Advanced Technical Information
VCES = 600 / 800V
IC25 = 60 A
VCE(sat) = 2.5 V
IGBT with Reverse
Blocking capability
IXRH 50N80
IXRH 50N60
tf
= 75 ns
C
TO-247 AD
G
G
C
E
C (TAB)
E
G = Gate,
C = Collector,
E = Emitter,
TAB = Collector
Features
IGBT
●
IGBT with NPT (non punch through)
structure
reverse blocking capability indepen-
dent from gate voltage
Symbol
VCES
Conditions
Maximum Ratings
±
800
±
600
TVJ = 25°C to 150°C
IXRH 50N80
IXRH 50N60
V
V
●
- function of series diode monolithically
integrated
- no external series diode required
- soft reverse recovery
positive temperature coefficient of
saturation voltage
- optimum current distribution
when paralleled
±
VGES
20
V
IC25
IC90
TC = 25°C
TC = 90°C
60
40
A
A
●
ICM
VCEK
VGE = 0/15 V; R = 22 Ω; TVJ = 125°C
80
A
V
RBSOA, ClampGed inductive load; L = 100 µH
500
Ptot
TC = 25°C
300
W
●
Epoxy of TO 247 package meets
UL 94V-0
Symbol
Conditions
Characteristic Values
(TVJ = 25°C, unless otherwise specified)
Applications
min.
typ. max.
converters requiring reverse blocking
capability:
- current source inverters
- matrix converters
- bi-directional switches
- resonant converters
- induction heating
VCE(sat)
IC = 40 A; VGE = 15 V; TVJ = 25°C
TVJ = 125°C
2.5
3.0
3.1
V
V
VGE(th)
ICES
IC = 2 mA; VGE = VCE
4
8
V
VCE = 0.8 VCES;VGE = 0 V; TVJ = 25°C
TVJ = 125°C
0.4 mA
mA
3.0
- auxiliary switches for soft switching
in the main current path
±
IGES
VCE = 0 V; VGE
=
20 V
500 nA
td(on)
tr
td(off)
tf
Eon
Eoff
80
100
380
75
3.6
2.1
ns
ns
ns
ns
mJ
mJ
Inductive load, TVJ = 125°C
VCE = 500 V; IC = 40 A
VGE = 0/15 V; RG = 22 Ω
Cies
QGon
VCE = 25 V; VGE = 0 V; f = 1 MHz
VCE = 500V; VGE = 15 V; IC = 40 A
4
150
nF
nC
IRM
trr
IF = 40 A; diC/dt = -400 A/µs; TVJ = 125°C
VCE = -500 V; VGE = 15 V
58
840
A
ns
RthJC
0.42 K/W
IXYS reserves the right to change limits, test conditions and dimensions.
© 2000 IXYS All rights reserved
1 - 2
