T
at Rated DC Blocking Voltage
J
=25OC
J
=125OC
10.0
150
I
R
uA
T
Typical Junction capacitance (Note 1)
C
J
17
60
pF
OC / W
ns
Typical Thermal Resistance(Note 2)
RθJA
Maximum Reverse Recovery Time (Note 3)
Operating Junction and Storage Temperature Range
T
RR
50
100
T
J
,TSTG
-55 TO +150
OC
NOTES:
1. Measured at 1 MHz and applied reverse voltage of 4.0 VDC.
2. Thermal Resistance from Junction to Ambient and from Junction to lead length 0.375”(9.5mm) P.C.B. mounted.
3. Reverse Recovery Time IF=.5A ,IR=1A , Irr=.25A
