150W MICRO ATX PC Power with 1U Type
1U150 series
Features :
AC input range selected by switch
With +5VSB:0 ~ 1.5A max.
Power good signal output
Power fail signal output
High efficiency
Approvals: UL/ CUL/ CB /CE
Forced air cooling by built-in DC fan
100% full load burn-in test
Low cost
1 year warranty
SPECIFICATION
MODEL
CH1
CH2
CH3
CH4
CH5
STANDBY
DC VOLTAGE
3.3V
5V
12V
-5V
-12V
0.1A
0.5A
5VSB
0A
MINIMUM CURRENT
MAXIMUM CURRENT
RATED POWER (max.)
1.2A
2.4A
12A
1.0A
5.0A
0.1A
0.5A
6.0A
1.5A
150W continue
OUTPUT
RIPPLE & NOISE (max.) Note.2 50mVp-p
100mVp-p
1%
100mVp-p
1%
150mVp-p
2%
150mVp-p
2%
100mVp-p
1%
LINE REGULATION
LOAD REGULATION
HOLD UP TIME
1%
Note.3 5%
5%
10%
10%
10%
4%
16ms min. at full load
VOLTAGE RANGE
90 ~ 132VAC/180 ~ 264VAC selected by switch
FREQUENCY RANGE
EFFICIENCY (Typ.)
AC CURRENT
47~63Hz
70%
INPUT
5.0A / 115VAC 3.0A / 230VAC
INRUSH CURRENT (max.)
LEAKAGE CURRENT (max.)
40A / 115VAC
80A / 230VAC
3.5mA / 240VAC
105~150% rated output power
OVER LOAD
Protection type : Shut down o/p voltage, re-power on to recover
+5V, +12V: 110%~130% of rated voltage
PROTECTION OVER VOLTAGE
SHORT CIRCUIT
Protection type : Shut down o/p voltage, re-power on to recover
All output equipped with short circuit
Protection type : Shut down o/p voltage, re-power on to recover
POWER GOOD SIGNAL
The TTL compatible signal out with 100ms to 500ms delay after power set up
The TTL compatible signal will go down at least 1ms before +5V below 4.7V
Power on: PS-ON = "Low" or "<0.8V" ; Power off: PS-ON = "Hi" or ">2V"
FUNCTION
POWER FAIL SIGNAL
PS-ON INPUT SIGNAL
WORKING TEMP.
-10~+35
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
20~90% RH non-condensing
-20~+85 , 10~95% RH
ENVIRONMENT
0.05% / (0~50
)
10~200Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
UL1950 Approved
SAFETY STANDARDS
WITHSTAND VOLTAGE
ISOLATION RESISTANCE
I/P-O/P, I/P-FG:1.5KVAC
SAFETY &
I/P-O/P, I/P-FG:100M Ohms / 500VDC
EMI CONDUCTION & RADIATION Compliance to EN55022 (CISPR22) class B
EMC
(Note 4)
Compliance to EN61000-3-2,-3
HARMONIC CURRENT
EMS IMMUNITY
MTBF
Compliance to EN61000-4-2,3,4,5,6,8,11, Light industry level, criteria A
100K hrs min. MIL-HDBK-217F (25
)
CONNECTOR
COOLING
ATX main power connector*1ea Peripheral power connector* 4ea Floppy drive power connector* 1ea
OTHERS
NOTE
Forced air ventilation by 4cm DC fan
150*82*42.8mm (L*W*H)
DIMENSION
PACKING
0.6kg; 20pcs / 16kg / CARTON
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Load regulation is measured from 20% to 100% max. Load.
4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives.
File Name:1U-150-SPEC 2004-06-21
