1U1 ~ 1U7
ULTRAFAST RECOVERYRECTIFIERS
Unit: inch(mm)
R-1
1.0 Amperes
50 to 1000 Volts CURRENT
VOLTAGE
FEATURES
• Plastic package has Underwriters Laboratory
Flammability Classification 94V-O utilizing
Flame Retardant Epoxy Molding Compound
.025(.64)
.021(.53)
• Exceeds environmental standards of MIL-S-19500/228.
• Ultra Fast switching for high efficiency.
• In compliance with EU RoHS 2002/95/EC directives
MECHANICAL DATA
• Case: Molded plastic, R-1
• Terminals: Axial leads, solderable per MIL-STD-750,Method 2026
• Polarity: Band denotes cathode
• Mounting Position: Any
.102(2.6)
.087(2.2)
• Weight: 0.0068 ounce, 0.1937 gram
MAXIMUMRATINGSANDELECTRICALCHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified. Resistive or inductive load, 60Hz.
PARAMETER
SYMBOL
UNITS
1U1
50
1U2
100
1U3
200
1U4
400
1U5
600
1U6
1U7
Maximum Recurrent Peak Reverse Voltage
VR R M
800 1000
V
V
V
A
A
V
Maximum RMS Voltage
VR M S
VD C
IF ( A V )
IF S M
VF
35
50
70
140
200
280
400
1.0
30
420
600
560
700
Maximum DC Blocking Voltage
100
800 1000
Maximum Average Forward Current .375"(9.5mm)
lead length at TA =55O
C
Peak Forward Surge Current : 8.3ms single half sine-wave
superimposed on rated load(JEDEC method)
Maximum Forward Voltage at 1.0A
1.0
1.3
1.7
Maximum DC Reverse Current at TJ =25O
Rated DC Blocking Voltage TJ =100O
C
10.0
500
µA
IR
C
Typical Junction capacitance (Note 1)
Typical Thermal Resistance(Note 2)
CJ
17
65
pF
O C / W
ns
Rθ J A
Maximum Reverse Recovery Time (Note 3)
tr r
50
75
Operating Junction and Storage Temperature Range
TJ ,TS T G
-55 to +150
O C
NOTES:
1. Measured at 1 MHz and applied reverse voltage of 4.0 VDC.
2. Thermal Resistance from Junction to Ambient and from Junction to lead length 0.375”(9.5mm) P.C.B. mounted.
3. Reverse Recovery Time IF=.5A ,IR=1A , Irr=.25A
