N-channel MOS-FET
250V
1,1W
4A
20W
FAP-IIA Series
> Characteristics
Typical Output Characteristics
Drain-Source On-State Resistance vs. Tch
Typical Transfer Characteristics
ID=f(VDS); 80µs pulse test; TC=25°C
RDS(on) = f(Tch); ID=2A; VGS=10V
ID=f(VGS); 80µs pulse test; VDS=25V; Tch=25°C
•
•
•
1
2
3
VDS [V] ®
Tch [°C] ®
VGS [V] ®
Typical Drain-Source On-State-Resistance vs. ID
Typical Transconductance
Gate Threshold Voltage vs. Tch
RDS(on)=f(ID); 80µs pulse test; TC=25°C
gfs=f(ID); 80µs pulse test; VDS=25V; Tch=25°C
VGS(th)=f(Tch); ID=1mA; VDS=VGS
•
•
•
4
5
6
ID [A] ®
ID [A] ®
Tch [°C] ®
Typical Capacitances
Typical Gate Charge Characteristics
Forward Characteristics of Reverse Diode
C=f(VDS); VGS=0V; f=1MHz
VGS=f(Qg); ID=4A
IF=f(VSD); 80µs pulse test; VGS=0V
•
•
•
•
7
8
9
VDS [V] ®
Qg [nC] ®
VSD [V] ®
Power Dissipation
Safe Operation Area
PD=f(Tc)
ID=f(VDS): D=0,01, Tc=25°C
•
Transient Thermal impedance
Zthch=f(t) parameter:D=t/T
•
10
•
12
Tch [°C] ®
VDS [V] ®
t [s] ®
